Hand Held Power Supply Instruction Manual...
Page 2
CAUTION The equipment covered in these operating instructions should be used by qualified employees, trained in and familiar with the safety-related work practices, safety rules and other safety requirements associated with the use of this type of equipment. These instructions are not intended as a substitute for adequate training, nor do they cover all details or situations which could be encountered in relation to the operation of this type of equipment.
Page 3
Design and Function The Hand Held power supply is designed to provide a single phase known voltage source for the test and verification of a voltage detector. It is recommended to use this tool before and after each use of the meter to verify function of the meter to prevent false indications in the event of a tool malfunction.
Page 4
TESTING ON KNOWN VOLTAGE Testing with the Hand Held power supply on non-wired voltage detectors only. 1. Turn the meter in question on and follow the instruction for preparing the unit for use. The power supply can test the appropriate meters in any position listed on the chart on page 5.
Page 5
Hand Held Power Supply Expected Results. Meter Position Expected reading VDA040C FULL SCALE 2.0 - 3.4 2.5 - 5.0 1.0 - 2.0 VDA040P FULL SCALE 2.0 - 3.4 2.5 - 5.0 1.0 - 2.0 VD1000 2.5 - 5.5 3.0 - 6.0 6.0 - 16.0...
Page 6
Bierer & Associates Inc. Bierer & Associates Inc. does not express or imply to be an insurer of these risks, and by purchasing or using this product you AGREE TO ACCEPT THESE RISKS.
