BMC PS2000EL+ Programming Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
V1.31
DPRTLP.21.05

Advertisement

loading
Need help?

Need help?

Do you have a question about the PS2000EL+ and is the answer not in the manual?

Questions and answers

Related Manuals for BMC PS2000EL+

Summary of Contents for BMC PS2000EL+

  • Page 1 V1.31 DPRTLP.21.05...

  • Page 2: Table Of Contents

    Table of Contents Page I. B A S I C O P E R A T I O N 1. P2 MODE 2. P1 MODE 3. MENU SELLECTION KEY 4. LCD OPERATOR DISPLAY 5. EXAMPLE OF SETTING II. P R O G R A M M I N G ' P 2 ' P O S I T I O N 1.
  • Page 3 (39)Flag No.39 (USER'S CHOICE OPERATION FLAGS) DPRTLP.21.05...
  • Page 4 Table of Contents Page 2. OPTION FLAG PROGRAMMING (40)Flag No.40 (Not used) (41)Flag No.41 (02 BAR CODE TYPE FLAG) (42)Flag No.42 (REPORT FLAGS) (43)-(48) Flag No.43 – Flag No.48 (Not used) (49)Flag No.49 (SCALE FLAGS) 3. CHANGING KEY LAYOUT *KEY POSITION NUMBER ON KEYBOARD *KEY POSITION NUMBER ON OPTION KEYBOARD *KEY POSITION NUMBER ON FLAT KEYBOARD *FUNCTION KEY CODE TABLE...
  • Page 5 Table of Contents Page II. P R O G R A M M I N G ' P 1 ' P O S I T I O N 1. DEPARTMENT PROGRAMMING 2. PLU PROGRAMMING 3. PLU PRICE CHANGE 4. COMMERCIAL MESSAGE 5.
  • Page 6 Table of Contents Page 28. MASTER/SLAVE TABLE FOR I.R.C. 1)Machine ID programming 2)Master slave table programming 29. TIME PROGRAMMING 30. DATE PROGRAMMING 31. TARE WEIGHT PRESET 32. CONSECUTIVE No. SET 33. MODEM PRESET 34. ALL PRESET REPORT 35. PROGRAM VERSION DISPLAY 36.
  • Page 7 Table of Contents Page III. S E R I A L I N T E R F A C E & C O N N E C T I O N S 1. INTER-REGISTER COMMUNICATION (IRC) (1) INTERFACE SPECIFICATION for Inter-Register Communication (2) INTRODUCTION of Inter-Register Communication (3) PROGRAMMING with Inter-Register Communication 2.

  • Page 8: Basic Operation

    BASIC OPERATION 1. P2 MODE This programming mode is used for important function level. Therefore don’t change in user side. <P2> MODE : SPECIAL PROGRAMMING MODE SELECT PROGRAM ITEM OPTION FLAG PROGRAM CHANGE LAYOUT CHANGE ALPHA LAYOUT SELECT PROGRAM ITEM RAM CLEAR OPERATION COPY SYSTEM...

  • Page 9: P1 Mode

    2. P1 MODE This programming mode is used for general user programming. <P1> MODE : USER PROGRAMMING MODE SELECT PROGRAM ITEM DEPARTMENT PROGRAM PROGRAMMING COMMERCIAL MESSAGE SELECT PROGRAM ITEM PRESET REPORT VERSION No. DISPLAY TRAINING MODE You can select following menu by using SCRL-UP and SCRL DOWN keys. DEPARTMENT PROGRAMMING PLU PROGRAMMING PLU QUICK PRICE CHANGE...

  • Page 10: Menu Sellection Key

    3. MENU SELECTION KEY In P1 and P2 mode, following six keys are used frequently. Used for scrolling up menu items. Used for scrolling down menu items. Used for selecting each menu. Used for data setting. (Same as ENTER key on PC) Used for returning to main menu and exit.
  • Page 11 Example: Changing option flag#3 value from 15 to 14 Press [CASH] key to enter Option flag programming SELECT PROGRAM ITEM mode. OPTION FLAG PROGRAM CHANGE LAYOUT CHANGE ALPHA LAYOUT Press [CASH] key to select data preset mode. SELECT OPERATION DATA PRESET MODE PRESET...

  • Page 12: P R O G R A M M I N G A T ' P 2 ' P O S I T I O N

    P. 5 II. P R O G R A M M I N G ' P 2 ' P O S I T I O N THE CONTROL LOCK KEY SHOULD BE TURNED TO 'P2' POSITION. TURNING TO 'P2' POSITION IS AVAILABLE ONLY BY SPECIAL P2 KEY. 1.

  • Page 13: Option Flag Programming

    P. 6 2. OPTION FLAG PROGRAMMING OPERATION SEQUENCE Select "OPTION FLAG PROGRAM" in P2 mode main menu and [CASH] key. If you choose "DATA PRESET MODE", press [CASH] key. If you choose "PRESET REPORT ", press [CASH] key for a program scan. Note: To exit operation press [TOTAL] key.

  • Page 14: Flag No.2 (Department Flags)

    P. 7 (2)Flag No.2 (DEPARTMENT FLAGS) [1]Not used [2]Assign the operation of DEPT SHIFT KEY = STAY DOWN MODE = POP UP MODE [3]Skip 0 data on Department Report yes/no [4]Not used +-----------+-------+---------+-------+-------+ | Flag Value| +-----------+-------+---------+-------+-------+ | POP UP | POP UP | POP UP | POP UP...

  • Page 15: Flag No.4 (Plu Flags)

    P. 8 BEFORE CHANGING OPTION FLAG 4 READ TOP OF PAGE 42 (4)Flag No.4 (PLU FLAGS) [1]PLU price level 1level/3levels [2]PLU descriptor length 12digits/16digits [3]not use [4]Prohibit programming PLU unit price of "0" yes/no +-----------+-------+------+-------+-------+ | Flag Value| [2] | +-----------+-------+------+-------+-------+ | ----- | | ----- |...

  • Page 16: Flag No.6 (Plu Flags)

    P. 9 (6)Flag No.6 (PLU FLAGS) [1]Print Negative PLU on All PLU Reports yes/no [2]Print sales ratio of All PLU Reports yes/no [3]Print sales ratio of PLU GROUP 1 Report yes/no [4]Print sales ratio of PLU GROUP 2 Report yes/no +-----------+-------+-------+-------+-------+ | Flag Value| +-----------+-------+-------+-------+-------+...

  • Page 17: Flag No.8 (Cashier/Clerk Flags)

    P.10 (8)Flag No.8 (CASHIER/CLERK FLAGS) [1]Cashier Key is changeable during registration yes/no [2]CLERK-ID number is changeable during registration yes/no [3]Maintain CLERK-ID after registered yes/no [4]Allow indication of the CLERK-ID number yes/no (If 'no' then operation is [CLERK-ID] 999999 [CLERK-ID]) +-----------+-------+-------+-------+-------+ | Flag Value| +-----------+-------+-------+-------+-------+ | *DEFAULT VALUE...

  • Page 18: Flag No.10 (Tax Flags)

    P.11 (10)Flag No.10 (TAX FLAGS) [1]Assign Tax 1 [2]Assign Tax 2 [3]Assign Tax 3 = Add-on Tax Mode (EXCLUDE) [4]Assign Tax 4 = Value Added Tax Mode (INCLUDE) +-----------+---------+---------+---------+---------+ | Flag Value| +-----------+---------+---------+---------+---------+ | EXCLUDE | EXCLUDE | EXCLUDE | EXCLUDE | *DEFAULT VALUE | EXCLUDE | EXCLUDE | EXCLUDE | INCLUDE | | EXCLUDE | EXCLUDE | INCLUDE | EXCLUDE | | EXCLUDE | EXCLUDE | INCLUDE | INCLUDE |...

  • Page 19: Flag No.12 (Tax Flags)

    P.12 (12)Flag No.12 (TAX FLAGS) [1]Print Tax symbol yes/no [2]Print Taxable Amount on receipt/journal yes/no [3]Print Amount of each tax on receipt/journal yes/no [4]Print Total of all taxes on receipt/journal yes/no +-----------+-------+-------+-------+-------+ | Flag Value| +-----------+-------+-------+-------+-------+ | *DEFAULT VALUE +-----------+-------+-------+-------+-------+ (13)Flag No.13 (ROUNDING/CALCULATION FLAGS) [1]Decimal point position This operation is available only when all report data is zero.

  • Page 20: Flag No.15 (Rounding/Calculation Flags)

    P.13 (15)Flag No.15 (ROUNDING/CALCULATION FLAGS) [1]Not used +-----------+---------------------+ | Flag Value| +-----------+---------------------+ Round Down Round Up +-----------+---------------------+ (16)Flag No.16 (ROUNDING/CALCULATION FLAGS) [1]Rounding factor for % calculation and FC calculation +-----------+---------------------+ | Flag Value| +-----------+---------------------+ Round Down | *DEFAULT VALUE Round Up +-----------+---------------------+ (17)Flag No.17 (ROUNDING/CALCULATION FLAGS) [1]Overflow check by SUBTOTAL only / by SUBTOTAL &...

  • Page 21: Flag No.18 (Rounding/Calculation Flags)

    P.14 (18)Flag No.18 (ROUNDING/CALCULATION FLAGS) [1]Rounding for last 2 integers of used minimum coin +-----------+---------------------+ | Flag Value| +-----------+---------------------+ minimum coin = 1 | *DEFAULT VALUE +-----------+---------------------+ (19)Flag No.19 (ROUNDING/CALCULATION FLAGS) [1]Rounding for last 2 integers of maximum Round Down an amount +-----------+---------------------+ | Flag Value| +-----------+---------------------+...

  • Page 22: Flag No.21 (2X Bar Code Type Flag)

    P.15 (21)Flag No.21 (2X BAR CODE TYPE FLAG) Reading the 2X type of bar code is available by using a general barcode scanner. See "(8) 2X TYPE of BAR CODE" of "2. SCANNER CONNECTION". +-----------+-------------------------------+ | Flag Value| Content +-----------+-------------------------------+ | Not use the 2X code | *DEFAULT VALUE +-----------+-------------------------------+...

  • Page 23: Flag No.22 (Receipt/Journal Flags)

    P.16 (22)Flag No.22 (EXTERNAL DISPLAY FLAGS) [1]Not used [2]Used external display type STANDARD/EPSON [3]Subtotal to external display include add-on TAX yes/no [4]Subtotal display during transaction yes/no +-----------+-------+-------+-------+-------+ | Flag Value| +-----------+-------+-------+-------+-------+ | EPSON | | EPSON | | EPSON | | EPSON | +-----------+-------+-------+-------+-------+ (23)Flag No.23 (RECEIPT/JOURNAL FLAGS)

  • Page 24: Flag No.24 (Receipt/Journal Flags)

    P.17 (24)Flag No.24 (RECEIPT/JOURNAL FLAGS) [1]Number of times to permit Buffered printing 1 time/unlimited [2]Count up consecutive number yes/no [3]Print on Journal during transaction yes/no [4]Buffered Receipt printing is permitted yes/no +-----------+---------+-------+-------+-------+ | Flag Value| +-----------+---------+-------+-------+-------+ | 1 time | *DEFAULT VALUE | 1 time | 1 time | 1 time...

  • Page 25: Flag No.26 (Receipt/Journal Flags)

    P.18 (26)Flag No.26 (RECEIPT/JOURNAL FLAGS) [1]Graphic LOGO with/without [2]Printer cutting type full/Percale cut [3]Printer auto cutter with/without [4]Graphic LOGO used default data yes/no +-----------+---------+---------+---------+-------+ | Flag Value| +-----------+---------+---------+---------+-------+ with full | without | with full | without | with full with with full...

  • Page 26: Flag No.28 (Report Flags)

    P.19 (28)Flag No.28 (REPORT FLAGS) [1]Print report count on report yes/no [2]Reset consecutive number after issuance of Z1 Report yes/no [3]Grand total after Z1 Full Report Resetable/Non resetable [4]Skip 0 data on Function report yes/no +-----------+-------+-------+---------------+-------+ | Flag Value| +-----------+-------+-------+---------------+-------+ Resetable Resetable | Non resetable |...

  • Page 27: Flag No.30 (Report Flags)

    P.20 (30)Flag No.30 (REPORT FLAGS) [1]Print CANCEL total on report yes/no [2]Print Non Resetable Grand Total and Gross Total yes/no [3]Print Non Resetable Grand Total on X2,Z2-report yes/no [4]Addition Gross Total to Grand Total or Addition NET Total to Grand Total +-----------+-------+-------+-------+-------------+ | Flag Value| +-----------+-------+-------+-------+-------------+...

  • Page 28: Flag No.32 (Error/Invalid/Prohibit Operation Flags)

    P.21 (32)Flag No.32 (ERROR/INVALID/PROHIBIT OPERATION FLAGS) [1]Not used [2]Generate an error when total amount is '0' yes/no [3]When non-preset key is used Generate on error or invalidate the operation [4]Compulsory card number input in card payment yes/no +-----------+-------+-------+------------+---------+ | Flag Value| +-----------+-------+-------+------------+---------+ error error...

  • Page 29: Flag No.34 (User's Choice Operation Flags)

    P.22 (34)Flag No.34 (TRAININNG OPERATION FLAGS) *1 [1]Print training total amount on Report and display yes/no [2]Print on receipt in training mode yes/no [3]Print on journal in training mode yes/no [4]Training mode entering is available in R mode yes/no +-----------+-------+-------+-------+-------+ | Flag Value| +-----------+-------+-------+-------+-------+ | *DEFAULT VALUE...

  • Page 30: Flag No.36 (User's Choice Operation Flags)

    P.23 (36)Flag No.36 (USER'S CHOICE OPERATION FLAGS) [1]TenKey speaker with/without [2]Compulsory [SUBTOTAL] key operation before finalization yes/no [3]Chain multiplication or Split pricing [4]Multi subtotal % operation yes/no +-----------+---------+-------+-------------+-------+ | Flag Value| +-----------+---------+-------+-------------+-------+ with | Chain multi | with | Chain multi | with | Split price | | *DEFAULT VALUE...

  • Page 31: Flag No.38 (User's Choice Operation Flags)

    P.24 (38)Flag No.38 (USER'S CHOICE OPERATION FLAGS) [1]Allow POST-TENDERING yes/no [2]Allow for Check Cashing yes/no [3]Stop report printing yes/no [4]Subtotal display include add-on TAX yes/no +-----------+-------+-------+-------+-------+ | Flag Value| +-----------+-------+-------+-------+-------+ | *DEFAULT VALUE +-----------+-------+-------+-------+-------+ Note [3]: If you press the clear key, the display will show '-- FIn --',Receipt and Journal will print '*INCOMPLETE REPORT' and the printer will stop.

  • Page 32: Flag No.40 (Not Used)

    P.25 (40)Flag No.40 (Not used) [1]Not used [2]Not used [3]Check validation Sales total / Check tender [4]Allow issuance of multi Validation Yes / No Note: Flag [3],[4] is available only on the machine which is installed a dot matrix printer. +-----------+-------+-------+-------+-------+ | Flag Value| +-----------+-------+-------+-------+-------+...

  • Page 33: Flag No.42 (Report Flags)

    P.26 (42)Flag No.42 (REPORT FLAGS) [1]Not used [2]Print Z-Count on Z transaction report yes/no [3]Prohibit issuance of X2-report all yes/no [4]Prohibit issuance of Z2-report all yes/no +-----------+-------+-------+-------+-------+ | Flag Value| +-----------+-------+-------+-------+-------+ | *DEFAULT VALUE +-----------+-------+-------+-------+-------+ (43)-(47) Flag No.43 – Flag No.47 (Not used) (48)Flag No.48 (SUBTOTAL AMOUNT DISCOUNT FLAGS) [1]DISCOUNT1 AFFECT FOOD STAMP Yes/No...

  • Page 34: Changing Key Layout

    P.27 3. CHANGING KEY LAYOUT OPERATION SEQUENCE Select "CHANGE KEY LAYOUT" in P2 mode main menu and press [CASH] key. ●If you choose "PRESET REPORT ", press [CASH] key for a program scan. ●If you choose "DATA PRESET MODE", press [CASH] key. CHANGE ALPHA LAYOUT...

  • Page 35: Key Position Number On Flat Keyboard

    P.28 KEY POSITION NUMBER ON FLAT KEYBOARD *01:[RF],08:[JF] CAN NOT BE RELOCATED. +---+---+---+---+---+---+---+---+---+---+ | 64| 75| 86| 97|108|119|130|141|152|163| +---+---+---+---+---+---+---+---+---+---+ | 65| 76| 87| 98|109|120|131|142|153|164| +---+---+---+---+---+---+---+---+---+---+ | 66| 77| 88| 99|110|121|132|143|154|165| +---+---+---+---+---+---+---+---+---+---+ | 67| 78| 89|100|111|122|133|144|155|166| +---+---+---+---+---+---+---+---+---+---+---+---+---+---+---+---+---+---+---+ |*01|*08| 15| 22| 29| 36| 43| 50| 57| 68| 79| 90|101|112|123|134|145|156|167| +---+---+---+---+---+---+---+---+---+---+---+---+---+---+---+---+---+---+---+ | 02| 09| 16| 23| 30| 37| 44| 51| 58| 69| 80| 91|102|113|124|135|146|157|168| +---+---+---+---+---+---+---+---+---+---+---+---+---+---+---+---+---+---+---+...

  • Page 36: Function Key Code Table

    P.29 FUNCTION KEY CODE TABLE +-----+-----------------------------------+-----+-----------------------------------+ | CODE| FUNCTION | CODE| FUNCTION +-----+-----------------------------------+-----+-----------------------------------+ 00 | NOP 50 | CLEAR 01 | 1 51 | ERROR CORRECTION 02 | 2 52 | VOID 03 | 3 53 | RETURN 04 | 4 54 | CANCEL 05 | 5 55 | +%1...

  • Page 37: Changing Alpha Key Layout

    P.30 4. CHANGING ALPHA KEY LAYOUT OPERATION SEQUENCE Select "CHANGE ALPHA LAYOUT" in P2 mode main menu and press [CASH] key. ● If you choose "PRESET REPORT ", press [CASH] key for a program scan. ● If you choose "DATA PRESET MODE", press [CASH] key. CHANGE ALPHA LAYOUT...

  • Page 38: Default Alpha Key Layout

    P.31 DEFAULT ALPHA KEY LAYOUT The following keys are fixed. [RF] KEY : The Receipt Feed Key [JF] KEY : The Journal Feed Key [ENT/REL] KEY : A CAPITAL LETTER MODE <--> A SMALL LETTER MODE [PLU] KEY : A DOUBLE-WIDE CHARACTER [VOID] KEY : The Back Space Key [CLR]...

  • Page 39: Default Alpha Key Layout On Flat Keyboard

    P.32 DEFAULT ALPHA KEY LAYOUT ON FLAT KEYBOARD +---+---+---+---+---+---+---+---+---+---+ | A | B | C | D | E | F | G | H | I | J | +---+---+---+---+---+---+---+---+---+---+ | K | L | M | N | O | P | Q | R | S | T | +---+---+---+---+---+---+---+---+---+---+ | U | V | W | X | Y | Z | +---+---+---+---+---+---+---+---+---+---+...

  • Page 40: Alpha Key Code Table

    P.33 A L P H A K E Y C O D E T A B L E You may use the following keys with the ALPHA Input Mode. [PLU] KEY : A DOUBLE-WIDE CHARACTER [ENT/REL] KEY : A CAPITAL LETTER MODE <-->...

  • Page 41: Changing Transaction Descriptor

    P.34 5. CHANGING TRANSACTION DESCRIPTOR OPERATION SEQUENCE Select "CHANGE DESCRIPTOR " in P2 mode main menu and press [CASH] key. ●If you choose "PRESET REPORT ", press [CASH] key for a program scan. ●If you choose "DESCRIPTOR PRESET", press [CASH] key to entry programming mode. CHANGE DESCRIPTOR ENTER DSC.

  • Page 42: Transaction Descriptor Table No.1 : English

    P.35 TRANSACTION DESCRIPTOR TABLE No.1 : ENGLISH +---+---------+---+---------+---+---------+---+---------+---+-------------------------+ |No.| 8 CHARA |No.| 8 CHARA |No.| 8 CHARA |No.| 8 CHARA |No.| 24 CHARACTERS +---+---------+---+---------+---+---------+---+---------+---+-------------------------+ 1| DEPT TL | 51| CARD4 |101| ITEM# |151| PASSWORD|201| * * * * * * * * | 2| RETURN | 52| CHARG ID|102| EXCH |152| LOCK OUT|202| * * * *...

  • Page 43: Setting Serial Port

    P.36 6. SETTING SERIAL PORT Cautions: Port #2 is fixed for I.R.C. by hardware setting. Not to plug any other device into port #2.If you want to use it as RS-232C serial port, you must modify the main board following another instructions. Please don’t change its configuration without main board modifications.

  • Page 44: Hold Record Count(Level)

    P.37 7. HOLD RECORD COUNT(LEVEL) OPERATION SEQUENCE You can select number of level (0-8) for HOLD record. ● Select "HOLD RECORD COUNT" in P2 mode main menu and press [CASH] key. HOLD RECORD COUNT ENTER HOLD REC. Enter hold maximum count (level) and press [CASH] key. (MAX holding count =0-8) ●...

  • Page 45: Ram Copy (Irc)

    P.38 10. RAM COPY (IRC) Select "IRC RAM COPY" in P2 mode main menu and press [CASH] key. And enter slave number and press [CASH] key. If want to select all ECR, press [CASH] key without any number. Note: To exit operation, press [TOTAL] key. The Master ECR will copy all preset data to the selected Slave ECR except DATE, TIME, CONSECUTIVE No., MACHINE No., PASSWORD, HOLD record count, LOGO STAMP MESSAGE, detail slip format and Serial Port Programming.

  • Page 46: P R O G R A M M I N G A T P O S I T I O N

    P.39 III. P R O G R A M M I N G ' P 1 ' P O S I T I O N 1. DEPARTMENT PROGRAMMING Select "DEPARTMENT PROGRAM" in P1 mode main menu and press [CASH] key. ●...
  • Page 47 P.40 DEPARTMENT PROGRAM DEPT-0001 ENTER UNIT PRICE 0.00 Enter unit price and press [CASH] key. DEPARTMENT PROGRAM DEPT-0001 ENTER HALO TABLE Enter HALO table number(1-15) and press [CASH] key. DEPARTMENT PROGRAM DEPT-0001 ENTER FLAG VALUE 000000 Enter 6 digits number for FLAG A,B and C and press [CASH] key. +---+---+---+ FLAG | | | | | | |...
  • Page 48 P.41 DEPARTMENT PROGRAM DEPT-0001 ENTER DEPT GROUP Enter department group number(0-10) and press [CASH] key. DEPARTMENT PROGRAM DEPT-0001 ENTER LALO TABLE Enter LALO table number(1-15) and press [CASH] key. ● If you choose "DELETE ", press [CASH] key to delete programming data. DEPARTMENT PROGRAM ENTER...

  • Page 49: Plu Programming

    P.42 2. PLU PROGRAMMING Operation sequence is similar to DEPARTMENT programming. Please refer to PAGE 39, 40 and 41. Before starting, please check the value of option flag 3 and 4. If you want to change basic format of PLU memory, please change these option flags value first.
  • Page 50 P.43 PLU option flag +---+---+---+ OPTIONS | | | | | | | A,C : Linked Department Flag by Option Flag No.3 +---+---+---+ B : Only PLU Flag +---+-------+-------+----------+--------+ | SINGLE|NON ADD| NEGATIVE | FOOD | A | ITEM ITEM| ITEM STAMP | +---+-------+-------+----------+--------+...

  • Page 51: Plu Price Change

    P.44 3. PLU PRICE CHANGE OPERATION SEQUENCE Select "PLU PRICE CHANGE" in P1 mode main menu and press [CASH] key. PRICE CHANGE ENTER Enter PLU number and press [CASH] key. PRICE CHANGE ENTER UNIT PRICE 0.00 Enter new PLU price and press [CASH] key. Note: To exit operation, press [TOTAL] key.

  • Page 52: Direct Plu Key Programming

    P.45 5. DIRECT PLU KEY PROGRAMMING (MAX. 100 KEYS) Note: First of all, you must program some DIRECT PLU KEYS on the Keyboard. See CHANGING KEY LAYOUT('P2' position). And then you must choose PLU shift type by the option Flag No.7-[3] before programming direct PLU key table. Three types of PLU SHIFT function are available.
  • Page 53 P.46 DIRECT KEYTABLE ENTER TABLE No.1-100 (3) Enter start table number and press [CASH] key. DIRECT KEYTABLE ENTER (4) Enter PLU code and press [CASH] key. Table number is incremented automatically. If you want to decrement table number, press [SUBTOAL] key. (5) If you want to program for next shift level, press [TOTAL] to exit this mode and then repeat sequence.
  • Page 54 P.47 DIRECT KEYTABLE TIME 00:00-24:00 Enter start time (HH,MM 4 digits) and press [CASH] key. Note: You can select PLU code lengths 6 or 13 digits. (See option flag No.3) DIRECT KEYTABLE ENTER SHIFT Enter shift number and press [CASH] key. Note: Time shift table affects to PLU shift TPYE 3.

  • Page 55: Plu Stock Programming

    P.48 6. PLU STOCK PROGRAMMING Select "PLU STOCK PROGRAM" in P1 mode main menu and press [CASH] key. ● If you choose "NEW STOCK ENTER ", press [CASH] key. STOCK PROGRAM ENTER Enter PLU number that you want to program stock and press [CASH] key. STOCK PROGRAM NAME...

  • Page 56: Clerk-Id Number And Name

    P.49 7. CLERK-ID NUMBER and NAME (MAX 99 CLERKS) Select "CLERK PROGRAMMING" in P1 mode main menu and press [CASH] key. ● If you choose "CORRECTION, CREATE ", press [CASH] key. CLERK PROGRAM CLERK TABLE 1-99 Enter Clerk number(1-99) and press [CASH] key. CLERK PROGRAM CLERK...

  • Page 57: Machine No

    P.50 8. MACHINE No. Select "MACHINE No. PROGRAM" in P1 mode main menu and press [CASH] key. MACHINE PROGRAM ENTER MACHINE Enter machine number(1-99) Note: When using PC communication or I.R.C this machine number must be programmed. 9. REPORT P2MODE PASSWORD Select "PASSWORD PROGRAMMING"...

  • Page 58: Tax Rate (Tax1 - Tax4)

    P.51 10. TAX RATE (TAX1 – TAX4) Select "TAX RATE PROGRAMMING" in P1 mode main menu and press [CASH] key. ● If you choose "STRAIGHT TAX RATE", press [CASH] key. RATE PROGRAM RATE nn.nnn 5.000 Enter percent rate (including three decimal parts) for tax 1 and press [CASH] key. Note: TAX rate is 5 digits.

  • Page 59: Lock Out Amount Table (Halo/Lalo Table)

    P.52 11. LOCK OUT AMOUNT TABLE (HALO/LALO TABLE) Select "HALO TABLE PROGRAM" in P1 mode main menu and press [CASH] key. You can use 16 kinds of HALO table. HALO TABLE PROGRAM ENTER HIGH AMOUNT 100.00 Enter HALO value (MAX. 8 digits) and press [CASH] key. You can use 15 kinds of LALO table.

  • Page 60: Group Name For Report

    P.53 13. GROUP NAME for REPORT Select "GROUP NAME PROGRAM" in P1 mode main menu and press [CASH] key. ● If you choose "DEPARTMENT GROUP", press [CASH] key. GROUP NAME PROGRAM ENTER DEPT GROUP Enter department group number (1-10) and press [CASH] key. GROUP NAME PROGRAM...

  • Page 61: Direct Dept Key With Shift Programming

    P.54 14. DIRECT DEPT KEY WITH SHIFT PROGRAMMING (MAX. 40 KEYS) First of all, you must program some DIRECT DEPT KEYS WITH SHIFT on the Keyboard. See CHANGING KEY LAYOUT. DIRECT DEPT KEY will shift by pressing the DEPT SHIFT KEY. Select "DIRECT DEPT KEY TABLE"...

  • Page 62: Cashier Name And Link Drawer

    P.55 15. CASHIER NAME and LINKED DRAWER Select "CASHIER PROGRAMMING" in P1 mode main menu and press [CASH] key. CASHIER PROGRAMMING ENTER CASHIER No.1-4 Enter cashier number (1-4) and press [CASH] key. CASHIER PROGRAMMING ENTER NAME Enter cashier name. (See alpha key code table) SELECT USED DRAWER...

  • Page 63: Percentage Discount/Add-On Key

    P.56 16. PERCENTAGE DISCOUNT/ADD-ON KEY Select "%DISCOUNT %ADD-ON" in P1 mode main menu and press [CASH] key. ● Select preset item. %DISCOUNT %ADD-ON ENTER PERCENT nn.nnn 0.000 Enter percentage rate with decimal point. Note: Rate is 2digits(integer) + 3digits(decimal). In case of 10%, input only integer 10. In case of 10.005%, input 10 and 005 after decimal point.
  • Page 64 P.57 +-+-+ (1) Tax calculation obeys linked tax flag yes/no OPTION | | | (2) Calculated amount link to DEPT/PLU yes/no +-+-+ (3) Compulsory Validation yes/no (4) Management Control(X-LOCK) yes/no +---+-----+-----+-----+-----+ | (1) | (2) | (3) | (4) | +---+-----+-----+-----+-----+ | 00| NO |...

  • Page 65: Amount Discount Key

    P.58 17. AMOUNT DISCOUNT KEY Select "AMOUNT DISCOUNT" in P1 mode main menu and press [CASH] key. ● Select preset item. AMOUNT DISCOUNT ENTER DISC. AMOUNT 0.00 Enter discount amount (MAX. 8 digits) and press [CASH] key. AMOUNT DISCOUNT ENTER HALO TABLE Enter HALO table number and press [CASH] key.

  • Page 66: Mix Match Table

    P.59 18. MIX MATCH TABLE Select "MIX MATCH TABLE" in P1 mode main menu and press [CASH] key. MATCH TABLE ENTER MATCH Enter mix match table number (1-30) and press [CASH] key. MATCH TABLE MATCH COUNT Enter match quantity (0-99) and press [CASH] key. MATCH TABLE DISCOUNT...

  • Page 67: Closing Media Key

    P.60 19. CLOSING MEDIA KEY Select "CLOSING MEDIA" in P1 mode main menu and press [CASH] key. ● Select preset item. CLOSING MEDIA CASH ENTER HALO TABLE Enter HALO table number and press [CASH] key. CLOSING MEDIA CASH ENTER FLAG VALUE Enter option flag value and press [CASH] key.

  • Page 68: Other Function Key

    P.61 20. OTHER FUNCTION KEY Select "OTHER FUNCTION KEY" in P1 mode main menu and press [CASH] key. Select preset item. OTHER FUNCTION ENTER HALO TABLE Enter HALO table number and press [CASH] key. Note: HALO table programming item is indicated only when R/A or P/O selected. OTHER FUNCTION ENTER...

  • Page 69: Foreign Currency

    P.62 21. FOREIGN CURRENCY Select "FOREIGN CURRENCY" in P1 mode main menu and press [CASH] key. FOREIGN CURRENCY ENTER NUMBER(1-5) Enter foreign currency number (1-5) and press [CASH] key. FOREIGN CURRENCY RATE nnn.nnnnnn 0.000000 Enter foreign currency rate (without decimal point) and press [CASH] key. FOREIGN CURRENCY ENTER...

  • Page 70: Report Chain

    P.63 23. REPORT CHAIN Select "CHAIN REPORT PROG." in P1 mode main menu and press [CASH] key. Select report level from X1 to Z2. Select chain report items. When finished, SCROLL to top and choose “ END OF SELECTION”. Note: If you want to cancel the REPORT CHAIN, you must select the "END OF SELECTION"...

  • Page 71: Print Item For Check Printing

    P.64 26. PRINTING ITEM for CHECK PRINT Select "CHECK PRINT ITEM" in P1 mode main menu and press [CASH] key. ● If you choose "PRESET CHECK PRINT", press [CASH] key. Select printing item. CHECK PRINT ITEM SUBTOTAL SYMBOL1 Preset character. (SEE ALPHA KEY CODE TABLE) Programmable printing item +------------------------+-----------------------------+ | PRINTING ITEM...
  • Page 72 P.65 CHECK PRINT FORMAT ENTER PRINT FORMAT Enter print format data and press [CASH] key. PRINT ITEM NUMBER +----------+------------------------+-------------------------------------------+ | ITEM No. | PRINTING ITEM | ABOUT FORMAT +----------+------------------------+-------------------------------------------+ | NON PRINT | SUBTOTAL with SYMBOL 1 | Programmable SYMBOL 1 (Max.10 Characters) | | SUBTOTAL with SYMBOL 2 | Programmable SYMBOL 2 (Max.10 Characters) | | DAY of DATE | Fixed Format "DD"...

  • Page 73: Master/Slave Table For I.r

    P.66 28. MASTER/SLAVE TABLE (IRC) When using I.R.C function, following item must be programmed correctly. 1) Machine ID programming Turn the mode lock to the P1 position. SELECT PROGRAM ITEM STOCK PROGRAM CLERK PROGRAM MACHINE No. PROGRAM Then select Machine No. programming and press [CASH] key. MACHINE No.ROGRAM ENTER...

  • Page 74: Time Programming

    P.67 29. TIME PROGRAMMING Select "TIME PROGRAMMING" in P1 mode main menu and press [CASH] key. Display now time and you can enter new TIME. Note: Time enter by 24 hour. If enter 6 digits, HH,MM,SS If enter 4 digits, HH,MM To exit operation, press [TOTAL] key.

  • Page 75: Modem Preset

    P.68 33. MODEM PRESET Select "MODEM PRESET" by P1 mode main menu. ● If you choose "MODEM FLAG PRESET", press [CASH] key. MODEM PRESET ENTER FLAG VALUE Enter modem option flag value and press [CASH] key. +-+-+ (1)Not used OPTION | | | (3)Not used +-+-+...

  • Page 76: All Preset Report

    P.69 33. ALL PRESET REPORT Select "P1 PRESET REPORT" in P1 mode main menu and press [CASH] key. ISSUE the Preset Report 34. PROGRAM VERSION DISPLAY OPERATION SEQUENCE Select "VERSION No. DISPLAY" in P1 mode main menu and press [CASH] key. Version x.xx 35.

  • Page 77: Inter-Register Communication (Irc)

    P.70 III. S E R I A L I N T E R F A C E & C O N N E C T I O N S Port#3 and #4 are option Cautions: Port #2 is fixed for I.R.C. by hardware setting. to plug any other device into port #2.If you want to use it as RS-232C serial port, you must modify the main board following another instructions.

  • Page 78: Programming With Inter-Register Communication

    P.71 (3) PROGRAMMING with Inter-Register Communication If you program at the Master ECR, the Master ECR will copy the programmed data to all Slave ECRs. If the Master ECR can not communicate to a Slave ECR, when you pressed Q/F key for programming No. input, your input will be of no effect.

  • Page 79: Scanner Connection

    P.72 2. SCANNER CONNECTION YOU MAY CONNECT A BARCODE SCANNER TO ONE OF RS-232C PORTS (PORT-#1,#3,#4). Cautions: Port #2 is fixed for I.R.C. by hardware setting. to plug any other device into port #2.If you want to use it as RS-232C serial port, you must modify the main board following another instructions.

  • Page 80: Connection For Nippondenso Bhs 6060 Hand Scanner

    P.73 (3) CONNECTION for NIPPONDENSO BHS 6060 Hand Scanner (with PORT-#1,#3,#4) ECR side BHS 6060 side DSUB9 DSUB9 (Pin No.D) Received Data (RXD) 3 (TXD) Transmitted Data (TXD) 2 (RXD) Data Terminal Ready (DTR) 4 (CTS) Data Set Ready (DSR) Clear To Send (CTS) 5 (RTS)

  • Page 81: Metrologic Ms700 Scanner Dip Switch Settings

    P.74 (5) Metrologic MS700 Scanner Dip Switch Settings +-+-+-+-+-+-+-+-+ +-+-+-+-+-+-+-+-+ +-+-+-+-+-+-+-+-+ +-+-+-+ |o|o|o|o| | |o|o| | | | | | | | |o| |o| | | |o| | |o| |o| | | OFF | | | | |o|o| | | |o|o|o|o|o|o|o| | | |o|o|o| |o|o| | | |o|o|...

  • Page 82: Type Of Bar Code

    P.75 (7) 2X TYPE of BAR CODE The 2X type of bar code can be read by the scanner. The 2X type of bar code is the following EAN/JAN(13 digits bar code) for the weight of goods or the unit price of goods. You can select The 2X type of bar code by the option flag No.21.

  • Page 83: Scale Connection

    P.76 3. SCALE CONNECTION THE SCALE (67xx SERIES by NCI WEIGHTRONIC or PD-1 by CAS) CAN BE CONNECTED TO THE ECR. YOU MAY CONNECT THE SCALE TO ONE OF RS-232C SERIAL PORTS(PORT-#1,#3,#4). Cautions: Port #2 is fixed for I.R.C. by hardware setting. to plug any other device into port #2.If you want to use it as RS-232C serial port, you must modify the main board following another instructions.

  • Page 84: Protocol

    P.77 (3) PROTOCOL -----------------> SCALE COMMAND <----------------- SCALE RESPONSE COMMAND : 'W'(57H) RESPONSE : WEIGHT +-------+---------+-------------+ | 1 byte| STX | 02H | 5 byte| WEIGHT | Kg = XX.XXX | | 1 byte| CR | 0DH +-------+---------+-------------+ RESPONSE : ERROR +-------+---------+-----+ STATUS : Bit4 = 1 : CENTER OF ZERO | 1 byte| STX...

  • Page 85: Slip Printer Connection

    P.78 4. SLIP PRINTER CONNECTION THE SLIP PRINTER (TM-290II or TM-U295 BY SEIKO EPSON) CAN BE CONNECTED TO THE ECR. YOU MAY CONNECT THE SLIP TO ONE OF RS-232C PORTS(PORT-#1,#3,#4). Cautions: Port #2 is fixed for I.R.C. by hardware setting. to plug any other device into port #2.If you want to use it as RS-232C serial port, you must modify the main board following another instructions.

  • Page 86: External Display Connection

    P.79 5. EXTERNAL DISPLAY CONNECTION THE EXTERNAL CUSTOMER DISPLAY (DSP-800) CAN BE CONNECTED TO THE ECR. YOU MAY CONNECT THE DISPLAY TO ONE OF RS-232C SERIAL PORTS(PORT-#1,#3,#4). Cautions: Port #2 is fixed for I.R.C. by hardware setting. to plug any other device into port #2.If you want to use it as RS-232C serial port, you must modify the main board following another instructions.
  • Page 87 P.80 (4) CONNECTION OF THE EXTERNAL DISPLAY AND THE SCANNER A BARCODE SCANNER AND THE EXTERNAL DISPLAY CAN CONNECT TO A SERIAL PORT AT THE SAME TIME. EXAMPLE) PORT #1 ECR side DSP-800 side DSUB9 Transmitted Data (TXD) -------------> 3 (RXD) Clear To Send (CTS) <--+----------...
