Summary of Contents for enervent Freeway WEB
- Page 1 Freeway WEB Bus adapter Installation and operating manual Before installing and operating this unit, please read this manual thorougly, and retain it for future reference. FREEW A Y Enervent Freeway WEB www.enervent.fi...
- Page 2 NAMING THE SYSTEM UPDATING THE FREEWAY SOFTWARE WIRING DIAGRAM NOTE! The Freeway Ethernet Bus adapter only works with Enervent® ventilation units with EDA control system. The venti- lation unit must be equipped with a mother board version 210 or newer.
- Page 3 Connect one end of the network cable to the LAN 1 gate on the Freeway router and the other end to a computer. Connect to Internet on the computer and go to the Freeway site 192.168.69.1. (Requirements for the Internet browser; Internet Explorer vers. 6 or newer / Mozilla FireFox vers. 2 or newer). Enervent® Freeway Ethernet EN 2011_1...
- Page 4 Enervent Freeway user interface STARTING UP THE WIRELESS NETWORK (WLAN) Begin by choosing the Configuration tab on the Freeway user interface. Next choose Wireless network configura- tion, activate Wireless access enabled and feed the parameters: SSID is the name used to identify the wireless network (default is EDA Freeway) The Channel needs to be changed only if another wireless network uses the same channel WPA-PSKey is the password for the wireless network.
- Page 5 192.168.x.x or 10.x.x.x indicate that Freeway is connected to the buildings own network and can be reached only on the internal network, not on the Internet. (Freeway can be reached over the Internet by configurating the router). Enervent® Freeway Ethernet EN 2011_1...
- Page 6 LINKING FREEWAY TO A MONITORING SYSTEM THROUGH MODBUS/TCP The Enervent ventilation unit can be added as a part of a monitoring system using Modbus/TCP communication protocol. The Freeway adapter acts as a Modbus/TCP server and the data from the ventilation unit connected to the Freeway can be read of Slave id 1.
- Page 7 SETTING THE ALARM E-MAIL ADDRESS The alarms from the Enervent ventilation unit can automatically be sent to an e-mail address. To activate the function click Other settings on the Configuration tab. Fill out the complete e-mail address for the alarm messages in the field Recipent for alarm messages.
