Surface Mount Installation
Core Drill Installation Instructions
Finished grade
12"
1. Drill 2-1/4" diameter hole into mounting surface
at uplight installation location as per lighting
plan.
Do not exceed surface diameter, installation
relies on surface mount collar resting on surface
grade. Collar diameter is 2-1/4". Surface mount
flange is 2-3/4" diameter.
Pull secondary wiring from remote driver.
Screws on faceplate will
align with alignment
Screws on faceplate will
arrows on temporary
align with alignment
cover
arrows on temporary
cover
4. Align holes to final installation orientation.
Arrows on temporary cover point towards screw
location on faceplate for alignment purposes.
NOTE: Do not remove temporary cover until
installation of faceplate.
LINE
12V
Remote
Transformer
COM COM
6"
min.
Finished grade
7. Access remote wiring inside housing. Make
watertight connections using waterproof wire
connectors (By Others). Wire nuts must clear
opening. Insert fixture, wiring and connections
into housing. See wiring diagram.
Finished grade
8 3/4"
IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
B-K LIGHTING
2-3/4" O.D.
2-1/4" O.D.
2. Loop minimum of 6" of wiring inside housing to
Rebar or stake (by others)
Finished grade
5. Use a silicone based sealant (By Others) between
FIXTURE
Wire nuts must
clear opening
9. Make watertight connections using waterproof
Rebar or stake (by others)
Finished grade
MINI-MICRO™ RECESSED UPLIGHT
Finished grade
8 3/4"
allow for fixture service.
NOTE: Do not remove temporary cover!
Stability flange
Concrete
Pea gravel or sand
2 window
faceplate
shown
Optical opening on
faceplate will align with
alignment arrows on
temporary cover
fixture and mounting surface.
LINE
12V
Remote
Transformer
COM COM
wire connectors (By Others). Insert fixture and
low voltage wire into Power Pipe™.
Stability flange
LED - For use with 12VAC
Concrete
remote transformer or
Pea gravel or sand
transformers only. B-K Lighting cannot
Finished grade
guarantee performance with third party
manufacturers' transformers.
8 3/4"
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX 559.438.5900
www.bklighting.com • info@bklighting.com
3. Place housing into hole. Surface mount collar
should rest on finished surface grade.
NOTE: Do not remove temporary cover!
Rebar or stake (by others)
Finished grade
6. Remove temporary cover and pull out remote
wiring.
FIXTURE
10. Mount faceplate to collar using (2) #6-32
screws (provided) with a 5/64" Allen wrench.
Rebar or stake (by others)
magnetic
Finished grade
6"
min.
Finished grade
RELEASE DATE
12-13-16
Stability flange
Concrete
Pea gravel or sand
Stability flange
Concrete
Pea gravel or sand
Wire nuts must
Concrete
clear opening
REFERENCE NUMBER
INS000933.1
