ZANE BENCH LARGE
BX-1034-24
Assembly Instructions
Component List :
(A)
Tools List :
(D1) BOLT
(D2) BOLT
Before beginnig
Unpack all parts and hardware to ensure you have all needed components for assembly.
Read this guide cover to cover before beginning assembly.
Have 2 adults on hand for assembly.
Assembly on a padded, non-marring surface.
Save all packaging until finish.
(B)
(E)
HEXAGON NUT
(F)
(G)
WASHER
NUT SPANNER
(SMALL)
(C)
(H)
NUT SPANNER
Advertisement
Table of Contents
Summary of Contents for Moe's BX-1034-24
- Page 1 ZANE BENCH LARGE BX-1034-24 Assembly Instructions Component List : Tools List : (D1) BOLT (D2) BOLT HEXAGON NUT WASHER NUT SPANNER NUT SPANNER (SMALL) Before beginnig Unpack all parts and hardware to ensure you have all needed components for assembly.
- Page 2 ASSEMBLY STEPS - Step 1: Align Tabs of Metal Legs (C) With the Nut Bolt of the Bench top (A) as shown below in diagram, Insert Bolt (D1),With hexagon Nut (E) With Washer (F) & tighten with SPANNER (G). Repeat the same process to secure other end. Do not tighten Allen Bolts fully. Step 2 : METAL ROD(B) Insert Bolt (D2),With hexagon Nut (E) With Washer (F) &...
- Page 3 Step 3 : Once all connections are fully tighten, Turn the table in upright position. Step 4 : Product is ready to use. ASSEMBLLED VIEW Care: Do not clean furniture with harsh clensers or polish. Do not put hot items directly on furnitue surface. Do not put furniture in direct sunlight.
