8
if you are leaving the work area even for a short period of time switch gun off and allow to cool.
8
do not use the soldering gun for any purpose other than that for which it has been designed.
8
do not allow untrained persons to operate the soldering gun.
8
do not touch the workpiece as it will be very hot. Allow to cool.
8
do not operate the soldering gun if damaged.
8
do not hold the workpiece by hand.
8
do not allow children to operate the soldering gun.
2. introduction
Pistol type, instant heat soldering gun with trigger control and illumination. Supplied with 1.5mtr cable and 230V/13Amp plug fitted with 3
amp fuse. supplied with a 10g coil of general purpose solder and a spare tip.
3. sPeciFication
model no: .................................................................. sd200
replacement tips:: ..................................... (card of 2) sd02
Power rating: ...............................................................100W
4. oPeration
note: The 100 Watt soldering gun is primarily intended for electrical and electronic use. Its main advantage is the ability to heat up
within 20 seconds of pressing the trigger. the tip temperature will reach 300
that may be damaged if excessively heated.
dutY cYcle. The gun has a duty cycle of 12 seconds continuous soldering which should be followed by a 48 second rest. If the trigger
4.1.
is held for less than 12 seconds the necessary rest period needed will be correspondingly less.
‰
Warning! do not try to lock the trigger by any means as this will overheat the tip and the transformer causing permanent damage and
will invalidate your guarantee.
PreParing the gun. Prepare the gun by 'tinning' the tip with a thin layer of solder. If any difficulty is experienced getting the solder to
4.2.
take to the tip use a proprietary tip tinner/cleaner.
holding/PreParing the WorK. Ensure that the items to be joined are clean and securely held together. Where possible a good
4.3.
joint will be more easily obtained if the items to be joined are tinned separately first.
soldering. Press and hold the trigger for approximately 20 seconds to get the tip to full temperature. Bring the tip of the gun and the
4.4.
solder to the joint simultaneously. leave the iron on the joint just long enough to melt the solder so that it flows onto the two parts to be
joined. Remove the gun and release the trigger. Leave the joint to cool. When the gun is not in use, but still hot, ensure that when it is put
down the tip is not touching, or close to, any material that will melt or is inflammable.
4.5.
changing tiPs. disconnect the gun from the mains and wait until the gun is completely cold. loosen the two screws holding the tip.
remove the tip and insert the new one. tighten the screws. if the old tip is difficult to remove, grip it with a pair of pliers and pull it out. do
not use pliers to insert the new tip as the plating may be damaged.
5. Maintenance
8
do not allow solder to accumulate where the tip enters the gun as this may make the tip difficult to remove.
8
do not get solder deposits on the tip retaining screws as this may prevent a screwdriver fitting into the cross head.
Periodically, use a proprietary tip cleaner/tinner to keep the gun clean an correctly tinned.
5.1.
5.2.
spare tips for gun: - model no. sd02 (card of two) .
environMent Protection
recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
note: it is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
important: no liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
sealey group, Kempson Way, suffolk Business Park, Bury st edmunds, suffolk. iP32 7ar
01284 757500
© Jack sealey limited
Parts support is available for this product. Please log on to
www.sealey.co.uk, email sales@sealey.co.uk or telephone 01284 757500
01284 703534
Original Language Version
o
c so care must be taken with delicate electronic components
sales@sealey.co.uk
www.sealey.co.uk
Issue 4 (H, F) 05/02/18
sD200
