  • Page 1 K-FRAME VIDEO PRODUCTION FRAMES Video Production Center Installation Planning Guide 13-00006-000AA 5/3/17...
  • Page 2 Belden Inc. or its affiliated companies in the United States and other jurisdictions. Grass Valley, K-Frame, Kayenne, Karrera, and GV Korona are trademarks or registered trademarks of Grass Valley USA, LLC. Belden Inc., Grass Valley USA, LLC, and other parties may also have trademark rights in other terms used herein.

  • Page 3: Symbols And Their Meanings

    K-Frame Installation Planning Guide Important Safeguards and Notices Symbols and Their Meanings ............iii Warnings .

  • Page 4: Warnings

    Notices The presence of this symbol in or on Grass Valley equipment means that it has been tested and certified as complying with applicable Intertek Testing Services regulations and recommendations for USA/Canada. The presence of this symbol in or on Grass Valley product means that it complies with all applicable European Union (CE) directives.

  • Page 5: Cautions

    K-Frame Installation Planning Guide Cautions Important Safeguards and Notices ........... . iii A caution indicates a possible hazard to equipment that could result in equipment damage.
  • Page 6 Notices Battery Handling This product includes a backup battery. There is a danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions.
  • Page 7 K-Frame Installation Planning Guide Identifie une borne de mise à la terre externe qui peut être connectée en tant que borne de mise à la terre supplémentaire. Signale la présence de composants sensibles à l’électricité statique et qui sont susceptibles d’être endommagés par une décharge électrostatique. Utilisez des procédures, des équipements et des surfaces antistatiques durant les interventions d’entretien.
  • Page 8 Notices • Cet équipement est mis à la terre par le conducteur de mise à la terre des cordons d’alimentation. Pour éviter les chocs électriques, branchez les cordons d’alimentation sur une prise correctement câblée avant de brancher les entrées et sorties de l’équipement.
  • Page 9 K-Frame Installation Planning Guide • L’appareil peut comporter plus d’un cordon d'alimentation.  Afin de prévenir les chocs électriques, débrancher tous les cordons d'alimentation avant toute opération d’entretien. • Veillez à toujours prendre les mesures de protection antistatique appropriées quand vous manipulez l’équipement. Protection contre les décharges électrostatiques (DES) Une décharge électrostatique peut se produire lorsque des composants électroniques ne sont pas manipulés de manière adéquate, ce qui peut entraîner...
  • Page 10 Notices Recycling Visit www.grassvalley.com for recycling information. Certification and Compliance Safety Compliance ..............x Restriction on Hazardous Substances (RoHS) .
  • Page 11 K-Frame Installation Planning Guide Restriction on Hazardous Substances (RoHS) Restriction of Hazardous Substances (RoHS) KAYN-2-25-2M-KC, KAYN-2-25-3M-KC, KAYN-3-35- (Toxic or hazardous Substances and Elements) 3M-KC, KAYN-3-35-4M-KC, KAYN-3-35-4M-KS, KAYN- 3-35-5M-KS, KAYN-4-35-4M-KS, KAYN-4-35-5M-KS, KAYN-PNL-100-15, KAYN-PNL-200-25, KAYN-PNL- 200-35, KAYN-PNL-300-25, KAYN-PNL-300-35, KAYN- PNL-400-25, KAYN-PNL-400-35, KOR-1-15-1M-KCS, KOR-2-20-2M-KCS, KRR-2-25-2M-KC, KRR-2-25-C-...
  • Page 12 Notices K-FRM-CTRL-CS, K-FRM-INPUT, K-FRM-IO, K-FRM- IO-10GE, K-FRM-ME-DPM-S, K-FRM-OUTPUT and (Pb) (Hg) (Cd) KRR-PRO-PS (PBB) (PBDE) (Cr6) Part name Circuit Modules Metal Parts (Toxic or hazardous Substances and Elements) KOR-PNL-LAN-20 Part name (Pb) (Hg) (Cd) (PBB) (PBDE) (Cr6) Cables and Cable Assemblies (Toxic or hazardous Substances and Elements) KOR-PNL-KIT Part name...
  • Page 13 K-Frame Installation Planning Guide • EN 61000-4-2 Electrostatic discharge immunity • EN 61000-4-3 Radiated, radio-frequency, electromagnetic field immunity • EN 61000-4-4 Electrical fast transient immunity • EN 61000-4-5 Surge transient immunity • EN 61000-4-6 Conducted disturbances immunity • EN 61000-4-8 Power frequency magnetic field immunity •...
  • Page 14 Notices...

  • Page 15: Table Of Contents

    Table of Contents 1 Introduction ......... . . 1 Overview.
  • Page 16 Table of Contents K-Frame V-series Controller Connections and Status Indicators.....30 K-Frame V-series Video Processor Rear View ........30 K-Frame 13-RU Power Supply AC Requirements .
  • Page 17 K-Frame Installation Planning Guide RS-232 Port Pin Assignments............60 Appendix A Specifications .
  • Page 18 Table of Contents xviii...

  • Page 19: Introduction

    Introduction Overview The Grass Valley K-Frame family of multi-format digital production switchers provides powerful, ground-breaking features designed to meet the widest range of requirements for live studio, mobile, and post-production applications. The following K-Frame Video Processors are the heart of the system, providing extensive video switching and signal processing capabilities: •...

  • Page 20: K-Frame Standard Frame

    Introduction K-Frame Standard Frame • Interfaces with Grass Valley routers and Kaleido Multiviewers and their control systems. • Optional Integrated Image Store capable of delivering up to 64 GB storage (up to 32GB for S-series and V-series) of Stills (3,000 images) or “Movies” (up to 50 seconds) of 1080p video.

  • Page 21: K-Frame Compact S-Series Frame

    K-Frame Installation Planning Guide • Every M/E has six keyers with standard keying modes including Chroma Key, two frame stores per keyer—every keyer except for Controller M/E can use the pool of optional floating 3D iDPMs. • 2D-DPMs (resizers) on every keyer, with 6 Video/Key pairs per M/E. •...
  • Page 22 Introduction Kayenne Control Surface 4-ME 35 Control Panel Menu Panel Menu Panel Articulated Optional Module Optional Device Control Module Panel Control Unit (PCU) Kayenne 4-M/E 35 Control Surface 3-ME 35 Control Panel Menu Panel Menu Panel Optional Device Articulated Control Module Panel Control Unit (PCU) Kayenne 3-M/E 35 Control Surface 2-ME 25 Control Panel...

  • Page 23: Flat Or Curved Control Panel Orientation

    K-Frame Installation Planning Guide Flat or Curved Control Panel Orientation The main Kayenne Control Panel supports different physical orientations. Besides a conventional flat surface, a special support design permits a curved working surface, where the M/Es progressively tilt for improved ergonomics. Curved Control Panel Assembly Flat Control Panel Assembly Curved and Flat Control Surface Installations...

  • Page 24: Menu Application

    Introduction Menu Application The Menu Panel has four USB ports, two on the right side edge of the panel and two on the back for keyboard and mouse (wired or wireless are supported). Menu Panel with Articulated Arm Menu Application The Menu application software provided with every K-Frame system can be run on a standard PC.

  • Page 25: Karrrera Control Surface

    K-Frame Installation Planning Guide for independent building and running of macros by each operator at the control surface. Hardware resources in the Video Processor Frame can be assigned to an individual suite during configuration, essentially creating two separate switchers sharing one frame. Suite 1 4-ME 35 Kayenne Control Panel Menu Panel...

  • Page 26: Touch Screen Menu Panel Option

    Introduction Touch Screen Menu Panel Option Karrera 3-ME 35 Control Panel Menu Panel Articulated Optional Touch Screen Karrera Menu Panel with Fanless PC Karrera 3-M/E 35 Control Surface Karrera Menu on PC Karrera 2-ME 25 Control Panel (Customer Supplied PC) Karrera 2-M/E 25 Control Surface Touch Screen Menu Panel Option A hardware Karrera Menu Panel is available as an option, which features a wide format 15...

  • Page 27: Karrera K-Frame System Examples

    K-Frame Installation Planning Guide Karrera K-Frame System Examples Basic Single Suite Karrera Panel System A basic K-Frame system consists of a Control Panel, a Menu application running on a PC, and a Video Processor Frame. The Control Panel and Menu application make up a control surface associated with that frame.

  • Page 28: Gv Korona Control Surfaces

    Introduction GV Korona Control Surfaces Suite 1 Karrera 3-ME 35 Control Panel Optional Touch Screen Karrera Menu Panel with with Fanless PC and Articulated Arm KSP 1-ME Standard 13-RU Soft Panel Option K-Frame (Keyboard Included) (Customer Supplied PC) Suite 2 Karrera Menu on PC Karrera 2-ME 25 Control Panel (Customer Supplied PC)

  • Page 29: Basic Single Suite Gv Korona Panel System Example

    K-Frame Installation Planning Guide GV Korona Control Surfaces Basic Single Suite GV Korona Panel System Example A Basic K-Frame GV Korona system consists of a Control Panel with a fully integrated multi- touch menu system and an S-series 6RU Frame. GV Korona 2-ME 20 Control Panel K-Frame V-series 3-RU GV Korona Single Suite S-Series Frame Example...
  • Page 30 Introduction Multiple Suites and Control Surfaces Example Suite 1 3-ME 35 Kayenne Control Panel Menu Panel Menu Panel Optional Device Articulated Control Module Panel Control Unit (PCU) 2-ME 20 GV Korona Control Panel Standard 13-RU K-Frame Suite 2 Karrera Menu on PC 2-ME 25 Karrera Control Panel (Customer Supplied PC) K-Frame Multi-Suite Frame Example...

  • Page 31: Soft Panel (Ksp) Option

    K-Frame Installation Planning Guide Soft Panel (KSP) Option Soft Panel Application The KSP is an optional 1-M/E Soft Panel GUI which provides direct control of switching crosspoints, recalling effects and macros together with an integrated version of the Menu application. A customized PC keyboard is included with the option for users who like quick cut and mix action from a hard-button interface.

  • Page 32: Supported Control Protocols

    Introduction Supported Control Protocols Supported Control Protocols • PBus II • Grass Valley CPL (Control Point Language) for Control Panel, Menu, Frame, and Automation systems • GPI Inputs and Outputs • Serial BVW-75 for VTR control • Odetics protocol for VTR control •...

  • Page 33: Frame Installation

    Frame Installation 13-RU Video Processor Dimensions 482 mm 19.0 in. 460 mm 18.1 in. 439 mm 17.3 in. 577 mm 22.7 in. K-Frame 13-RU Dimensions (Front View) CAUTION: Mounting a K-Frame in a rack immediately below equipment that extends forward from the rack may not provide enough clearance to completely remove the K-Frame door.
  • Page 34 Frame Installation 13-RU Video Processor Dimensions 442 mm 17.4 in. 566 mm 22.3 In. 602 mm 23.7 in. 37 mm 1.5 in. 483 mm 19.0 in. K-Frame 13-RU Dimensions (Top View)

  • Page 35: 13Ru Video Processor Installation And Airflow

    K-Frame Installation Planning Guide 13RU Video Processor Installation and Airflow CAUTION: K-Frame installations require the use of the provided rear rack supports. Rear Rack Support Air Exhaust (Chassis Top) Rear Rack Support Intake (Chassis Bottom) Intake (Chassis Bottom) K-Frame 13-RU Rack Mounting and Cooling Airflow 13RU Video Processor Views CAUTION: The Video Processor front door must remain in place and closed during normal system operation to maintain...
  • Page 36 Frame Installation 13RU Video Processor Views Image Store ME C1 & C2 ME B1 & B2 Controller ME D1 & D2 with ME ME A1 & A2 Assembly IMAGE STORE ME D1 & D2 ME C1 & C2 CONTROLLER & ME ME B1 &...

  • Page 37: K-Frame 13-Ru Power Supply Views

    K-Frame Installation Planning Guide Output Video Input Video (16 pairs of identical (32 inputs, outputs each) 8 GPI in/out, and 24 Tally) Up to 4 modules Up to 5 modules CAUTION Turn off power before removing or installing Control I/O in slot R6. Mod I/O 1 Mod I/O 3 Mod I/O 5...
  • Page 38 Frame Installation K-Frame 13-RU Power Supply Views Front View with Cover 482 mm 19.0 in. 44 mm 1.72 in. Power Modules (up to 3) Front View Cover Removed DC Power Out Rear View Grounding Lug AC Input IEC C19 (3) (to K-Frame) 38 mm 1.5 in.

  • Page 39: K-Frame 13-Ru Power Supply Frame Rack Installation And Airflow

    K-Frame Installation Planning Guide 442 mm 17.4 in. 466 mm 18.3 in. 449 mm 17.7 in. 265 mm 490 mm 10.4 in. 19.2 in. 448 mm 41 mm 17.6 in. 1.6 in. 483 mm 19.0 in. K-Frame 13RU Power Supply Frame Dimensions (Top View) K-Frame 13-RU Power Supply Frame Rack Installation and Airflow The K-Frame power supply frame is ideally rack mounted immediately above the 13-RU Video Processor chassis.

  • Page 40: K-Frame 13-Ru Power Supply Cooling

    Frame Installation K-Frame 13-RU Power Supply Cooling Exhaust Power Supply Frame Intake K-Frame Chassis 13-RU K-Frame Power Supply Rack Installation and Cooling Airflow Rear Rack Support Exhaust Rear Rack Support Intake Isolated K-Frame 13-RU Power Supply Rack Installation K-Frame 13-RU Power Supply Cooling The top surface of the rear of the K-Frame Power Supply Frame has air holes and is slightly recessed, which permits air flow even if equipment is mounted in the rack directly above.

  • Page 41: 6-Ru Video Processor Dimensions

    K-Frame Installation Planning Guide These top recessed air holes must remain open for proper cooling. Ensure paper or other obstructions do not block these air holes. 6-RU Video Processor Dimensions 482 mm 19.0 in. 460 mm 18.1 in. 439 mm 17.3 in.
  • Page 42 Frame Installation 6-RU Video Processor Dimensions 442 mm 17.4 in. 596 mm 22.0 In. 559 mm 23.5 in. 37 mm 1.5 in. 483 mm 19.0 in. K-Frame 6-RU Dimensions (Top View)

  • Page 43: 6Ru Video Processor Installation And Airflow

    K-Frame Installation Planning Guide 6RU Video Processor Installation and Airflow CAUTION: K-Frame installations require the use of the provided rear rack supports. Rear Rack Support Exhaust Rear Rack Support Intake K-Frame 6-RU Rack Installation and Cooling Airflow 6RU Compact S-series Front View with Door Removed The Compact S-series Frame includes four keyers per M/E and two Multiviewers on the Controller board.

  • Page 44: 6Ru Compact Front Views With Door Removed

    Frame Installation 6RU Compact Front Views with Door Removed ME A ME B Controller Assembly Front Slots F1 - F4 K-Frame Compact S-series 6-RU, Front View with Door Removed 6RU Compact Front Views with Door Removed The Compact Frame includes optionally, an Image Store board and six keyers per M/E. ME A ME B Controller...

  • Page 45: 6Ru Video Processor Rear View

    K-Frame Installation Planning Guide 6RU Video Processor Rear View Input Video Output Video Control I/O (32 inputs, (16 outputs) (Reference,Ethernet 8 GPI in/out, and 24 Tally) Up to 2 modules and Serial ports) Up to 2 modules Power Supply Modular I/O Up to 4 modules Module 4 Module 1...

  • Page 46: 3Ru Video Processor Dimensions

    Frame Installation 3RU Video Processor Dimensions Ethernet (6) (communications) SERIAL PORTS RS422/485 LINK/ACTIVITY OFF-10/AMBER-100/GREEN-1000 ANALOG REFERENCE Serial Ports (8) Reference RS422/485 Illuminated LED indicates Port 1 is in diagnostic mode Controller I/O Connections, Rear of Chassis 3RU Video Processor Dimensions 482.6 mm 19.0 in.

  • Page 47: 3Ru Video Processor Installation And Airflow

    K-Frame Installation Planning Guide 3RU Video Processor Installation and Airflow CAUTION: K-Frame installations require the use of the provided rear rack supports. Exhaust Rear Rack Support x2 Exhaust Intake 3RU Front Views with Door Removed The V-series Frame Fan Assembly is removed to access the Controller/Image Store, M/E and other boards.

  • Page 48: K-Frame V-Series Controller Connections And Status Indicators

    Frame Installation K-Frame V-series Controller Connections and Status Indicators The V-series Frame includes a Controller/Image Store board, an M/E board, with four keyers per licensed M/E and VPE. Note: Slots are keyed to prevent damage resulting from boards being installed in the wrong slots. K-Frame V-series 3-RU, Front View with Door and Fan Assembly Removed K-Frame V-series Controller Connections and Status Indicators Test Points...

  • Page 49: K-Frame 13-Ru Power Supply Ac Requirements

    K-Frame Installation Planning Guide K-Frame V-series 3-RU, Rear View Ethernet (6) (communications) Console Ports Serial Ports (4) Illuminated LED indicates RS232 RS422/485 Port 1 is in diagnostic mode Controller I/O Connections, Rear of Chassis Sync Reference Tally/GPI MediaPort (2) Reference I/O Connections, Rear of Chassis K-Frame 13-RU Power Supply AC Requirements The K-Frame 13-RU Power Supply Frame has provision to support up to three hot swappable power modules.

  • Page 50: K-Frame V-Series Power Supply Ac Requirements

    Frame Installation K-Frame V-series Power Supply AC Requirements cells can have a module installed. Each cell has its own AC line cord. The supplies are power factor corrected and automatically accommodate low line (120V nominal) or high line (240V nominal). The power supplies have a rating of 100 – 240 volts, although it is designed and tested for a range of 90 to 264 volts to accommodate under and over voltage conditions.

  • Page 51: System Cabling

    System Cabling About the K-Frame System Cabling Section This section provides overview information that is common to all K-Frame systems as well as information specific to Kayenne, Karrera, and GV Korona K-Frame Control Panels and components. K-Frame System Cabling Overview The K-Frame systems use Ethernet, serial, and USB connections and custom multi-pin cables for Kayenne.

  • Page 52: Customer Supplied Ethernet Routers And Switches

    System Cabling Customer Supplied Ethernet Routers and Switches Customer Supplied Ethernet Routers and Switches Existing facility Ethernet switches can be used in conjunction with a Kayenne system. If connecting to a network area outside that used by the Kayenne system, use of an appropriately configured Ethernet Router is strongly advised.

  • Page 53: Kayenne K-Frame System Cabling

    K-Frame Installation Planning Guide K-Frame System Default IP Addresses Devices IP Address Control Panel Surface 1B 192.168.0.177 Control Panel Surface 2A 192.168.0.178 Control Panel Surface 2B 192.168.0.179 Clip Store 192.168.0.180 Kayenne/Karrera only: IP Address: 192.168.1.2 32-Crosspoint Remote Aux Panels Frame IP: 192.168.1.1 V1.6.5 and higher software: Gateway IP: 192.168.1.1 (hard reset with the front panel buttons)

  • Page 54: Kayenne Network Cabling

    System Cabling Kayenne Network Cabling Menu Panel Kayenne PCU K-Frame Video Processor RS-422/485 Menu Video Keyboard, VGA GPI In/Out Processor Hard RS-232 Tally Disk Kayenne Control Panel Keyboard, VGA Internal Control Menu RS-23 Local Aux Stripe Hard Image Store (option) Disk ME Stripe ME Stripe...

  • Page 55: Kayenne Suites And Control Surfaces

    K-Frame Installation Planning Guide communications throughput (to support Image Store file operations) and also offers redundancy. Because the Menu Panel and the Control Panel have independent cable connections, failure of one of these cables will not completely disable the K-Frame system. Either the Menu Panel or the Control Panel will remain operational after a single network cable failure.

  • Page 56: Kayenne Control Panel Cabling

    System Cabling Kayenne Control Panel Cabling Ethernet Kayenne PCU 1 K-Frame Video Processor (100m / 300ft max single hop length, unlimited distance using switches) Kayenne Suite 1 Menu Video Menu Panel Processor Internal Control Kayenne Control Panel Menu Image Store Local Aux Stripe (option) ME Stripe...

  • Page 57: Kayenne Satellite Panel Cabling

    K-Frame Installation Planning Guide mapped, but this order matches the default configuration. The table below shows the connections for various Kayenne Control Panel models used in a single suite. PCU Port to Control Panel Stripe Connections, Single Suite Control Panel Model PCU Port Panel Stripe 4-M/E with Local Aux...

  • Page 58: Kayenne Touch Screen Menu Panels (Used With Pcu)

    System Cabling Kayenne Touch Screen Menu Panels (Used with PCU) The Single Module Satellite Panel has internal module cabling the same as the other Stripes. Simply plug the module into a port using the provided cable. The Double Module Satellite Panel has a similar internal cabling arrangement, but one cable passes through a hole to the other tray.

  • Page 59: Karrera Control Panel Network Cabling

    K-Frame Installation Planning Guide Suite Boundary Suite 1 Ethernet Menu Ethernet Menu Panel (100m / 300ft max single hop length, unlimited distance using switches) DVI-D K-Frame Video Processor Ethernet LAN Switch Karrera Control Panel, Suite 1 RS-422/485 Video GPI In/Out Processor Tally Keyboard, VGA...

  • Page 60: Optional Karrera Local Aux Panel Cabling

    System Cabling Optional Karrera Local Aux Panel Cabling Touch Screen Menu Panel Bottom View Power Supply (80 watts) Power Source Fanless PC USB 2.0 Port Ethernet (front side Connector DVI-D 90 deg.) Type B (straight) Switcher Network Power Input Karrera Control Panel (rear) DVI-D (rear side 90 deg.)
  • Page 61 K-Frame Installation Planning Guide Karrera Control Panel (rear) 12 Volt Panel to DC Out Local Aux Control Redundant AC (not Ethernet) Power Sources (2) Switcher Ethernet Network Karrera Local Aux Panel Use tiewrap for cable strain relief. 12 Volt DC In Local Aux Panel Cabling GV Korona K-Frame System Cabling The GV Korona K-Frame system uses Ethernet connections for communications.

  • Page 62: Gv Korona Suites And Control Surfaces

    System Cabling GV Korona Suites and Control Surfaces K-Frame Video Processor RS-422/485 Video GPI In/Out Processor Tally GV Korona Control Panel Keyboard, VGA Internal Control RS-232 Image Store Operator’s Laptop Clip Store Disable Internet or Wireless Connections Remote Aux Panel Facility LAN Ethernet Switch...

  • Page 63: About K-Frame Video Cabling

    K-Frame Installation Planning Guide Suite Boundary Suite 1 Ethernet Ethernet (100m / 300ft max single hop length, unlimited distance using switches) K-Frame Video Processor Ethernet LAN Switch Korona Control Panel, Suite 1 RS-422/485 Video GPI In/Out Processor Tally Keyboard, VGA Internal Control RS-232 Operator’s...

  • Page 64: Inputs/Outputs Standard, Compact, S-Series Frames

    System Cabling Inputs/Outputs Standard, Compact, S-series Frames Inputs/Outputs Standard, Compact, S-series Frames Inputs Standard, Compact, S-series Non-looping video inputs on the back of the Video Processor Frame are numbered 1 through 32 on each input module. Each accepts a 270 MHz, 1.485 Gb, or 3 Gb serial digital video signal.

  • Page 65: Reference Input Standard, Compact, And S-Series

    K-Frame Installation Planning Guide Reference Input Standard, Compact, and S-series The K-Frame Video Processor has digital referencing that can lock to any digital input video signal or one analog looping reference input. Each can be used with any SD/HD/3G/4K standard. For the analog looping reference input, 75-ohm termination of the looping input can be used either directly, on the adjacent connector, or at the end of a daisy chain looping to other equipment.

  • Page 66: K-Frame System Video Timing And Delay

    System Cabling K-Frame System Video Timing and Delay • 1920x1080i 25/29.97/30 Hz Note: HDCP is not supported. K-Frame System Video Timing and Delay The total delay of a video input to the switcher output can vary according to the relationship of the input to the switcher reference. The switcher will automatically autotime inputs that fall within an autotiming window.

  • Page 67: Timing Analyzer

    K-Frame Installation Planning Guide • For inputs entering the switcher in zero time with the reference, the total delay through the switcher is the Nominal Switcher Delay (A μs). • Inputs that reach the switcher at the latest point in the autotiming window (+B μs) will have a total delay that equals the time required for switcher processing.

  • Page 68: Time Zones And The Autotiming Window

    System Cabling Time Zones and the Autotiming Window K-Frame systems have an autotiming window. Sources that fall within that window will be properly timed throughout the Kayenne K-Frame system, even if the signal is cascaded through multiple M/Es. The Switcher Horizontal and Switcher Vertical soft knobs adjust the timing of the Kayenne K-Frame system relative to the incoming reference.

  • Page 69: Clipstore Cabling

    K-Frame Installation Planning Guide Any source fed to the switcher must be within the autotiming range of all six time zones. If not, the source will be in time on some M/Es but not on others. As illustrated in the figure, a source centered in one time zone’s autotiming range can be too early or late for other switcher time zones.
  • Page 70 System Cabling ClipStore Video Cabling ClipStore (4 Channel Summit) C1 SDI IN 1 C1 SDI IN 2 Channel 1 C1 SDI OUT 1 C1 SDI OUT 2 C2 SDI IN 1 C2 SDI IN 2 Channel 2 C2 SDI OUT 1 C2 SDI OUT 2 K-Frame Video Processing...

  • Page 71: Video Processor Frame Gpi/Relay Tally Interface

    K-Frame Installation Planning Guide ClipStore (Summit) Aux Bus Out/Video to DA (odd) Aux Bus Aux Bus Out/Key to DA (even) Pair Out Channel 1 Channel 2 K-Frame Video Processing Frame Video/Key Channels In Channel 3 Channel 4 ClipStore Connection Using Distribution Amplifiers Video Processor Frame GPI/Relay Tally Interface The GPI (General Purpose Interface) and relay tally interface provides a means to transfer commands to and from the switcher to external devices.

  • Page 72: Gpi Inputs

    System Cabling GPI Inputs software and the relay tally is driven by the Relay Tally system software. Relay tally connections can be used to trigger GPIs on external devices. GPI Inputs The purpose of the GPI In pins is to provide a stimulus from the external devices to the switcher.

  • Page 73: Relay Tally/Gpi Outputs

    K-Frame Installation Planning Guide + 3.3 V Opto Isolator 50-pin Connector (1 of 8) Pin Numbers 150 ohm GPI IN 1 Open Collector + 3.3 V Opto Isolator (5 of 8) 150 ohm GPI IN 5 Ground and Chassis User Equipment Video Processor Frame GPI Input Connections (Typical 2 of 8 Connections Relay Tally/GPI Outputs...
  • Page 74 System Cabling Relay Tally/GPI Outputs 50-pin Connector Pin Numbers Tally1A Tally2A Logic Tally3A Tally4A Common A Tally5B Tally6B Common B 12V Lamp GPIOut3G GPIOut4G Common G 12V Lamp GPIOut5H GPIOut6H 12V Lamp GPIOut7H GPIOut8H + 12V DC Common H Video Processor Frame User Equipment Relay Tally and GPI Output Connection Example Although the diagram shows mechanical relays, the actual outputs are implemented with...

  • Page 75: Gpi In, Gpi Out, Relay Tally Pin Assignments

    K-Frame Installation Planning Guide Relay Tally and GPI Output Specifications Maximum off (open circuit) voltage between output and 60 Volts peak common Maximum voltage between any point and ground (chassis) 60 Volts peak GPI In, GPI Out, Relay Tally Pin Assignments Each Input Module has a 50 pin connector for GPI and Relay Tally.
  • Page 76 System Cabling GPI In, GPI Out, Relay Tally Pin Assignments D-50 Female Pin 18 Pin 1 Pin 34 Pin 33 Pin 17 Pin 50 Socket Pinout GPI Signals IMPORTANT: For V-series, use the column labeled “1” only. GPI In, Tally, GPI Out Signals Ribbon 50-Pin D- Cable...
  • Page 77 K-Frame Installation Planning Guide GPI In, Tally, GPI Out Signals Ribbon 50-Pin D- Cable Tally6B Tally30K Tally54T Tally78AB Tally102AH Tally7B Tally31K Tally55T Tally79AB Tally103AH Tally8B Tally32K Tally56T Tally80AB Tally104AH TallyComC TallyComL TallyComU TallyComAC TallyComAJ Tally9C Tally33L Tally57U Tally81AC Tally105AJ Tally10C Tally34L Tally58U Tally82AC...

  • Page 78: Rs-422/485 Port Pin Assignments

    System Cabling RS-422/485 Port Pin Assignments RS-422/485 Port Pin Assignments Eight RS-422/485 ports (four for V-series) are available on the rear of the K-Frame Video Processor, and can be used to control various devices, or for switcher control by an external controller.
  • Page 79 K-Frame Installation Planning Guide...
  • Page 80 System Cabling RS-232 Port Pin Assignments...

  • Page 81: Appendix A Specifications

    Specifications K-Frame Video Processor Specifications K-Frame Video Standards 3G Modes 1080p 50/59.94/60, Level A and SMPTE 424M-2006 Level B HD Modes 1080i 29.97/30 SMPTE 274M Tables 4 and 5 1080i 25 SMPTE 274M Tables 6 1080psf 23.976/24/25/29.97 SMPTE RP211 Table 12-16 720p 50/59.94/60 SMPTE 296 Table 1-3 SD Modes...
  • Page 82 Specifications K-Frame Video Processor Specifications K-Frame Environmental Storage temperature -20 to 70 C (-4 to 158 F) Operating temperature 0 to 40 C (32 to 104 F) Relative humidity 0-95% (non-condensing) Electromagnetic environment E2 (according to EN55103-1 and -2 K-Frame Network Connections Type of connection 10/100/1000 Base T Protocol...
  • Page 83 K-Frame Installation Planning Guide K-Frame—Number of M/Es, Inputs, and Outputs GPI/Tally Smart I/O Modules Frame M/Es Inputs Outputs GPI Inputs Outputs (MatchDef/SetDef V-series 3-RU 1 to 5 8 to 32 SDI, 1-4 4-16 with 2 8 per Frame 32 per Media Ports Media Ports Frame...
  • Page 84 Input Impedance 75 ohm Max cable length SD Video 350 meters (1148 ft.) using Belden 1694A type cable HD Video 200 meters (656 ft.) using Belden 1694A type cable 3G Video 140 meters (459 ft.) using Belden 1694A type cable...

  • Page 85: Appendix B Regulatory Notices

    Regulatory Notices Certifications and Compliances FCC Emission Control This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 86: Fcc Emission Limits

    Regulatory Notices FCC Emission Limits FCC Emission Limits This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may no cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesirable operation.

  • Page 87: Dekra Certificate

    K-Frame Installation Planning Guide Category Standard Designed/tested for compliance with: EMC Directive 2004/108/EC Audio, Video and Entertainment Lighting Control for the via EN 55103-1 and 2 European Community. EN55103-1 : 2009 Electromagnetic compatibility. Product family standard for audio, video, audio-visual and entertainment lighting control apparatus for professional use.
  • Page 89 Contact Us Grass Valley Technical Support For technical assistance, contact our international support center, at 1-800-547-8949 (US and Canada) or +1 530 478 4148. To obtain a local phone number for the support center nearest you, please consult the Contact Us section of Grass Valley’s website ( www.grassvalley.com An online form for e-mail contact is also available from the website.
