SATELLITE MODEM
SCPC
USER MANUAL
SOFTWARE RELEASE 3.2
[UHP.SC32.EN]
JANUARY 2015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SCPC and is the answer not in the manual?

Questions and answers

Summary of Contents for UHP NETWORKS SCPC

  • Page 1 SATELLITE MODEM SCPC USER MANUAL SOFTWARE RELEASE 3.2 [UHP.SC32.EN] JANUARY 2015...

  • Page 2: Table Of Contents

    Configuring IP Address ......................11 2.1.1 Configuring IP Address using Telnet Access ................12 Site Setup ..........................12 Profiles ............................ 13 2.3.1 SCPC modem Profile ....................... 14 2.3.2 Receive and Transmit Configuration ..................15 2.3.3 Modulator Settings ......................... 15 2.3.4 TLC Settings ..........................
  • Page 3 7.4.1 Fault Identification ........................40 7.4.2 Fault Fixing ..........................40 7.4.3 Support Information ....................... 40 Example of SCPC – Fault Fixing ....................41 7.5.1 Monitoring Demodulator Status..................... 41 7.5.2 Monitoring Modulator Status....................42 ROUTER FIRMWARE ......................43 SW Memory Banks ........................43 Configuration of Memory Banks .....................
  • Page 4 UHP SCPC MODEM USER MANUAL, v3.2 Figure 18 Configuration of IP route ......................18 Figure 19 Configuration of additional static IP route .................. 18 Figure 20 Routing table of Station-1 ......................19 Figure 21 Routing table of Station-2 ......................19 Figure 22 1:1 redundant router connection diagram .................

  • Page 5: Acronyms And Abbreviations

    DVB-S2 frames 64800 bits long (including FEC). Require slightly lower C/N than short frames. MCPC Multiple channels per carrier. All TDM carriers generated by UHP can be treated as MCPC. Even if they are called SCPC. MODCOD Modulation and coding mode.
  • Page 6 UHP SCPC MODEM USER MANUAL, v3.2 Outdoor Unit – part of earth station installed outside. QPSK 4 Phase-shift keying (QPSK) is a digital modulation scheme that conveys data by changing, or modulating, the phase of a reference signal (the carrier wave).

  • Page 7: Introduction

    USER MANUAL, v3.2 INTRODUCTION This document provides general guidance on operation of UHP-X000 series satellite routers, in SCPC or MCPC modes. The document describes the system capabilities, specifications and operation rules. Additional information about specifications, installation and operation guidelines for specific router models can be found in the GENERAL DESCRIPTION AND INSTALLATION GUIDE for the specific router.

  • Page 8: Getting Started

    Ethernet cable with RJ-45 connectors or directly via a crossover Ethernet cable (not supplied). Required Information This manual describes how to configure a pair of SCPC modems interacting as SCPC duplex channel. Both modems should be based on universal UHP routers and in combination with respective RF systems and antennas. A satellite...

  • Page 9: Web-Interface

    Figure 2 Example SCPC channel structure A SCPC carrier of 2 MHz bandwidth (symbol rate 1667 KSps with roll-off=1.2) is used to transmit data from the Station-1 to the Station-2, while another SCPC carrier of 1 MHz bandwidth (symbol rate 834 KSps with roll-off = 1.2) is used to transmit data from the Station-2 to Stations-1.

  • Page 10: Figure 3 Uhp Web Interface

    ARNING PPLIED BUT SAVED SETTINGS WILL HAVE EFFECT UNTIL THE NEXT ROUTER REBOOT ONLY Configuration of SCPC Station consists of five steps (see also Figure 3): 1. Station parameters configuration – Site Setup; 2. Station profile configuration – Profile; 3. Routing configuration – IP routing;...

  • Page 11: Configuration

    UHP SCPC MODEM USER MANUAL, v3.2 2. CONFIGURATION A computer used for configuration of UHP router should be configured for the same network as the router. By default the router has 10.0.0.1XX IP-address (where XX are the last two digits of the router’s serial number) with 255.255.255.0 subnet mask.

  • Page 12: Configuring Ip Address Using Telnet Access

    Name of Station - this name will appear on the left side of the Status bar and in command line as a command prompt (e.g. Station 1#);  Geographical location of Station - not used for SCPC;  RF interface – this defines RF parameters of the Station.

  • Page 13: Profiles

    Profile is a pre-configured group of UHP settings that defines the mode of operation and the general RF configuration. This manual describes only one configuration supported by UHP operation mode: SCPC modem. UHP router may have multiple profiles with various modes of operations or/and different RF settings.

  • Page 14: Scpc Modem Profile

    “Autorun” until it would establish a communication; Mode UHP operation mode (SCPC modem); Timeout Specifies the time period before the router switches to the next profile marked as “Autorun” if current profile is unable to establish communication.

  • Page 15: Receive And Transmit Configuration

     Activation of Station’s modulator. 2.3.2 Receive and Transmit Configuration Transmit and Receive configuration should be entered into TDM/SCPC TX and TDM/SCPC RX forms respectively. Once respective form is configured it should be applied to take effect. Terminal-1 Terminal-2 Figure 11 Transmit and Receive Configuration 2.3.3...

  • Page 16: Tlc Settings

    Once respective form is configured it should be applied to take effect. Desired C/N receive level on the remote Station (Desired C/N on local hub/SCPC side) should be set using TX level control form. This level should ensure proper quality of receive for the defined MODCOD. It is recommended using C/N values defined in the UHP specifications plus some (0.4-0.9 dB) margin.

  • Page 17: Adaptive Modulation And Coding

    MODCOD scheme; • Activate ACM for the respective direction of the SCPC channel by the ACM enable check-box. Once respective form is configured it should be applied to take effect. With active ACM mode Stations using TLC exchange protocols to retrieve information about quality of reception on the remote end and dynamically adjust its transmission MODCOD ensuring maximal throughput with proper quality of reception (depends on the actual whether conditions on the remote end).

  • Page 18: Figure 18 Configuration Of Ip Route

    UHP SCPC MODEM USER MANUAL, v3.2 Terminal-1 Terminal-2 Route from Terminal-1 to Terminal 2 Route from Terminal-2 to Terminal 1 Figure 18 Configuration of IP route The Static route form allows adding static routes with the default gateway. Figure 19 Configuration of additional static IP route The following figures represent Routing tables of the Stations.

  • Page 19: Redundancy

    UHP SCPC MODEM USER MANUAL, v3.2 Figure 20 Routing table of Station-1 Figure 21 Routing table of Station-2 Entries in the routing table may have the following meaning: А – Router IP -address; –SVLAN outgoing route (IP map); – Static route;...

  • Page 20: Redundancy Configuration

    UHP SCPC MODEM USER MANUAL, v3.2 Every 4 seconds both routers exchange information about their status via UDP protocol. When the router gets switched on, its status is BACKUP. The router launches a 10 sec. timer and waits for messages about the second router’s status during this time.

  • Page 21: Figure 23 Assign Additional Ip Address On Main Router

    UHP SCPC MODEM USER MANUAL, v3.2 Go to Advanced –> IP routing in the Menu on commands. The routing table will be displayed on the Control panel. Choose Add IP address to assign the additional IP-address. Figure 23 Assign additional IP address on main...

  • Page 22: Redundancy Status Monitoring

    UHP SCPC MODEM USER MANUAL, v3.2 4. Configure the redundancy. Go to Advanced –> Network –> STLC/NMS/Red in the Command menu. Backup settings will be displayed on the Control panel (see Figure 25 and Figure 26). The following settings should be configured: ...

  • Page 23: Figure 28 Redundancy Status

    UHP SCPC MODEM USER MANUAL, v3.2 Figure 28 Redundancy status Select Overview in Menu of commands to see the current status of the routers. The information will be displayed on the Control panel (see Figure 28). © ROMANTIS 2015 www.uhp.net...

  • Page 24: Script-Based Configuration

    Assign a local oscillator (LO) to LNB and BUC respectively rf lo 10000000 13050000 Create a SCPC modem profile with number 2 and automated run profile 2 type auto scpc Configure the receive frequency and symbol rate respectively...
  • Page 25 10000000 13050000 profile 2 type au scpc profile 2 rx 11018170 834 profile 2 tx 14317373 1667 8 profile 2 tlc on 10 0 profile 2 acm on 19 1...

  • Page 26: Configuration Using Opt File

    UHP SCPC MODEM USER MANUAL, v3.2 4. CONFIGURATION USING OPT FILE UHP router configuration can be saved as a binary file. This feature allows using the saved file for the following:  Back up a device configuration;  Optimize configuration of a large number of UHP routers. Optimization is achieved by creating a standard configuration template.
  • Page 27 UHP SCPC MODEM USER MANUAL, v3.2 with configuration which is stored on TFTP-server. Click Save. The configuration will be loaded into the router RAM and the settings will be applied. SELECTED ARNING CONFIGURATION FROM THE MEMORY BANK WILL BE LOADED AS CURRENT...

  • Page 28: Pointing To Satellite

    UHP SCPC MODEM USER MANUAL, v3.2 5. POINTING TO SATELLITE Before pointing an antenna system to a satellite follow the procedure below: 1. Choose the antenna installation place:  To install the antenna choose a flat horizontal surface or vertical surface perpendicular to the ground;...

  • Page 29: Pointing With Use Of Web-Interface

    Pointing with Use of WEB-Interface Before pointing to the satellite the router’s demodulator should be properly configured. Go to Profiles –> [used profile name] –> TDM/SCPC RX (see Figure 31); Figure 31 Configuring demodulator settings Click Apply once the settings are specified.

  • Page 30: Cross Polarization Test

    UHP SCPC MODEM USER MANUAL, v3.2 going down again. Choose the maximum C/N level and fix the fittings responsible for elevation angle adjustment. 3. Polarization Adjustments; Release the fittings responsible for antenna feed system adjustment. Slowly turn the antenna clockwise and monitor the C/N value on the screen.

  • Page 31: Figure 35 Manual Start Of Crosspol Test

    UHP SCPC MODEM USER MANUAL, v3.2  Go to Profiles section in the Menu of command and press * in Run column to activate the CrossPol test profile. Once it is active the respective mode will be displayed in the Status bar (see Figure 35).

  • Page 32: Transmitter 1Db Compression Point Setting

    UHP SCPC MODEM USER MANUAL, v3.2 Transmitter 1dB Compression Point Setting This procedure is used to determine the Station transmission power level where the BUC enters compression mode and to determine the power margin calculated according to the measurements. Like in the previous section the measurements are performed using unmodulated (CW) carrier. It is necessary to increase the transmission power by changing TX Level setting by 1dB (Up/Down buttons of modulator control can be used).

  • Page 33: Communications On The Move (Cotm)

    COTM Station. UHP router and antenna controller exchange the following information:  Overall level on SCPC Rx interface (for controller);  Level of the locked TDM or SCPC carrier (for controller);  Current geographic location of the Station (for UHP);...

  • Page 34: Cotm With Use Of Snmp

    UHP SCPC MODEM USER MANUAL, v3.2 Command Parameters Description 0 or 1 Indicates if router is locked to the carrier (1) or not (0). Antenna send this in response to F command and repeat Functional periodically confirming that antenna is pointed to the satellite Functional –...

  • Page 35: Figure 39 Definition Of The Coverage

    UHP SCPC MODEM USER MANUAL, v3.2 While beam switching is active the router on its startup or profile activation verifies if its current position is within any of preconfigured coverages and selects the one with highest EIRP. The beam coverages can be created using built-in editor Advanced ->...

  • Page 36: Interaction With Mobile Antenna Controller

    UHP SCPC MODEM USER MANUAL, v3.2 dia- Beam diameter in degrees (10) or in miles (10m) or in kilometers (10k); eirp- EIRP value in range of 0-100. Interaction with Mobile Antenna Controller Configuration of the interface between UHP router and the mobile antenna controller is centralized in a special editor Advanced –>...

  • Page 37: Cotm Working Principles

    UHP SCPC MODEM USER MANUAL, v3.2 Figure 41 Configuration and permission using SNMP for COTM If parameter Access IP 1 is set to 255.255.255.255 value then UHP router is accessible by SNMP protocol from all network devices. When Beam Switching uses OpenAMIP protocol, UHP router sends to the mobile antenna controller the respective commands to point to the required satellite.

  • Page 38: Operation

    UHP SCPC MODEM USER MANUAL, v3.2 7. OPERATION Information on UHP router status is displayed in the different section of its WEB-interface:  Status bar;  Menu of commands;  Control panel. Status Bar Statistics The information on router operation is given by the following elements of the Status bar (see Figure 42):...

  • Page 39: Menu Of Commands Statistics

    UHP SCPC MODEM USER MANUAL, v3.2 Section 1 Section 2 Section 3 Section 4 Section 5 Figure 43 Control panel statistics The main screen shows the following settings: Refresh – manual screen update; – device serial number; – type of active software;...

  • Page 40: Fault Identification

    UHP SCPC MODEM USER MANUAL, v3.2 7.4.1 Fault Identification To identify the fault: 1. Assess the information about the ongoing router operation provided by the markers in the Statistics area; 2. Assess the information on the configured router operating modes displayed on the main screen and in the relevant sections of the Menu of commands marked by icon.

  • Page 41: Example Of Scpc - Fault Fixing

    Example of SCPC – Fault Fixing Figure 44 UHP demodulator statistics and configuration To monitor the status of the SCPC channel the following should be performed on the router:  Check the demodulator status – choose DEM1 in Statistics area;...

  • Page 42: Monitoring Modulator Status

    UHP SCPC MODEM USER MANUAL, v3.2 Figure 45 UHP demodulator statistics and configuration 7.5.2 Monitoring Modulator Status. Quality of transmission could be verified on the basis of UHP modulator statistics and configuration (see Figure 46). Figure 46 UHP Modulator statistics and configuration.

  • Page 43: Router Firmware

    UHP SCPC MODEM USER MANUAL, v3.2 8. ROUTER FIRMWARE SW Memory Banks UHP software (SW) is placed in non-volatile flash memory. The built-in flash memory can contain up to three different SW versions stored in so-called memory banks. The memory banks are numbered from 0 to 3. Memory bank zero contains the boot-loader supporting selection of SW to be used and the configuration profile at startup.

  • Page 44: Configuration Of Memory Banks

    UHP SCPC MODEM USER MANUAL, v3.2 Configuration of Memory Banks UHP has two configuration banks (current settings). Each bank contains a full router configuration with 8 profiles, routing and stations information. By default the configuration is loaded from Bank 0. The equipment allows changing the boot loader settings specifying the number of configuration memory bank.

  • Page 45: Sw Installation Applying Console Connection

    UHP SCPC MODEM USER MANUAL, v3.2 1. Follow Advanced -> System -> Flash / Boot (see Figure 47) in the Menu of commands; 2. Click “Select file” and select the file with the required SW; 3. Click “Load To RAM” to load the SW into the router RAM;...
