ASSEMBLY INSTRUCTIONS
CHARLOTTE TWIN BED
To clean your furniture, use a dry or wet cloth, and do not use
chemicals that may damage your product.
The products' assembly system works according to the increasing
order of the indicated numbers. For example: 01, 02, 03, 04 ... to the
end of the assembly.
NOTICE
ASSEMBLY SYSTEM
1
Advertisement
Summary of Contents for Home International Furniture CHARLOTTE D520-05
- Page 1 ASSEMBLY INSTRUCTIONS CHARLOTTE TWIN BED D520-05 White D520-90 Gray D520-101 Coffee Assembly Requirements NOTICE To clean your furniture, use a dry or wet cloth, and do not use chemicals that may damage your product. ASSEMBLY SYSTEM The products’ assembly system works according to the increasing order of the indicated numbers.
-
Page 2: Parts List
ITM/D520- *Please check contents and read the instructions before commencing assembly. *Assemble this product following the enclosed instructions carefully. *Please take care to avoid damaging panels during assembly. *Please assemble on a clean soft suface to avoid damage. PARTS LIST Please Note: The below parts have all been stamped with the part number to help identify them during assembly. -
Page 3: Fittings List
ITM/D520- FITTINGS LIST Screw 1/4x3.1/2 (90mm) Screw 4,5x60mm FLA. Screw 4,5x50mm CHT. Screw 4,0x25mm CHT. Shoe Bolt cover adhesive 10mm Dowel 8x25mm Cylindrical nut Ringed Nails 12x12mm Slats holding support Rails holding support Half moon nut 12mm hole plugs 16mm hole plugs... -
Page 4: Pre-Assembly
Pre-Assembly ITM/D520- Dowel 8x25mm Cylindrical nut... - Page 5 ITM/D520- Pre-Assembly Shoe Ringed Nails 12x12mm...
- Page 6 ITM/D520- Screw 4,0x25mm CHT.
- Page 7 ITM/D520- Screw 4,5x60mm FLA. 12mm hole plugs...
- Page 8 ITM/D520- Screw 4,0x25mm CHT.
- Page 9 ITM/D520- Screw 4,5x60mm FLA. 12mm hole plugs...
- Page 10 ITM/D520- Screw 4,5x60mm FLA. 12mm hole plugs Slats holding support Bolt cover adhesive 10mm Screw 4,5x50mm CHT.
- Page 11 ITM/D520- Rails holding support Screw 1/4x3.1/2 (90mm) Half moon nut 16mm hole plugs...
- Page 12 ITM/D520- Rev.001 Ringed Nails 12x12mm Recommended evenly distributed maximum weights.
