Summary of Contents for Amica AEC60SS

  • Page 1 AEC60SS AEC90SS Curved glass extractor Use and maintenance...
  • Page 2 Contents Important information Using your extractor Care and maintenance LED lighting Mains electricity connection Troubleshooting Mounting your extractor Installation 2 | Instruction Manual...
  • Page 3 Important information The CDA Group Ltd cannot be held responsible for injuries or losses caused by incorrect use or installation of this product. Please note that CDA reserve the right to invalidate the guarantee supplied with this product following incorrect installation or misuse of the appliance or use in a commercial environment.
  • Page 4 IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2012/19/EU. At the end of its working life, the product must be taken to a special local authority waste collection centre or to a dealer providing appliance recycling services. Disposing of a household appliance separately avoids possible negative consequences for the environment and health.

  • Page 5: Using Your Extractor

    Using your extractor For best performance, you should switch on the extractor 15 minutes before starting to cook and leave it to run for approximately 15 minutes after the end of cooking. Control Panel A - Power off button B - Speed level buttons C - Light button Fig.

  • Page 6: Care And Maintenance

    Care and maintenance IMPORTANT : DO NOT PERFORM MAINTENANCE OR CLEANING OF THE EXTRACTOR WITHOUT FIRST SWITCHING OFF THE ELECTRICITY SUPPLY. Cleaning You should use a non-abrasive Fig. 2 cleaner. Any abrasive cleaner (including Cif) will scratch the surface and could erase the control panel markings.

  • Page 7: Led Lighting

    Please note: Cleaning the grease filter in the dishwasher may lead to discolouration. This is normal and does not constitute a fault with the appliance. Changing the charcoal filter (re-circulating only) To ensure best performance of your extractor, you should replace the charcoal filter every four to six months, depending on use.

  • Page 8: Mains Electricity Connection

    Mains electricity connection THIS APPLIANCE MUST BE CONNECTED TO THE MAINS SUPPLY BY A COMPETENT PERSON, USING FIXED WIRING VIA A DOUBLE POLE SWITCHED FUSE SPUR OUTLET AND PROTECTED BY A 3A FUSE. We recommend that the appliance is DOUBLE POLE SWITCHED FUSED SPUR OUTLET connected by a qualified electrician, who is a member of the N.I.C.E.I.C.

  • Page 9: Electrical Information

    Note: Use a 3A Fuse. Assembly and electrical connection should be carried out by specialised personnel. When installing this product we recommend you seek the help of another individual. Electrical Information Mains electrical voltage: 230 – 240Vac Total rated power consumption: 114W Troubleshooting Please note:...

  • Page 10: Ducting And Ventilation

    Mounting your extractor When the extractor is to be installed above an Amica hob, the minimum distance between the hob and the extractor must exceed 550mm. If the instructions provided with another brand of gas hob state that Centre the required distance between the...

  • Page 11: Installation

    Wherever possible use the rigid circular pipe which has a smooth interior, rather than the expanding concertina style ducting. The lengths of ducting without performance being affected are as follows: 4 metres with 1 x 90° bend • 3 metres with 2 x 90° bends •...
  • Page 12 Tools required Mark out wall as required, see Fig 4. . g i . g i Drill holes Fit wall fixings and top screws - Ensure that any fixings you use are appropriate for the wall type. 10mm Secure hood (tighten all screws) .
  • Page 13 Note: If you are using the supplied ducting adaptor to reduce the diameter from 150mm to 125mm, secure this in before continuing to Fig. 11 Mount chimney brackets. Fix ducting (seal joint) Fig. 10 Fig. 11 Mount the chimney. Adjust and secure the chimney.
  • Page 14 This page has been intentionally left blank 14 | Instruction Manual...
  • Page 15 This page has been intentionally left blank Instruction Manual | 15...
  • Page 16 Amica The CDA Group Building Harby Road Langar Nottinghamshire NG13 9HY Sales Department Phone: 01949 862010 Amica Customer Care Phone: 01949 862012 Email: customer.care@cda.eu ©2021 CDA Group Ltd...
