Page 1 ® multisonic infra ontrol Inhaling with ultrasonic Instructions for Use...
Page 2: Overview Of Inhalation Unit
Overview of inhalation unit Exhalation valve Plug-in mains supply unit MN 81200 (light blue) Inhalation valve (dark blue) Plug 12 V DC Mouthpiece (on supply unit and rechargeable battery pack) Nebuliser head Rechargeable battery pack Baffle plate (depending on design) Function display Sealing ring (green, yellow)
Page 3: Table Of Contents
Table of Contents Overview of inhalation unit Introduction and general information Starting the unit for the first time Hygiene: Cleaning, disinfection and sterilization Use of the rechargeable battery pack Trouble shooting Information on medicines Spare parts/consumables Optional accessories Service information and guarantee conditions Explanation of symbols Technical data and classification...
Page 4: Introduction And General Information
Dear Patient The multisonic® infraControl is a powerful ultra- • Universal usage sound inhalation unit for preventative and thera- • Optimal penetration of tissues peutic deep inhalation that reflects the latest sci- • High nebuliser performance and short inhalation entific findings in this area. times However, the unit has not been designed for life- •...
Page 5 The basic package comprises the following components: 1 hand unit 1 nebuliser head 1 mouthpiece 1 sealing ring 1 baffle plate 1 inhalation valve 1 exhalation valve 1 metering aid 1 plug-in power supply unit 1 carrying case 1 set of Instructions for Use...
Page 6 Points to note • If you interrupt the inhalation process please • The multisonic® infraControl can be used for switch off the unit by pressing the ON-/OFF Switch. the nebulisation of all inhalation solutions that are water-based, including suspensions and na- •...
Page 7 Principle of function Air outflow Air inflow Exhalation valve Aerosol exit Inhalation valve Air and particles Baffle plate Aerosol Medicine Ultrasound waves Ultrasonic generator (quartz)
Page 8 An example of periodic inhalation (mg) Average pulmonary deposition (NaCl 0.9%) Inhalation Pause in breathing Exhalation Breathing in slowly & deeply Hold breath Exhale deeply Yellow LED is lit Duration of inhalation (secs)
Page 9: Starting The Unit For The First Time
Using the multisonic® infraControl for the first time 230 VA Fig. 1 Fig. 2 Fig. 3 Pull the stopper out of the Plug the plug-in mains supply Remove the nebuliser head mains socket of the unit and unit into the mains socket out- from the hand unit and place plug in the 12V DC plug of the let (230V AC).
Page 10 Inhalation Fig. 1 Fig. 2 Fig. 3 Fill the medicine – dose and Ensure that the sealing ring Place the nebuliser head on the quantity as directed by your sits correctly and that the baf- hand unit and turn it in the di- physician –...
Page 11 Exhalation valve Inhalation valve Inhalation valve Exhalation valve Fig. 4 Fig. 5 Fig. 6 Fit the mouthpiece, the inha- Lift up the hand unit and press Bring the hand unit up to your lation valve (dark blue) and the the button “ON/OFF“. Two yel- mouth.
Page 12 Air outflow Exhalation valve Air inflow Exhalation filter Dome (optional) Inhalation filter Aerosol (optional) exit Inhalation valve • If you interrupt the inhalation Optional use of the filter process please switch off the unit by pressing the ON-/OFF A filter can optionally be fitted as an exhalation fil- Switch.
Page 13 Examples of various uses of the multisonic® infraControl Fig. 1 Fig. 2 Fig. 3 Inhalation via the mouthpiece Inhalation via a mask Inhalation whilst lying down...
Page 14 The multisonic® infraControl indicates that inhalation is com- plete through the flashing of the red LED “End/Off“ and then turns itself off automat- ically after a few seconds if this is not triggered by pressing the ON/OFF button. The unit can be re-filled with medicine after it has been cleaned and the inhalation pro- cess repeated.
Page 15: Sterilization
Cleaning and disinfection Please note the following laid out on the cloth and not The inhalation unit and acces- covered. Drying may be acce- sories must be cleaned before lerated through the use of being used for the first time, warm air from a hairdryer (at after each inhalation proce- the lowest power setting).
Page 16 sealing ring and filter holder It is recommended that users should be disinfected in a plas- in Germany use one of the dis- tic container that is suitable for infectants listed in the current use with disinfectants. They may DGHM* list. Preparations based be cleaned in a dishwasher or on compounds that release disinfected in a vaporizer.
Page 17 Disinfection in a vaporizer Fig. 1 Fig. 2 Fig. 3 Before using the vaporizer for the first time it is very important that you read the Instructions for Use. Remove the cover and the cen- Place the hand unit “infra- Now place the central section tral section of the vaporizer.
Page 18 Further hygiene measures In clinics: After sealing the socket with the stopper the hand unit can be disinfected / sterilized through immersion disinfec- tion, placing it in a chemical- thermal disinfector (60°C for Abb. 4 Abb. 5 10 minutes) or in a gas steri- Cover the central section and In the home: lizer.
Page 19 Hygiene Table Designation Cleaning Disinfection Sterilization Multisonic Rinsing: Dish- Wiping & Immer- Chemical- Steam in Auto- Formal- Plasma infraControl unit warm run- washer spray disin- sion in dis- thermal 60ºC vaporizer claving dehyde & consumables ning water fection infectant for 10 mins/ at 134ºC solution dishwasher...
Page 20: Use Of The Rechargeable Battery Pack
Use of the MN 81300 rechargeable battery pack The following instructions must the duration of charging. If the LED 1 LED 2 be followed for the use of the battery pack has only a very green yellow rechargeable battery pack to low charge then the charging ensure that inhalation can be cycle will commence with a...
Page 21 The battery pack must then be • Never use a new battery pack The initial charge is very impor- recharged up to a capacity of until it has been fully charged. tant for the performance of the > 20% (LED 3 lit up) before it A new battery pack must be battery pack.
Page 22: Trouble Shooting
Trouble shooting If the unit malfunctions then please check the • Has the medicine chamber been treated with following: grease or a detergent in error? If so, rinse it out thoroughly with water that is • Is the unit connected to a power supply (plug-in warm/hot (approx.
Page 23: Information On Medicines
Recommendation Only use medicines that your The inhalation unit has been • The unit is not designed for physician has prescribed or re- tested with various medicines, emergency life-saving meas- commended. including Atrovent®, Bero- ures. If you accidentally inhale medi- tec®, Berudual®, Bromhexin- Respiratory disorders that can cines that are not suitable for...
Page 24: Spare Parts/Consumables
Spare parts (consumables) The mouthpiece, nebuliser head, inhalation valve, exhalation valve, sealing ring, baffle plate and filter holder will need to be changed according to the number of inhalations per day and the degree of Nebuliser head Sealing ring set wear that results from cleaning and disinfection.
Page 25: Optional Accessories
Optional Accessories Mask for infants Gr.1-85805 Mask for children Oxygen insert 85771 Gr.2-85810 Mask for adults Cornet adapter 85772 Gr.3-85820 Filter 85715 Larynx mask Gr.0-85830 T-piece with exhalation valve 85776 Travel plug set 81220...
Page 26: Conditions
24 months from the date of purchase. signature of its representative. Only original acces- sories may be used with the unit. Otto Schill Medizintechnik will not assume any lia- bility if these conditions are not adhered to.
Page 27: Explanation Of Symbols
Explanation of symbols Symbol Meaning Direct voltage Alternating voltage IP XY Degree of protection against ingress of dust (X) and water (Y) Caution – observe documentation Type 8 usage component Central positive (connection DC 12 V) • Mark of conformity protected by law 0366 Do not use in humid environments Not to be worked on by unauthorized personnel...
Page 28: Technical Data And Classification
Technical Data – multisonic® infraControl Type MN 81100 Rechargeable battery pack MN 81300 Noise level: <15 dB (A) (noiseless) Input voltage: DC 12 V Nominal voltage: DC 12 V (plug-in power Output voltage: DC 12 V supply unit MN 81200) Ah capacity Nominal frequency: plug-in power supply...
Page 29 Otto Schill GmbH & Co. KG Medizintechnik Auwiesen 12 D-07330 Probstzella Fon +49 (0) 3 67 35 / 4 63 - 0 Fax +49 (0) 3 67 35 / 4 63 - 44 info@multisonic.de www.multisonic.de...
