- Page 1 EcoPure ® Cartridge Filter INSTALLATION & OPERATING INSTRUCTIONS 50sqft 75sqft 100sqft 150sqft IMPORTANT: PLEASE READ THIS DOCUMENT CAREFULLY. Please pass these instructions on to the operator of this equipment. davey.com.au...
- Page 2 INTRODUCTION The installation of this product should be carried out by a person knowledgeable in swimming pool plumbing requirements following the Installation Instructions provided in this manual. Please pass these instructions on to the owner of this equipment. YOUR MONARCH SERIES CARTRIDGE FILTER Congratulations on your purchase of a quality product from the Monarch Series range of Pool and Spa Equipment.
-
Page 3: Weather Protection
INSTALLATION & OPERATING INSTRUCTIONS LOCATION The filter should be placed in its permanent location, preferably as close to the pool as practicable. Position the filter tank and pump on a level concrete slab or similar base. Allow sufficient space around the filter for routine maintenance and provide for adequate ventilation and drainage. -
Page 4: Filter Operation
1. PUMP TO THE FILTER Monarch Series Cartridge Filters are equipped with two inlet ports marked ‘INLET’. Select the inlet port most suitable for the installation and plug the other inlet port with the blanking cap provided. Using the barrel unions provided, connect the pool pump delivery piping to the selected inlet port. -
Page 5: Cartridge Cleaning Procedure
CARTRIDGE CLEANING PROCEDURE gauge reading, cleaning the element cartridge is required. To perform the cleaning procedure : fitted. and remove the filter lid. Lift the element out. In most cases the element can be easily cleaned with a garden hose, using good velocity sprayed directly on the pleats. NOTE: Algae, calcium, clay, sun tan oil and body oils can form a coating on the element which may not be easily removed with normal hosing. -
Page 6: Troubleshooting
FILTER CARE The Monarch Series Cartridge Filter is the heart of the pool equipment installation. Proper care and maintenance will add many years of service and enjoyment to your pool. Keep the exterior of the filter clean using a mild detergent and water. TROUBLE SHOOTING Reduced flow of water to the pool generally indicates the filter is ready to be cleaned. - Page 7 NOTE: When making any enquiries about your Davey Filtration Equipment, be certain to quote the Model Number from the nameplate on the equipment. To avoid explosion and possible severe or fatal injury, filter pressure must not exceed 280kPa. Do not test filter with compressed air.
- Page 8 Routine Maintenance tasks – to maximise the life of your pool equipment & personal safety, use this checklist once a week. Turn pump off first. a. Make sure that any pressure gauges are in working condition and the operating pressure is within limits as specified on the product.
-
Page 9: Specifications
SPECIFICATIONS D = Clearance to remove cartridge TECHNICAL DATA Filtration Flow Operating Area Filtration Rate 4 Hour 6 Hour Operating Temp (sq metres) Area Model (lpm) Turnover Turnover Pressure (kPa) (°C) (sq feet) DIMENSIONS (mm) Model All dimensions in mm unless otherwise stated. - Page 10 Member of the GUD Group ABN 18 066 327 517 Web: www.rainbowpoolproducts.com.au ® Davey & EcoPure are registered trade marks of Davey Water Products Pty Ltd. © Davey Water Products Pty Ltd 2011. P/N Q916334-2 supersedes P/N Q916334-1 * Installation and operating instructions are included with the product when purchased new.
