  • Page 1 User Manual Delvotest® Fast Go Max Alexander Fleminglaan 1 2613 AX Delft, The Netherlands...

  • Page 2: Table Of Contents

    Contents Introduction ..................2 The Use of User Manual ................... 3 Please Be Well-informed before Using the Product ..........4 Product Description ................8 Characteristics of Product ..................8 Product Components and Installation Methods ............ 9 2.1. Product Components ....................... 9 2.2.

  • Page 3: Introduction

    Always have this user manual at hand in case of need. (Effective version: 1.0.10 build 20180112) Copyright© all rights reserved. ▶ Delvotest® Fast Go Max is a trademark of DSM. ▶ - 2 -...

  • Page 4: The Use Of User Manual

    1. The Use of User Manual Labels and symbols shown below are used throughout the user manual. Label Description To indicate the direct current (DC). CE mark – To indicate that this product is appropriate for the standard of EU. To indicate instruction manual.

  • Page 5: Please Be Well-Informed Before Using The Product

    2. Please Be Well-informed before Using the Product Precautions on Installation and Storage CAUTION: Please read this user manual carefully and follow instructions for installation. (1) Appoint an administrator and let the administrator install and run this system. An administrator should be medical professional, researcher or skilled operator with responsibilities.
  • Page 6 You can buy supplies like the calibrator and test devices from your supplier. Supplies should be tested for adaptability with the system before it is actually used for the test. Information about applicable supplies is available by contacting DSM. - 5 -...
  • Page 7 ② To prevent electric shock, check if the power supply is connected to the ground. ③ Use supplies only from DSM to prevent product damage. ④ Be careful not to block the air passage on the back of the reader.
  • Page 8 ③ We are not responsible for the damage occurred by not using appointed standardized parts or using other software, which is not provided in the product package. ④ Specifications of this product can be changed due to company’s action for improving convenience and product performance.

  • Page 9: Product Description

    Product Description 1. Characteristics of Product Delvotest® Fast Go Max , gives you quantitative assessment by capturing and analyzing images of lateral flow immunochromatography. When the Rapid Diagnostic Test (RDT) device is inserted into the tray, an internal camera captures and saves the image, and data is automatically collected to be converted to a graphical analysis.

  • Page 10: Product Components And Installation Methods

    Product and parts composition of ▷ AC/DC Adapter (12V, 5A output) ▷ Power Cable ▷ Touch Pen ▷ Calibrator: for QC purpose only ▷ User manual ※ If you have any questions or missing components, please contact DSM customer services - 9 -...

  • Page 11: Installation Methods

    The power button is located on the top panel of the Delvotest® Fast Go Max. After approximately one second of pressing and holding the power button, the DSM log o appears and begins the program. Although it is advisable to use the power button on the program to exit the reader, if the reader has a problem, push and hold the power bu tton for more than 4 seconds to force the reader to power down.
  • Page 12 ▶ Front LED Bar Front panel LED bar color indicates reader status. During operation, the color changes to a different color. Depending on the color, the status is as follows : Front LED Bar [Figure 2.3] Front LED Bar LED color Indication No light No power connection.

  • Page 13: Running Delvotest® Fast Go Max

    3. Running Delvotest® Fast Go Max 3.1. Instrument Registration [Figure 3.1] Instrument Registration Page ✓ Instrument Registration screen will be displayed when the analyzer is first booted. It will not be displayed after registered. ✓ Serial Number, Name, and Country are required, and you do not need to enter anything else.

  • Page 14: Supervisor Registration

    3.2. Supervisor Registration [Figure 3.2] Supervisor Registration Page ✓ Supervisor Registration is displayed at the first time after analyzer registered. It is not displayed after Supervisor registered. ✓ ID, Password and Confirm(PW) are mandatory fields. ✓ If Supervisor Registration succeeds, it will go to Log in screen. - 13 -...

  • Page 15: Log In

    3.3. Log In [Figure 3.3] Log in Page ✓ Enter the ID and PW (Password) to log in and click the Log in button to log in with that ID and go to the Main screen. ✓ If the ID is not registered or the Password is incorrect, an error message is displayed.

  • Page 16: Main Menu

    program stops and the analyzer will be halted. 3.4. Main Menu [Figure 3.5] Main Menu Menu Description Test Mode Measurement mode Test Reports Manage test results (Review, Export, Backup) Manager Manage Operators, Samples, and Test Files (Add, Remove, Modify) Instr. Check Run the Instrument Check of the analyzer and result - 15 -...

  • Page 17: Test Mode

    3.5. Test Mode [Figure 3.6] Test Mode Page ✓ Enter Sample ID, Sample Name, and then tap the prepared barcode to automatically enter the corresponding Kit, Lot Number, and CutOff values. ✓ By clicking the Button, you can search and input the sample ID already registered in the Sample list.
  • Page 18 ✓ If the test file corresponding to the input barcode has not been imported, you cannot proceed with the test. ✓ Click the button to start the measurement. When the measurement is completed, the screen will move to the result screen as shown in the image below.
  • Page 19 [Figure 3.10] Export E-Mail ✓ By clicking the Button, the Export as PDF screen will be displayed as shown below. Enter the File Name, and click the button, then a PDF file will be saved in the ResultPDF folder of the USB memory. [Figure 3.11] Export as PDF ✓...

  • Page 20: Test Results

    3.6. Test Results [Figure 3.12] Test Report Page ✓ You can search and manage the test results in Test Report screen. ✓ When you go to the Test Report screen, all test names in the Test folder are added to the Kit combo box. ✓...
  • Page 21 select the date to search. Select the date search method in the combo box. Supported types are All, Yearly, Monthly, Daily and so on. When the Type is changed, the Date field text automatically changes according to the Type. Note that even if you change the date with the calendar button, the Date field text will be displayed according to the format selected in Type.
  • Page 22 [Figure 3.14] Result Review Page - Export ✓ The selected results are exported to a CSV (Excel), File (Backup), PDF to USB. [Figure 3.15] Export Results - Delete ✓ Deletes the selected results permanently from the analyzer. - 21 -...

  • Page 23: Manager

    3.7. Manager You can manage Operators (Users), Samples, Test Files from Manager screen. [Figure 3.16] Manager Select Page A. Operator [Figure 3.17] Operator Manager Page ✓ New Register a new Operator. ID, Password, and Confirm (PW) are required fields. Authority can be selected between Supervisor and Operator. - 22 -...
  • Page 24 [Figure 3.18] Operator Registration Page ✓ Modify You can modify the password and information of the selected operator from the list. ID cannot be changed. [Figure 3.19] Operator Modification Page Delete ✓ You can delete the selected operator from the list. - 23 -...
  • Page 25 B. Sample [Figure 3.20] Sample Manager Page ✓ New Register a Sample. ID is required and you do not need to enter anything else. Gender can select Female and Male. [Figure 3.21] Sample Registration Page ✓ Modify You can modify the information of the selected sample from the list. ID cannot be changed.
  • Page 26 [Figure 3.22] Sample Modification Page ✓ Delete You can delete the selected sample from the list. Test Files You can view and manage the information in the Test file. [Figure 3.23] Test File Manager Page ✓ Test File Viewer Select a test file in the Instrument list and click the View button to display the information of the selected test file.
  • Page 27 [Figure 3.24] Select Test File [Figure 3.25] Test File Viewer ✓ Import Select test files in the USB list to import into the analyzer. When you click the button, the selected test files are imported from the USB storage into the analyzer.
  • Page 28 ✓ Remove If you click the Remove Test button after selecting the test files in the Instrument list, the selected Test files are deleted permanently from the analyzer. - 27 -...

  • Page 29: Instrument Check

    3.8. Instrument Check Check the status of the reader. [Figure 3.26] Instrument Check Page ✓ Check Insert the Reference cassette and click the Run button to start the Instrument Check. When the check is completed, it moves to the result page, where the Pass image is displayed when there is no problem in the analyzer, or the Fail image is displayed otherwise.
  • Page 30 [Figure 3.28] Instrument Check Result (Fail) ✓ Log & Review In the Instrument Check screen, select the item you want to review and click the View button. The check result is displayed as shown below. [Figure 3.29] Instrument Check Result Export ✓...

  • Page 31: Thermal Printer

    3.9. Thermal Printer Test results can be printed using the built-in thermal printer. A roll of paper is included as one of the components of the product. If you have used all the paper, you need to replace it with a new one, follow the procedures below. The thermal printer is located on the back of the analyzer.
  • Page 32 Pull the end of the print paper out of the case by inserting it into the slot of the case from inside so that the print paper is easily released. Press firmly the case of the thermal printer to close it. - 31 -...

  • Page 33: Product Specification And After-Sales Service

    4. Product Specification and After-sales Service Product Specification 4.1. Parameter Description / Value Model name Delvotest® Fast Go Max Operating System Embedded Linux Display 10″ Color LCD (Resolution 800 x 480) I/O Interface 4 x USB 2.0 / 1 x RJ-45 LAN Connector Control Touch Screen Supported Accessories...

  • Page 34: Troubleshooting And Maintenance

    On any accident that is occurred due to unapproved person’s illegal re-formation or fixation of reader, DSM is not responsible for that accident. If you have any problem regarding the reader, please make sure to read the following information and contact the headquarters, branches or local agency.
