Stobag CM100 K4 SW Coding Manual

Coding manual: for awning professionals
Hand transmitter cM100 K4 SW for all receiver types from euroMOT
(
Document Nr.992455-3-ba / Release: 3.00EN*)Art. No. 490455
*With this document version, all earlier versions lose their validity. euroMOT endeavours to improve these documents constantly.
However, we assume no liability for any existing errors or their consequences.
The cM100 K4 SW 4 channel hand transmitter with automatic on/off function is suitable for the
commandMot series, solvento series and powerFlex radio-controlled motors. It can also be used to
control components of the BUS system, using the BuBu-fk radio node. The radio frequency is 433.92
MHz.
1.0

Description :

Coding the hand transmitter

2.0
ON
1 2 3 4 5 6 7 8 9 ON
+
+
0
0
-
-
992455-3-ba.doc
euroMOT – Pilatusstrasse 36 CH 5630 Muri www.euromot.ch
• Use the slide switch (black) to select the level.
Slide switch left:
Slide switch right: 2. Level for channels 3 – 4 and Man/Auto command
The Manual/Auto command is required for systems with cM1000 sun-wind
automatic.
The code switches for coding the hand transmitter are underneath the
battery cover.
•
Slide switch for selecting levels:
Pos. left
channel 1
channel 2
Man/Auto 1*
•
LED lights when a button is pressed, if the battery is still good. If it no longer
lights, check or change the battery.
•
The battery rating is: 12 V (type A23). Used batteries must be disposed of in
compliance with national regulations.
ENTER THE CODE AND WRITE IT DOWN!
• Slide the group selection switch to the left (for coding the 1
channels 1 – 2 and Man/Auto 1*).
• Slide the teach-in DIP switch 1 to ON (coding mode).
• Set an individual code (code switches 1 – 7) and enter it into the list
on the left.
1. Level for channels 1 – 2 and Man/Auto command
Pos. right:
channel 3
channel 4
Man/Auto 2** extend
Erstellt: 07.12.07
Visum:
GB
retract auto manual
st
level for
Geändert: na / 26.08.08
Seite 1/ 2
