Summary of Contents for Logicbus SDS2000X Series
- Page 1 SDS2000X Series Digital Oscilloscope Quick Start...
-
Page 2: Copyright Information
Information in this publication replaces all previously corresponding material. Any way of copying, extracting or translating the contents of this manual is not allowed without the permission of SIGLENT. Note: SIGLENT is the registered trademark of SIGLENT TECHNOLOGIES CO., LTD. SDS2000X Series Digital Oscilloscope -I... -
Page 3: General Safety Summary
Use Only the Specified Fuse of the instrument. Before connecting the instrument, please read the manual carefully to gain more information about the ratings. Do Not Operate Without Covers Do not operate the instrument with covers or panels removed. II- SDS2000X Series Digital Oscilloscope... - Page 4 To avoid damages to the surface of the instrument and probe, please do not use any corrosive liquid or chemical cleanser. Make sure that the instrument is completely dry before restarting it to avoid short circuits or personal injuries. SDS2000X Series Digital Oscilloscope -III...
-
Page 5: Table Of Contents
Contents ............Copyright Information ............General Safety Summary ..............Quick start ............... The Front Panel ..............The Rear Panel ............Front Panel Overview ..............User Interface ............Using Security Lock ..............Troubleshooting ..............Contact us 1- SDS2000X Series Digital Oscilloscope... -
Page 6: Quick Start
SIGLENT. 3. Check the accessories Please check the accessories according to the packing list. If the accessories are incomplete or damaged, please contact your SIGLENT sales representative. Figure 2 Top View SDS2000X Series Digital Oscilloscope -2... - Page 7 Power Socket If at any time the fuse requires replacement, please replace only with a fuse of the same rating as the original. If there are questions, please contact Siglent directly. 3- SDS2000X Series Digital Oscilloscope...
- Page 8 Connect the Probe SIGLENT provides passive probes for the SDS2000X series oscilloscope. Please refer to corresponding Probe User Manual for detailed technical information. 1. Connect the BNC terminal of the probe to one of the channel BNC connectors on the front panel.
- Page 9 2. Check the displayed waveforms and compare them with the following figure. Under Compensated Over Compensated Correctly Compensated 3. Use a nonmetallic flat-head screwdriver to adjust the low-frequency compensation adjustment hole on the probe until the waveform matches the “Compensated Correctly” waveform above. 5- SDS2000X Series Digital Oscilloscope...
-
Page 10: The Front Panel
14.WaveGen Control 19.Digital Inputs 3.Run/Stop 9.Digital Channel Control 15.Channel Vertical Control 20.Analog Inputs 4.Default 10.Math 16.WaveGen Output 21.Print 5.Clear Sweeps 11.Reference 17.Probe Compensation/ 22.Function Menu Softkeys 6.Universal Knob 12.Math/Ref Vertical Control Ground Terminal 23.Power On/Off SDS2000X Series Digital Oscilloscope -6... -
Page 11: The Rear Panel
This hole is designed to accommodate a Kensington style of lock (user-supplied). 7. AC Power Socket The standard power supply for the instrument is 100~240V, 50/60Hz or 100~120V, 400Hz. Please use the power cord provided with the instrument to connect it to AC power. 7- SDS2000X Series Digital Oscilloscope... -
Page 12: Front Panel Overview
Turn it clockwise or counterclockwise to reduce or increase the timebase. The displayed waveform will be expanded or compressed when the timebase changes. Press down the knob to enter into the Zoom mode. SDS2000X Series Digital Oscilloscope -8... - Page 13 In the screen shot below the time interval between two consecutive rising edges is set to satisfy the limit range ([--,--]). High Level Low Level Negative runt pulse In the figure below, the trigger signal are positive runt pulse. 9- SDS2000X Series Digital Oscilloscope...
- Page 14 In the figure below, the trigger condition is set to “Start”. In the figure below, the selected logic is “AND”, both Channel 1 and Channel 2 are set to “High.” SDS2000X Series Digital Oscilloscope -10...
- Page 15 Set the trigger level. Turn it clockwise or counterclockwise to make the level move up or down. In addition, the trigger level value is displayed in the upper right portion of the display. Press the knob to quickly reset the trigger level to the 50% of waveform. 11- SDS2000X Series Digital Oscilloscope...
- Page 16 When changing the offset, the waveform will move up and down and the offset message at the lower part of the screen will change accordingly. Press down the knob to quickly reset the offset to zero. SDS2000X Series Digital Oscilloscope -12...
- Page 17 ‘amplitude’ of the waveform will increase or decrease and the scale value displayed on the right side of the screen will change accordingly. In addition, the knob can be used to change a digital channel. 13- SDS2000X Series Digital Oscilloscope...
- Page 18 This button is a shortcut key for clear function. When measurement statics are being displayed, press this button to clear the count and begin a new statistical count. When the screen persistence feature is turned on, press this button to clear the persistence. SDS2000X Series Digital Oscilloscope -14...
- Page 19 (up to 80,000). used to select between submenus under the current menu. Press the knob to select the current submenu. In addition, it can be used to modify parameters and to input a file name. 15- SDS2000X Series Digital Oscilloscope...
- Page 20 Square, Ramp, Pulse, DC, Noise, Cardiac, Gaus Pulse, ExpRise, ExpFall and Arb are supported. The max output frequency is 25MHz (Sine Wave). In addition, the user can download and output four waveforms using Siglent’s EasyWave software. SDS2000X Series Digital Oscilloscope -16...
-
Page 21: User Interface
Delay parameter to decrease or increase. Press down the knob to automatically reset the parameter to zero as well as return the waveform’s horizontal center to the middle of the screen. 17- SDS2000X Series Digital Oscilloscope... - Page 22 Indicates the USB Device is connected. Indicates the LAN port is connected. Indicates the LAN port is not connected. 13. Menu Displays menus of the currently selected function module. Press any menu softkey to perform corresponding setting. SDS2000X Series Digital Oscilloscope -18...
-
Page 23: Using Security Lock
Provisions for a Kensington-style lock are provided on the rear panel of the SDS2000X (Lock is not included). To use, align the lock with the lock hole and insert, turn the key clockwise to lock the instrument and then remove the key from the lock. Security lock hole 19- SDS2000X Series Digital Oscilloscope... -
Page 24: Troubleshooting
(3) Check the trigger type: “Edge” trigger suits to general signal and “Video” trigger suits to video signal. The correct trigger type setting can be important in obtaining a stable display. (4) Change the setting of trigger holdoff. SDS2000X Series Digital Oscilloscope -20... - Page 25 (3) Make sure the USB disk being used is of flash type, the instrument does not support USB of hard disk type. (4) Make sure the system format of used USB disk is FAT32. (5) Restart the instrument and then insert the USB to verify operation. (6) If a problem persists, please contact Siglent. 21- SDS2000X Series Digital Oscilloscope...
