Maximum 065-3111-4 Instruction Manual

600 Lumens
Rechargeable Tactical Flashlight
model no. 065-3111-4
IMPORTANT:
Please read this manual carefully before
using this flashlight and save it for future
reference.
3
model no. 065-3111-4 | contact us 1.888.670.6682
Battery Replacement
1 x 14500 USB battery can be replaced by Maximum brand battery SKU 065-3116
(compatible with 1 x CR123A or 1 x AA alkaline battery)
Red light: Charging
Blue light: Fully charged
Charging time: 3 h 30 min
(Fully charged by connecting
USB cable to 5 V / 1 A charger)
MODE SWITCH
Fully click to turn on the memory mode
In 'ON' position, tap lightly for mode switching
WARNING!
This flashlight generates a lot of heat when in use.
Do not place the activated flashlight near flammable materials, fire or extreme heat.
Do not set the activated flashlight lens side down, avoid any objects blocking front of lens when activated.
Do not leave activated flashlight unattended.
Do not touch bezel or front side of an activated flashlight with bare hands or any part of the body.
成品尺寸：46.6mm × 23.3mm
展开尺寸：140mm × 140mm
印刷说明：80克双胶纸双面印刷
颜色： PANTONE 2945 C+K
INSTRUCTION
MANUAL
Flashing
Low High
Click
Medium
2
model no. 065-3111-4 | contact us 1.888.670.6682
Technical Specifications
ANSI/PLATO-FL1 High
Light Output 600 lm
Run Time 45 min
Beam Distance 167 m
Impact Resistance 1 m
Waterproof IPX-7, 1 m
Weight: 88 g without battery
Weight And Length: 125 mm
Head diameter: 30 mm
Dimensions
Body diameter: 23 mm
Light source: OSRAM LED
Body Material
Black Anodized
Includes 3.6 V / 2.7 Wh 14500 rechargeable lithium-ion battery, Micro USB Cable
FEATURES
1
OSRAM LED, max output up to 600 lumens
2
Slight-tap mode-switching function with mode memory
Compatible with the following batteries: 1 x 14500 rechargeable lithium
3
battery (included) or 1 x CR123A battery or 1 x alkaline AA battery
4
MAINTENANCE
If flashlight comes in contact with salt water or corrosive chemicals,
1
please rinse immediately with clean water and dry.
Please use high quality batteries. Remove batteries when not being
2
used for long periods, and then store in a cool dry place.
LIFETIME WARRANTY
This MAXIMUM product carries a lifetime warranty against defects in
workmanship and materials. This product is not guaranteed against
wear and tear or breakage due to misuse and/or abuse. At its discretion,
Maximum Canada will repair or replace any defective product parts at no
charge when returned by the original purchaser with proof of purchase.
If this product is discontinued or no longer available for sale, Maximum
Canada, as its sole discretion, will provide a comparable substitute item.
MADE IN CHINA
IMPORTED BY MAXIMUM CANADA
TORONTO, CANADA M4S 2B8
Medium Low Flashing
215 lm 30 lm 600 lm
1 h 20 min 6 h
