  • Page 1 IDS701 Weighing Indicator User manual...
  • Page 2 IDS701 User Manual safety instruction For safety operation pls. follow the safety instruction. WARNING set. Calibrate, inspect and fix the the weighing indicator is prohibited by Non professional staff WARNING Pls. make sure the weighing display well earthing WARNING The indicator is electrostatic sensitive device, pls.

  • Page 3: Table Of Contents

    IDS701 User Manual LIST 1. Summary--------------------------------------------------------------------------3 1.1 Main function--------------------------------------------------------------------3 1.2 Optional function----------------------------------------------------------------3 ------------------------------------------------------------3 Technical parameter 1.4 Outline and installation drawing---------------------------------------------4 1.5 Battery using---------------------------------------------------------------------4 2. Installation------------------------------------------------------------------------5 2.1 Connection between indicator and load cell-----------------------------6 2.2 Connection of interface-------------------------------------------------------6 3. Basic operation-----------------------------------------------------------------6 ----------------------------------------------------6 Display and key instruction 3.2 Power on------------------------------------------------------------------------8...
  • Page 4 IDS701 User Manual 1. Summary IDS701 is specially designed for platform scale with friendly interface, simple operation, steady feature. The Basic function includes Weigh, Peak hold, Print. Communicate, Options are accumulate, Count and animal weighing. 1.1 Main function 》basic weighing function: zero tare retare 》peak hold...
  • Page 5 IDS701 User Manual 》Ambient temperature： -10～40℃ 》 ： -20～+60℃ Storage temperature 》 optional power： 6V/4Ah rechargeable battery； 9VDC adapter 1.4 Outline and installation picture 1.5 Battery 1. when you use the internal battery first time，you should charge the battery 10-12 hours, to prevent low voltage resulted from self leakage of battery.

  • Page 6: Installation

    2. Installation and Calibration 2.1 connection indicator with loadcell IDS701 can connect four pcs 350Ωload cell at most, both four and six wire load cell are ok. To make it simple, we use quick disconnect Or standard plug. As belows Quick disconnect connection 2.2 Connection of interface...

  • Page 7: Basic Operation

    IDS701 User Manual 3. Basic operation 3.1 Key and display IDS701 Weighing indicator display instruction LED display instruction Weighing data display Total accumulating Page 6 of 25...
  • Page 8 IDS701 User Manual Hold Hold weighing data Tare Display tare weight Display net weight Gross Display gross weight Display data keep still zero, indicating zero weight Battery Using battery Over setting weight Within setting weight Below setting weight 。 Decimal point Key’s function...

  • Page 9: Power

    IDS701 User Manual 1.At Gross mode, tare the loaded weight TARE 2.At Net mode, display gross weight after deduct tare TOTAL Work together with perform accumulating operation 1.Press it for 2 seconds to power on or power off ON/OFF 2.Work together with “SET” to enter calibration and function setting.

  • Page 10: Print Function

    IDS701 User Manual At Zero mode, load weight till stable, Press go to accumulating Mode,” total” light on, display” n001”, and then display loaded weight; unload weight , back to zero, load weight again till stable. Press display”n002” Then display the loaded weight. Repeat it maximum 999 times.

  • Page 11: Hold Function

    IDS701 User Manual Note： print the gross weight when at tare mode , if the net weight is zero. Can not print. 3.7 Hold function There are two different hold function. Peak hold function and data Hold function. And the setting is different accordingly.

  • Page 12: Parameter Setting

    IDS701 User Manual 4. Calibration and parameter setting 4.1 Enter setting There have two methods to enter the setting menu: 1. when the “span” is not pressed down, Press Press still and then press enter C08-C39 setting. 2. Take out the sealing screw on the back of indicator, then press down the “span”...
  • Page 13 IDS701 User Manual 4.2. Step of calibration operation: According to the second method which can enter setting menu, C01-C39 step display Remark Method of operation [C01 After you enter to calibration mode, it display [C01 press Weight unit option：1=kg 2=lb...
  • Page 14 IDS701 User Manual [0000.00] light is on Ensure zero calibration, countdown. Till show[0.00](example decimal point)。 press [C06 Loading calibration press [C06 option: 0=Non-load calibration [C06 1= load calibration press Basic on max capacity setting, press [SPAN add suitable weight on scale.
  • Page 15 IDS701 User Manual parameters setting finish, please do not set default parameters often, avoid the original setting parameters lost. 4.3 Application function parameters setting chart Setting Function parameters setting and instruction Item Options: 0 = close warning tone warning warning...
  • Page 16 IDS701 User Manual Kg/lb C12=0 kg/lb convert is ok conversion Kg/lb converstion C12=1 kg/lb convert is unworkable Upper/lower You can set it within the max. limit alarm Upper limit alarm capacity limit value Lower limit alarm value Inner Code At setting function mode, after...
  • Page 17 IDS701 User Manual Baud rate 0=1200/1=2400/2=4800/3=9600 option：0= close manually zero setting 1=± 1% max capacity Manually zero 2=± 2% max capacity range Zero range 4=± 4% max capacity option：0= no initial zero Initical zero range 1=± 1% max capacity 5=± 5% max capacity 10=±...
  • Page 18 IDS701 User Manual range Overload range 01d～99d remark： d is the setting graduation (division) Option：0=-9d Negative 10=10% max. capacity display Negative display 20=20% max. capacity option：0= quick 1= medium Standstill time 2= slow Standstill option：1=1d setting 2=2d 5=5d Standstill range...

  • Page 19: Output Data Format

    IDS701 User Manual option：0=close noise filter Noise filter 1=1 digital filter strength 2=2 digital filter strength 3=3 digital filter strength C30=0 yy.mm.dd Print time and date C30=1 mm.dd.yy C30=2 dd.mm.yy C30=3 yy.mm.dd 5.Output data format 5.1Computer continuous sending format Data...
  • Page 20 IDS701 User Manual 5.2 Big display continuous sending format Output continuous format State A Bits0,1,2 Decimal point position XXXXXX0 XXXXXXX XXXXX．X XXXX．XX XXX．XXX Bits3,4 Division State B BitsS function Bits0 gross=0， net=1 Bits1 symbol：positive =0，negative =1 Bits2 overload（or lower zero）=1...
  • Page 21 IDS701 User Manual Bits6 Constant 0 State C Bit2 Bit1 Bit0 unit Kg or lb Bit 3 printing=1 Extend Bit 4 display=1 Bit 5 Constant 1 Bit 6 Constant 0 5.3 Serial interface reception command： RS232COM serial interface can receive simple ASCII command.

  • Page 22: Maintenance

    IDS701 User Manual 5.5 Print the accumulated output format 004 （NO.） Date: XX.XX.XX (year. month. date) Time: XX.XX.XX (hour. minute. Second) Total: 003 (accumulate times，example for 3 times is 003) 2.88kg （accumulate weight） Total.W: 6. Maintenance 6.1 Regular Error and maintain method...
  • Page 23 IDS701 User Manual input added weight or input weight exceed max capacity. during calibration, the Added weight at least added weights 10%of Max. capacity, ERR2 enough Recommend the weights 60-80% Max. capacity during calibration, 1..Check connection is input single correct or not.
  • Page 24 IDS701 User Manual 6.3 Restore default parameters Enter setting menu, C07= 1,press then press exit saving setting, all parameters will be back to default setting. Note：Pls. do not restore default parameter easily if you are not professional and have not scale calibration.
  • Page 25 IDS701 User Manual Lower limit warning 000000 Inner code display Date Time Serial interface data output methord Serial interface Baud rate 3=9600 Manual zero setting Initical zero setting Automatic zero tracking range Automatic zero tracking time Verload range Negative display range...
  • Page 26 IDS701 User Manual 6.4 Packing list Packing list Material Sepcification unit Quanity name Weighing IDS701 series indicator Packing bag Accessories GB/DC9V US/DC9V UK/DC/9V Power supply EU/DC9V AU/DC9V others User’s manual quick connecter RS232 3 core Load cell core quick connecter joint Φ0.75mm...
