GB
OPERATING INSTRUCTIONS
for HS 480 / HS 481 / HS 482 series hotel safes

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HS 480 Series and is the answer not in the manual?

Questions and answers

Related Manuals for HARTMANN TRESORE HS 480 Series

Summary of Contents for HARTMANN TRESORE HS 480 Series

  • Page 1 OPERATING INSTRUCTIONS for HS 480 / HS 481 / HS 482 series hotel safes...

  • Page 2: Table Of Contents

    HARTMANN TRESORE TABLE OF CONTENTS Instructions 2. Technical specifications 3. Putting into operation 4. Opening/closing the safe 5. Emergency opening 6. Checking battery power Displays 8. Functions of the reader (CEU) 9. Advanced programming functions 10. Reading out operations 11. Tips and help 12.

  • Page 3: Instructions

    IMPORTANT NOTE: The manufacturing company reserves the right to make changes to the product! HARTMANN TRESORE AG is not liable for damage caused by improper use. 1 | INSTRUCTIONS Please follow the following instructions: • Fix the safe on a flat and solid surface using the fixing material supplied.

  • Page 4: Technical Specifications

    HARTMANN TRESORE 2 | TECHNICAL SPECIFICATIONS Control panel 1. Display 2. Control panel 3. RFID sensor 4. Cover 5. USB connection 6. Emergency lock (mechanical) The sketch may differ from the actual product.

  • Page 5: Putting Into Operation

    (see chapter 9). Please obtain the factory setting for the master code directly from HARTMANN TRESORE. For various additional functions, you need a reader, which can be purchased as an option (see chapter 8). To purchase one, please contact HARTMANN TRESORE.

  • Page 6: Emergency Opening

    HARTMANN TRESORE 4 | ÖFFNEN/ SCHLIESSEN DES SAFES 1. Locking the safe (with a 3–6-digit code; see chapter 9) • Close the door. • Enter a 3–6-digit code of your choice. (Code can be reassigned as required each time the safe is locked).

  • Page 7: Checking Battery Power

    HARTMANN TRESORE 4. Emergency opening with reader (CEU) • Connect the reader to the safe’s USB port. • Select “Emer Open” and press “OK” to confirm. • “Mgr Code____ ’’ appears in the display. Please enter the manager code “3333”...

  • Page 8: Displays

    HARTMANN TRESORE 7 | DISPLAYS 1. Normal message -> Repeat the last input. “AGAIN” “BA-HI” -> battery status normal. “BA-LO” -> battery status low. Batteries should be replaced. “CLOSE” -> Locking mechanism extended. “OPEN” -> Locking mechanism retracted. “DONE” -> Input complete.

  • Page 9: Functions Of The Reader (Ceu)

    HARTMANN TRESORE 8 | FUNCTIONS OF THE READER (CEU) You need the reader to make the following settings. Setting a room number • Connect the reader to the safe’s USB port. • Select “Setting” and press “OK” to confirm. •...
  • Page 10 HARTMANN TRESORE Changing the security code • Connect the reader to the safe’s USB port. • Select “Setting” and press “OK” to confirm. • “Mgr Code____ ’’ appears in the display. Please enter the manager code “3333” here and press “OK” to confirm.

  • Page 11: Advanced Programming Functions

    HARTMANN TRESORE 8 | FUNCTIONS OF THE READER (CEU) Example display • 0012-OPEN: The 12 The operation was opening (note that 0001 represents the most recent operation and 0100 represents the oldest) • User Code: opened with user code (opening method) •...
  • Page 12 HARTMANN TRESORE Activating the first number group Enter “clear clear”. “PROG” appears in the display. As soon as the display goes out, enter the function code 7-2-9-3-1-9. The first number group appears and can be changed. The preset is: (A) Displaying or hiding code Digit “0”...
  • Page 13 HARTMANN TRESORE 9 | ADVANCED PROGRAMMING FUNCTIONS 2/2 Digit “2” – private mode The user code is stored once. To lock, you only need to press “close”. The user code can be changed as follows: While the door is open, enter “clear clear 68...
  • Page 14 HARTMANN TRESORE Digit “2” – private mode * (3) Confirm the second number group with “close”. The third number group (date) appears and can be changed. Display A/B/C stands for day/month/year. Here, the example is “6 February 2004”. * (4) Confirm the third number group with “close”.

  • Page 15: Reading Out Operations

    HARTMANN TRESORE 10 | READING OUT OPERATIONS You can read out the last 500 operations. Proceed as follows: • Press appears in the display. “clear clear”. “PROG” • As soon as the display goes out, enter the function code 829319.
  • Page 16 HARTMANN TRESORE 2. Number group: Positions G, H: Show the day of the month the operation was carried out. Positions I, J: Show the month the operation was carried out. Positions K, L: Show the year the operation was carried out.
  • Page 17 Insert the batteries as intended. ons and/or display do not incorrectly. respond. Fault in the electronics. Contact a service employee at Hartmann Tresore AG*. RFID card/sensor is defective. Connection cable is faulty. Use a different cable. Connection between Connections are defective.

  • Page 18: Cleaning And Care

    HARTMANN TRESORE 12 | CLEANING AND CARE PLEASE NOTE! Do not use any strong detergents or hard objects for cleaning. • To clean the safe, please use a soft cloth and a mild, commercially available cleaning agent. Do not use aggressive cleaning agents.

  • Page 19: Guarantee

    HARTMANN TRESORE 14 | GUARANTEE The guarantee period begins with product purchase and lasts 12 months. Please note! The guarantee is rendered invalid if • the installation and operating instructions are not followed correctly and lead to malfunctions. • the appliance is modified in any way.
  • Page 20 HARTMANN TRESORE AG Pamplonastraße 2 33106 Paderborn, Germany +49 (0)5251 1744-179 support@hartmann-tresore.de...
