- Page 1 SUNNEX MEDICAL LIGHT TRI-STAR INSTALLATION AND SERVICE MANUAL MOBILE WALL TS2035M, TS2015M TS2035W, TS2015W...
-
Page 2: Table Of Contents
READ ALL INSTRUCTIONS BEFORE ASSEMBLY AND USE IF YOU DON’T UNDERSTAND ANY GUIDELINES IN THIS MANUAL, CALL DISTRIBUTOR OR MANUFACTURER DO NOT USE THIS LIGHT IF IT IS DAMAGED, BROKEN, OR HAS MISSING PARTS Sunnex TRI-STAR Service & Installation Manual... -
Page 3: Shipping Carton & Contents
Allen wrench (5/32) Aluminum cylinder CAREFULLY CHECK THE CONTENTS OF THE SHIPMENT. REPORT SHORTAGES AND/OR ERRORS, TO SUNNEX OR YOUR DEALER’S CUSTOMER SERVICE DEPARTMENT, W ITHIN FIVE (5) W ORKING DAYS. ALL FREIGHT CLAIMS BY EITHER THE DEALER OR CONSIGNEE SHOULD BE FILED W ITH THE TRANSPORTATION COMPANY W ITHIN FIVE (5) W ORKING DAYS. - Page 4 2.1 APPLICATIONS The Sunnex TRI-STAR offers an economical alternative to traditional examination lights. 2.2 TECHNICAL DATA This light is certified according to the following standards: CAN/CSA-C22.2 No. 601.1-M90 EN 60601-1, UL 60601-1, IEC 60601-2-41 Power Supply: 120V 60Hz or 230V 50Hz...
-
Page 5: Operation
Once in place, push down on the metal collar to properly seat the connection. CAUTION: IF YOU DO NOT FEEL A POSITIVE SEATING, PROPER CONNECTION HAS NOT BEEN ACCOMPLISHED. CHECK AGAIN TO ENSURE YOU HAVE SECURELY CONNECTED THE LAMP HEAD ASSEMBLY TO THE UPRIGHT COLUMN. Sunnex TRI-STAR Service & Installation Manual... -
Page 6: Assembly And Installation Of Tristar Wall
U-bracket and place plastic washers so that washers are between U-bracket and end of arm. Secure arm end to U-bracket with countersunk screws (2 X 1/4”-20), use provided Allen key (5/32). (See following illustrations). END OF EXTENSION Sunnex TRI-STAR Service & Installation Manual... -
Page 7: About Your Tri-Star
The lamp head rotates 359 degrees in either direction at the point at which it attaches to the vinyl-coated arm. The control of its movement is via the handles built into the lamp head frame. Sunnex TRI-STAR Service & Installation Manual... -
Page 8: Care For Your Tri-Star Light
While your TRI-STAR has been designed to provide many hours of professional performance, it will benefit from your periodic care and cleaning. Sunnex TRI-STAR Service & Installation Manual... -
Page 9: Service And Maintenance
. A qualified technician must perform any repairs to the lamp or the lamp can be returned to the Sunnex, LLC for repair. 8.1 BULB REPLACEMENT Sunnex TRI-STAR Service &... - Page 10 Press gently inward as you twist the assembly clockwise. You will hit a stop and set in place. 11. The light is now ready for use. Sunnex TRI-STAR Service & Installation Manual...
-
Page 11: Warranty
9. WARRANTY Limited Warranty Sunnex warrants that the Product, if properly used, will be free from defects in material and workmanship, for a period of three (3) years from the date of shipment to Customer. This Limited Warranty extends only to the original buyer. If the Product is determined to be defective within the warranty period, Sunnex, at its option, will repair or replace the Product, at no charge. - Page 12 LAW ARE LIMITED IN DURATION TO THE LIMITED WARRANTY PERIOD SET FORTH HEREIN, AND THEREAFTER ANY IMPLIED WARRANTIES ARE EXPRESSLY DISCLAIMED. No employee, agent, dealer, reseller or distributor of Sunnex is authorized to modify this Limited Warranty, or to make any additional warranties. REPAIR, REPLACEMENT, AS PROVIDED UNDER THIS LIMITED WARRANTY, ARE CUSTOMER’S SOLE AND EXCLUSIVE REMEDIES.
- Page 13 Limited Warranty. In the event Sunnex, at its sole discretion, opts to replace the Product, should said product be discontinued or no longer be offered for sale by Sunnex, a like product in design and functionality will be provided to Customer.
-
Page 14: Troubleshooting
Sunnex Customer Service flashes intermittently when light of lighting system head or arms are moved Sunnex TRI-STAR Service & Installation Manual... - Page 15 Sunnex Inc. 8001 Tower Point Drive Charlotte, NC 28227 Ph: 800-445-7869 Fax: 888-668-1920 REV. 4 September 22, 2019...
