GS520DZ Hot Sheet
System Model # GS5-GS520DZ-RCA-3.0K
Software Version # 39
EPN # 2552
Base PCBA – PN 55847
PCB GS500Z – PN 22015 Rev A
Base Panels
VL801D (Serial Deluxe) – PN 54108
VL802D – PN 54528
Template used: 40599_F.pdf 08/03/2007
54751_97_B.pdf 10/18/2007
Page 1
54751_97_B
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Balboa Instruments GS520DZ
Summary of Contents for Balboa Instruments GS520DZ
- Page 1 GS520DZ Hot Sheet System Model # GS5-GS520DZ-RCA-3.0K Software Version # 39 EPN # 2552 Base PCBA – PN 55847 PCB GS500Z – PN 22015 Rev A Base Panels VL801D (Serial Deluxe) – PN 54108 VL802D – PN 54528 Template used: 40599_F.pdf 08/03/2007 54751_97_B.pdf 10/18/2007...
- Page 2 System Revision History System PN EPN Date Requested By Changes Made 54751 2552 08.22.2007 Balboa New system release 54751 2552 10.05.2007 Balboa Software update to v41 54751 2552 10.18.2007 Balboa Software revert to v39 Page 2 54751_97_B...
-
Page 3: Power Requirements
Basic System Features and Functions Power Requirements System Outputs Setup 1 (As Manufactured) Setup 2 230V Blower (Stereo) (Stereo) Optional Devices Optional Devices Additional Options J72 72 EXT RLY AUX F SEN A SEN B Page 3 54751_97_B... - Page 4 F5, F3A 250V SWITCHBANK A SWITCHBANK A FUSE .3A 250V T0.25A 250V NEUTRAL NEUTRAL WHT AC LINE BLK AC BALBOA INSTRUMENTS, INC. 2-SPD VS500Z EXT RLY P/N 22972 REV D MADE IN U.S.A EXT. T T AUX. F SEN. A SEN. B...
- Page 5 J17/26 F4, T0.3A 250V OPT. BLWR/PUMP 2 E.GND J28 8 Balboa J101 J100 HTR2 HTR1 BALBOA INSTRUMENTS, INC. GS5xxDZ mode GS500Z Pb b P P P COPYRIGHT 2006 MADE IN U.S.A. P/N 22015_A SWITCHBANK A EXT RLY AUX F SEN A SEN B 3.0kW...
- Page 6 J17/26 F4, T0.3A 250V OPT. BLWR/PUMP 2 E.GND J28 8 Balboa J101 J100 HTR2 HTR1 BALBOA INSTRUMENTS, INC. GS5xxDZ mode GS500Z Pb b P P P COPYRIGHT 2006 MADE IN U.S.A. P/N 22015_A SWITCHBANK A EXT RLY AUX F SEN A SEN B 3.0kW...
- Page 7 DIP Switches and Jumpers Definitions SSID 100 94 39 Base Model GS520DZ DIP Switch Key A1 Test Mode (normally OFF) A2+A10 Control amp draw requirements (See Table 1) Table 1 # of Hi-Speed A3 N/A (must be OFF) Pumps/Blower A4 Aux Freeze (must be OFF)
- Page 8 Systems using multiple DIP switches for heat disable: Balboa J101 J100 HTR2 HTR1 BALBOA INSTRUMENTS, INC. Refer to system Hot Sheet DIP Switch Definition page GS500Z COPYRIGHT 2006 MADE IN U.S.A. and set the switches shown in Table 1 such that total...
- Page 9 Ozone Connections Note: A special tool is required to remove the pins from the connector body once they are snapped in place. Check with your Balboa Account Manager for information on purchasing a pin-removal tool. Balboa Ozone connector configuration for 230VAC 50Hz: Black or Brown Line Conductor Empty White or Blue Neutral Conductor...
- Page 10 Serial Deluxe Panel Configurations Time Time Warm Warm Blower Blower Light Light Mode/Prog Mode/Prog Cool Jets 1 Jets 2 VL801D (Serial Deluxe) PN 54108 with Overlay PN 10763 Connects to Main Panel terminal J1 Time Warm Blower Light Mode / Prog Cool Jets 1 Jets 2...
