Summary of Contents for Advanced Radiant Systems COOL-SPACE CS5-16
- Page 1 Operation and Maintenance Manual for: CS5-16, CS6-36, CS5-48 220V/60HZ GLACIER AVALANCHE BLIZZARD IMPORTANT SAFETY INFORMATION INSIDE Serious Injury or death possible. Read, understand, and follow all safety information and instructions in the manual before using or servicing this product.
-
Page 2: Table Of Contents
Operation & Maintenance Manual Table of Contents: 1.0 Introduction ® 2.0 Unpacking your COOL- SPACE ® 3.0 Set-up of COOL-SPACE unit 3.1 Connecting the water supply 3.2 Connecting the electrical supply 4.0 Operating procedures 4.1 Filling the unit with water 4.2 Starting the fan 4.3 Starting the pump and adjusting the water flow 5.0 Maintenance and storage... -
Page 3: Introduction
MAY result in property damage. 1.0 Introduction ® COOL-SPACE is a patented and registered Trade Mark of Advanced Radiant Systems, Inc. and manufactured in Indiana USA. ® COOL-SPACE is a compact, self-contained, high-efficiency portable evaporative cooler capable of lowering existing temperatures by as much as 15ºC. -
Page 4: Connecting The Electrical Supply
3.2 Connecting the electrical supply ® The COOL-SPACE unit should be plugged into a fused or circuit breaker protected 10 amp, 220 volt, and 60 Hz circuit. If the unit is custom built for a specific application, please consult the factory for proper configuration. -
Page 5: Operating Procedures
4.0 Operating procedures ® There are 3 factors to consider when determining where to place the COOL-SPACE unit. 1. Fresh air supply: The inlet side of the unit (pad side) requires a constant, uninterrupted supply of fresh air for maximum performance. A distance of 1 metre clear space to any obstructions at the rear or inlet side of the unit is recommended. -
Page 6: Starting The Pump And Adjusting The Water Flow
4.3 Starting the pump and adjusting the water flow DO NOT flood the pads with water, keep them moist. New pads will take a few days before they become completely saturated. It is normal to have several dry streaks on the face of the pads about 25 to 50 mm wide. -
Page 7: Periodic Maintenance
5.3 Periodic maintenance ELECTRICAL SHOCK HAZARD Disconnect the power supply before performing any service or maintenance on the unit. Failure to do so may result in serious injury or death. ® Depending on how often the COOL-SPACE unit operates, this procedure should be performed anywhere from every week for heavy use to monthly for light use. -
Page 8: Troubleshooting/Repair
6.0 Troubleshooting/Repair 6.1 Troubleshooting ELECTRICAL SHOCK HAZARD Disconnect the power supply before performing any service or maintenance on the unit. Failure to do so may result in serious injury or death. ® The COOL-SPACE unit consists of three systems: the fan, water distribution and pump. It is ®... - Page 9 6.1 Troubleshooting (continued) Fan System Please use caution when troubleshooting or repairing all electrical components. Be certain that ® all power is disconnected from the COOL-SPACE unit before the cooling pads or fan guard are removed to gain access to the fan. Direct &...
- Page 10 6.1 Troubleshooting (continued) Water System The water distribution system consists of two (2) assemblies: o The Water Inlet Assembly Brass bulkhead fitting Float valve connection hose Float valve assembly o The Hose and Valve Assembly Spray Bar Assembly ...
- Page 11 6.1 Troubleshooting (continued) Pump Problem Check Solution Pump motor will not run when Turn fan on to check for power. If fan doesn’t start; check switch is turned on. Is water level high enough to breaker and cord plug-in. If fan make the low- water cut-off does start;...
-
Page 12: Repair Procedures
6.2 Repair procedures Repairs should be performed by a qualified technician! Fan Motor Replacement ELECTRICAL SHOCK HAZARD Disconnect the power supply before performing any service or maintenance on the unit. Failure to do so may result in serious injury or death. GLACIER (CS5-16) Series Direct Drive Models 1. -
Page 13: Technical Support
6.2 Repair procedures (continued) BLIZZARD (CS5-48) Belt Drive Models 1. Remove the motor wiring plate and disconnect motor wires. Mark each wire with a marker that will allow easy matching when new motor is installed. (see section 5.1 for pad removal instructions) 2. -
Page 14: Warranty
7.0 Warranty Under normal use, the warranty covers the unit and its components for twenty-four (24) months from date of invoice. Refer to the manufacturer’s Warranty Policy for details. 7.1 Warranty Form ® You must register your COOL-SPACE Portable Evaporative Cooler within fifteen (15) days of initial purchase to validate your cooler’s warranty. -
Page 15: Optional Accessories And Replacement Parts
7.3 Optional Accessories and Replacement Parts Accessories and replacement parts are available from your local distributor or supplier. To ® order parts or for help finding a distributor or supplier visit the COOL-SPACE website at www.cool-space.com or call 001-317-577-0337 or email sales@cool-space.com. Common GLACIER, AVALANCHE, and BLIZZARD Replacement Parts Fan Motor 45cm (18”) Fan Assembly with Motor for GLACIER... - Page 16 International Sales Office PO Box 6916 Bridgnorth WV16 9ED UK 00 44 7979 243154 www.cool-space.com simon.hartles@cool-space.com DISTRIBUTOR: Disposal: This symbol on the product indicates that the appliance cannot be collection point for electric and electronic appliances. REV 01052016al PN CS5-16 CS6-36 CS5-48 220V/60HZ...
