H1 - MECHANICAL MOUNTING AND ELECTRICAL SAFETY
To avoid any risk of electrical shock H1 can be only used with mounted side bracket. Agora disclaim any
responsibility in case of use that does not comply with these instructions.
H1 is delivered with mounting brackets and coupling plates.
Package includes:
20 x Hexa screws M3*5mm
1 x long bracket
1 x short racket
2 x Mounting plates
2 x Screwdriver
1: Long bracket mounting instructions:
1: insert the plates of the bracket in the reserved spaces on the side of the box
2: screw the 8 x
M3*5mm in the designated holes (white circles)
3: Complete by screwing
2 x
M3*5mm on the side of the bracket
Please read the assembly instructions below.
