- Page 1 IMAporter Reader Contactless card reader with MobileAccess function RSW.04 reader with NFC support RSW.04-B reader with NFC and Bluetooth LE support Installation guide Version: 1.4 Karel Kalivoda Date: 1. 3. 2019...
-
Page 2: Table Of Contents
IMAporter Reader with MobileAccess function – installation guide 1 Table of contents Table of contents ............................2 Product description ..........................3 Technical specification ..........................3 Reader characteristics ........................3 Configuration options ........................4 Reader connection – wiring scheme ....................5 Configuration, reconfiguration and getting into operation .............. -
Page 3: Product Description
• add-on ID management platform The solution is based on the RSW.04 intelligent reader allowing user identification using a mobile device equipped with NFC or Bluetooth Low Energy (Bluetooth LE or BLE) technologies. The reader supports identification media of ISO14443 standard (e.g.: MIFARE DESFire, MIFARE Classic, MIFARE Plus, PayPass etc.), communication with NFC devices in Peer-to-Peer, Reader / Writer and Card... -
Page 4: Configuration Options
IMAporter Reader with MobileAccess function – installation guide Power supply / max. consumption: 12 – 15 VDC / 200 mA IP Rating: IP 65 Housing: plastic (ABS) Color: black with exchangeable front sticker Temperature range: -25°C to +60°C (-13°F to 140°F) Wiring: 2x power, 2x communication, 1-3x indication, 2x tamper contact Cable:... -
Page 5: Reader Connection - Wiring Scheme
IMAporter Reader with MobileAccess function – installation guide Reader connection – wiring scheme Signal Color Function +12V power supply black power supply Data0 green Wiegand data Data1 white Wiegand data LEDG pink green LED LEDR brown red LED BEEPER blue beeper purple tamper contact... -
Page 6: Configuration, Reconfiguration And Getting Into Operation
(system ID / Porter key) or after FW upgrade. Factory reset deletes all configuration and data stored in the reader. Resetting IMAporter Reader (RSW.04 or RSW.04-B) 1. Power the reader OFF 2. Short black, pink, brown and blue wires (ground the signalization wires) 3. -
Page 7: Reader Configuration Using A Configuration Card
IMAporter Reader with MobileAccess function – installation guide Demo Configuration Cards: • Wiegand 26bit + RS232 • Wiegand 32bit + RS232 • Wiegand 56bit + RS232 Demo Access Cards: • MIFARE Classic 1k (UID reading) • MIFARE DESFire (File: 0; No: 65534; Key: 12345678901234567890123456789012) Mobile devices: •... - Page 8 IMAporter Reader with MobileAccess function – installation guide During configuration download, the reader shines green LED for about 3sec. After that it shortly blinks red LED and switches to normal operating state in which it behaves according to the settings of the master control unit.
-
Page 9: Setting Up Using Imaporter Reader Config
Setting up the reader identifiers is carried out using the IMAporter Reader Config for Android, which can be downloaded here: http://ima.cz/app/setup Note: Setting up using the IMAporter Reader Config app is not required, if the MobileAccess (NFC, nor BLE) function was not allowed in the configuration card. -
Page 10: Communication With Id System (Control Unit)
IMAporter Reader with MobileAccess function – installation guide The Key must not be disposed to third parties as it could result in lowering the system security level. System ID: Identifier used by the user identification app for distinguishing between individual systems. The IMAporter Mobile Key user identification app allows saving credential sets for multiple access systems used in different premises. -
Page 11: Imaporter Mobile Key Identification App
When running the app for the first time, a screen informing about compatible technologies will be displayed. For mobile access using the RSW.04 reader, it is necessary for the mobile device to support NFC; while for RSW.04-B readers, the mobile device can support either or both NFC and BLE. -
Page 12: Adding The Mobile Key Using Idcloud Platform
IMAporter Reader with MobileAccess function – installation guide Adding the Mobile Key using IDcloud platform IMAporter IDcloud is a web service designed for easy and secure remote key distribution. Because of IDcloud utilization, there is no need to manually rewrite identifiers and keys to user phones, and the keys can be comfortably managed through an intuitive web interface. - Page 13 IMAporter Reader with MobileAccess function – installation guide Launch an intuitive guide by clicking on the Mobile Key Creation Wizard. You only need to enter a person's name/title/description and email or telephone contact to send the activation code. Everything else is done automatically - the system generates a unique ID and sends the mobile key to the user via email or SMS.
- Page 14 IMAporter Reader with MobileAccess function – installation guide The new user will receive their mobile key via email, SMS or printed in the form of a QR code, depending on the chosen form of sending: Now the user needs to only download the IMAporter Mobile Key app then on the Mobile Keys Download screen, enter or scan the received activation code.
-
Page 15: Adding The Mobile Key Manually
IMAporter Reader with MobileAccess function – installation guide Adding the Mobile Key manually To input the Mobile Key manually using the in-app form, proceed according to the following instructions. On the Mobile Keys download screen tap the menu icon in the top right corner and select the Add manually item. -
Page 16: Testing User Identification
RSW.04-B only (reader with BLE): Navigate to My doors tab and tap the button to search for a BLE reader in range. RSW.04-B only (reader with BLE): Tap on the reader to view a configuration form and fill it in • MAC address - unique identifier of the reader •... - Page 17 Navigate to Settings tab and enable NFC identification. BLE identification does not have to be enabled unless you want to use automatic opening from notification bar or by lighting up the display. RSW.04-B only (reader with BLE): Navigate to the Available doors tab and click the available detected reader displaying with a predefined name.
- Page 18 IMAporter Reader with MobileAccess function – installation guide RSW.04-B only (reader with BLE): Communication window will pop up for a second and reader will beep and light green/red LED according to access rights settings in the connected control unit. 18/24...
-
Page 19: Support And Error Codes
IMAporter Reader with MobileAccess function – installation guide 6 Support and Error Codes IMAporter MobileKey identification app During testing of BLE or NFC communication, the app says Unknown System ID and reader does not react. You have a typo in the System ID field when entered to the IMAporter MobileKey app. Please check and rewrite if needed to match the record entered using the IMAporter Reader Config app. -
Page 20: Reader State Signaling - Error States
IMAporter Reader with MobileAccess function – installation guide The user ID is not authorized to enter - it is not configured in the connected control unit Reader state signaling – Error states When turned ON, the reader blinks red LED in 1sec interval The reader has either not yet been configured using the configuration card or it is missing the system settings that are to be set using the IMAporter Setup app. -
Page 21: Declaration Of Conformity
4-5:2006, EN 61000-4-6:2007, EN 60068-2-1, EN 60068-2-2, EN 60068-2-18, EN 60068-2-30, EN 60068-2-75, EN 60068-2-6 RSW.04 readers use low range wireless standard 13,56 MHz, work according to ISO/IEC 14443 protocol and are in conformity with the requirements of the related standards. -
Page 22: Certification
RSW.04 3/12/2013 s.r.o. issued on 24/10/2013 a certificate for the RSW.04 reader. It confirms the clearance of accordance with Art. 46 of Act No. 412/2005 Coll., identification class of Type 2 and environment on the Protection of Classified Information and Security Clearance. - Page 23 IMAporter Reader with MobileAccess function – installation guide 23/24...
-
Page 24: Delivery Parameters
IMAporter Reader with MobileAccess function – installation guide 8 Delivery parameters Type of reader: RSW.04 IMAporter Reader with NFC RSW.04-B IMAporter Reader with NFC and Bluetooth LE Reader settings: Wiegand interface: 26bit 32bit 56bit ...
