Favero FULL-ARM 03 Instruction And Operations

ENGLISH
FULL-ARM 03
Art.830
PANEL 02
Art.835
TELE-FULL-ARM
Art.840
EXTERNAL RECEIVER
Art.841
EXTERNAL BUZZER
Art.842
FULL-ARM O3
Art. 830
TECHNICAL INFORMATION
Power supply: 12 Vdc or Vac (min. 10 Vdc, max. 16 Vdc). Fed onto the connector's two external poles
without the need to worry about polarity. Energy consumption: 0.2 Amp with the light bulbs turned off, plus
0.7 Amp for every light surface turned on.
Comes complete with a feed cable and clips for connection to an automobile battery and a connector for
possible use in fashioning a customized cable.
Warning: If the power supplied is 12 Vac, be certain that the transformer carries a certification of the
double isolation safety variety and that it has a 12 Vac 3A output. Make sure, too, that the electrical
system to which it is linked has a differential switch with a 30 mA threshold (circuit-breaker).
Inner fuses: 6.3A F on a lamp card, 1.6A T on a primary electronic card.
The following may be connected on the back: three repeater panels (PANEL O2) with DATA LINE outlets, an
external receiver for the remoter control device to the RECEPT. TELECOM. EXT. outlet, and an external
buzzer to the EXT. BUZZ. outlet.
OPERATIONS
This equipment incorporates a good number of use functions. These are grouped on the keyboard in four
sections having different colours:
COUNTER-THRUSTS
VARIOUS USE-FUNCTIONS purple keys
COUNTER-THRUSTS (red keys)
ON-OFF key. Turns on and off the counter-thrusts shown to the right on the display. -- MISE A ZERO
(Return to zero) keys (+) and (-). These increase, decrease and re-set at zero the countings. -- COMPT.
AUTOM. ÉPÉE key. In spade events and with the timer on, automatic increase of the counter-thrusts (on =
activated).
WEAPONS COMMAND (yellow keys)
FLEUR. ÉPÉE SABRE key. Selects the weapon being used.
programme desired within the range of the same weapon (whenever there is more than one). -- MODIF.
PROGR. key. Not used. -- RÉARM. key. For re-setting. -- RÉARM. AUTOM. (Automatic re-set) key.
Activates and deactivates the automatic re-set after a pre-determined time period. -- TEMPS RÉARM. sec.
key. If automatic re-set has been activated, this key establishes just how much time must pass before re-
setting occurs. It is possible to select time periods of 0, 2, 4, 6 and 120 seconds. A setting at 120 seconds
avoids the need to have the lights turned on at length when the machine is battery-powered. -- VOLUME
SON. key. Press down repeatedly in order to select one of the three sound levels.
VARIOUS USE-FUNCTIONS (purple keys)
PRIORITÉ MANUEL key. Press down repeatedly to assign or take away a precedence (or advantage). The
letter P will appear above the score of the fencer involved.
PRIORITÉ CASUEL key. Assigns precedence randomly. Turns off when pressed again. -- CART. JAUNE
key. Imposes and nullifies the "yellow card" penalty. Shown on the display by an empty rectangle situated
above the score. -- CART. ROUGE key. Imposes the "red card" penalty. Shown on the display for only
three seconds and by means of a full rectangle. One point is automatically assigned to the opponent. --
MATCHS COUNT key. Adds to the match-count total.
TÉLÉCOM. ACQUIS. key. Makes it possible to "tune in" the FULL-ARM 03 to any TELE-FULL-ARM remote
control device and only to that one. Press this key and within 5 seconds press the same button on the
remote control device (having been careful beforehand to point the device toward the receiver located on
the front of the machine). In the event the external receiver is also being used, this operation must be
followed by turning the apparatus off and then turning it on again.
MULTI-PURPOSE ELECTRONIC APPARATUS FOR FENCING
REPEATER PANEL
REMOTE CONTROL DEVICE
FOR USE WITH THE REMOTE CONTROL DEVICE
(SUPPLEMENTARY)
MULTI-PURPOSE APPARATUS FOR FENCING
red keys WEAPONS COMMAND yellow keys
TIMER
-- VERS. PROGR. key. Selects the
ELECTRONIC DESIGN
green keys
