BASIC MAINTENANCE INSTRUCTIONS
Basic Maintenance should be carried out after each game, failure to do so will void your
Manufactures Warranty. A full strip of the gun should be done when your marker is
subjected to adverse conditions.
Stage 1
Stage 2
Remove the cocking
Remove the main bolt
handle (part No. 0034) from
from Inferno, (Part No.0045)
the main body (Part No.1310).
should slide out esaily.
Stage 4
Stage 5
Using Inferno lube squirt a few
Place long bolt back into the
drops on the long bolt.
inferno marker. Make sure that
the holes are facing up and
transfer port downward.
NO ALKALINE OR SOAP CLEANERS ARE TO BE USED AS THIS
ATTACKS THE ALUMINIUM PARTS
WIPE CLEAN THE EXTERIOR WITH AN OILY RAG
OR MOISTENED SPONGE. DO NOT IMMERSE MARKERS IN WATER!
Extended warranty - 2 year Manufactures Warranty
2
YEAR
All Inferno markers now come with a 2 year warranty. The warranty covers markers
purchased from 1st January 2008 onwards.
WARRANTY
The warranty is subject to necessary maintenance of marker's as specified in the Inferno manual, supplied
with your marker.
Arrow Precision Limited, Unit 7, Elliott Industrial Park, Eastern Road, Aldershot, Hampshire, GU12 4TF
Tel:01252 408 550 Fax:01252 408 551 Email:sales@arrow-precision.com Web:www.arrow-precision.com
Stage 3
Squeegee the inferno with a
Powerball Bow Tie Squeegee
making sure it removes all dirt.
Stage 6
Push the cocking handle back
into the long bolt. The knurled
part should be facing up. It
should click into hammer.
Instruction manual
2008 Version
