ITEM NO: I287-333
Thank you for purchasing this quality product. Be sure to check all packing material carefully for
small parts that may come loose inside the carton during shipment.
I287-333
HARDWARE LIST:
Description
No.
Bolt Ø1/4" x 3/4"
A
Lock Washer Ø1/4"
B
Flat Washer Ø1/4" x 3/4"
C
Allen Wrench 4mm
D
Wood Screw #8 x 3/4"
E
FUNCTIONALITY INSTRUCTION
BEFORE USING THIS PRODUCT PLEASE READ, UNDERSTAND, AND FOLLOW THESE INSTRUCTIONS.
Save these instructions for future reference.
Page 1/2
Open Display case
Quantity
Sketch
24 PCS
24 PCS
24 PCS
Left Side Assembly
FOR INDOOR USE ONLY
MADE IN VIETNAM
ASSEMBLY INSTRUCTIONS
R
TOOLS REQUIRED (NOT PROVIDED)
PHILLIPS SCREWDRIVER
COMPONENTS LIST:
No.
1
Left Side Assembly
2
Right Side Assembly
3
Top Shelf (a)
4
Second Shelf (b)
5
Third Shelf (c)
6
Fourth Shelf (d)
1 PC
7
Bottom Shelf (e)
1 PC
8
Metal Stretcher
Top shelf (a)
Second shelf (b)
Right Side Assembly
Third shelf (c)
Fourth shelf (d)
Bottom Shelf (e)
Leveler on legs
Description
Sketch
Adjust the leveler
when necessary
Quantity
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
2 PCS
08-10-2020
Advertisement
Table of Contents
Summary of Contents for aspenhome I287-333
- Page 1 ASSEMBLY INSTRUCTIONS ITEM NO: I287-333 Open Display case Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts that may come loose inside the carton during shipment. I287-333 TOOLS REQUIRED (NOT PROVIDED)
- Page 2 ASSEMBLY INSTRUCTIONS ITEM NO: I287-333 Open Display case STEP 1: Put the left/right side assembly backside down on a soft surface. STEP 2: Attach the top shelf (a), second shelf (b), third shelf (c), fourth shelf (d) and bottom shelf (e) to left/right side assembly by using 20 bolts(A), lock washers(B) and flat washers(C).
