TYPE A 142-4903-0 Assembly

ELEMENT STORAGE TOWERS
Model No. 142-4903-0, 142-4904-8, 142-4905-6
Follow these steps in order to configure your storage drawers:
1 ) Remove the top drawer from the unit in order to gain access underneath the lid.
2) Remove the lid by pressing the release buttons on each corner, while lifting off the lid.
3) Align the frame of 142-4903-0 onto the existing frame and press down on all four
corners until it clicks.
4) Replace the drawer and store the extra lid for future use if required.
+ = + =
142-4903-0 142-4903-0 142-4903-0
142-4904-8
WARNING!
To help prevent tip-over:
• Place heaviest items in the bottom drawers.
• Do not set heavy objects on top of this product.
• Never allow children to climb or hang on drawers.
• Product can be used with or without castors.
• Castors should be used on flat surfaces.

WEIGHT LIMITS

These units have been designed to
support the maximum loads shown.
Exceeding these load limits could
cause sagging, instability, product
collapse, and/or serious injury.

HEIGHT LIMIT

142-4903-0 142-4904-8 142-4905-6
Do not stack above 30" (76.2 cm)
*10 lb (4.5 kg) *24 lb (10.8 kg) per drawer *24 lb (10.8 kg) per drawer
*72 lb (32.6 kg) overall *120 lb (54.4 kg) overall
high to prevent tip-over.
*Evenly distributed.
Made in Canada with Domestic and Imported Materials
Trileaf Distribution Trifeuil
Toronto, Canada M4S 2B8
1
Model No. 142-4903-0, 142-4904-8, 142-4905-6 | Toll free 1-844-586-4659
IN65141
