ICO Kontour K3023E Installation Manual

Kontour Angle
Towel Warmer
Installation Guide
Code: K3023E
24" x 39" Electric Plug-In
1

Rough-in Requirements

1. Your towel warmer requires 110V power. This 110V receptacle should be located no further than 18" from the
electric plug-in exit location (see Fig 2), and not above the electric plug-in exit location.
2. Wall studs or plywood backing is recommended in the wall at all bracket locations. See Fig 2 for bracket locations.
2

Installation Instructions

1. Check all items have been received. Read all instructions before continuing.
2. Fix wall supports "A" to the wall using the screws provided and in locations as shown
on figure 2.
3. Hang and adjust the Towel Warmer using set screws "B" to lock stud "C" in the wall
bracket "A". Ensure the Towel Warmer is firmly and safely fixed.
3

Electric Plug-In Connection

TURN OFF POWER SUPPLY BEFORE PROCEEDING
Do not connect the Towel Warmer to the power supply until all instructions have been read and installation carried out in
accord with them. Your towel warmer is 165W (110V) and conforms to CSA standards (File ref: 2422531). Please
ensure the CSA label is visible.
1. Turn off power supply.
2. Plug connector in.
3. Switch on power supply.
Warning: In case of damage or failure of the Towel Warmer the unit should be returned to the manufacturer or their
distributor. The warranty of 2 years on the Towel Warmer is NOT VALID in case of improper use or installation. Product is
designed for use within Canada and the United States only.
1-877-757-8930
(see figure 2)
(see figure 1)
fig. 1
A
C
B
www.kontour.ca
