I N S T A L L A T I O N
&
Installation & Replacement
Follow the individual procedures to perform the notebook's
installation and replacement of various major components.
Z70N
Series Notebook is a fusion of flexibility, style and performance. The key
upgradeable and replaceable items include the Memory module, HDD module, Optical
Drive module, CPU Module
Be sure to follow the safety instructions described from the start to safeguard the
notebook against any potential damages.
This chapter includes the following items:
• Appropriate Tools
• Precaution
• Installation and Replacement for HDD Module
• Installation and Replacement for Memory Module
►Second Memory Module
►First Memory Module
• Installation and Replacement for CPU Module
• Installation and Replacement for Mini-PCI Adapter
• Installation for ODD Module
R E P L A C E M E N T
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Asus Z70N Series
Summary of Contents for Asus Z70N Series
- Page 1 Installation & Replacement Follow the individual procedures to perform the notebook’s installation and replacement of various major components. Z70N Series Notebook is a fusion of flexibility, style and performance. The key upgradeable and replaceable items include the Memory module, HDD module, Optical...
- Page 2 I N S T A L L A T I O N Appropriate Tools The illustrations below show the appropriate tools that should be used for the notebook’s service and repair. Phillips-head Screwdriver C R O S S Use a Phillips-head screwdriver to fasten/remove the K- or B-typed screws. S C R E W - D R I V E R Single-Slotted Screwdriver...
- Page 3 I N S T A L L A T I O N & R E P L A C E M E N T Precautions C A U T I O N S Before you perform any service and/or repair on the notebook, please follow the steps below first.
- Page 4 H D D M O D U L E The Z70N series Notebook uses an industry-standard 2½ HDD with IDE interface. You can replace the HDD to any capacity of your choice within our approval and prior test First, remove AC-power and battery 1.
- Page 5 I N S T A L L A T I O N & R E P L A C E M E N T 4. Replace the new Hard-Disk onto the HDD Housing. 5. Secure 2 screws (M2*4L) on both sides 6.
- Page 6 I N S T A L L A T I O N & R E P L A C E M E N T M2.5*6L...
- Page 7 Installation and Replacement for Memory Module M E M O R Y The Z70N Series Notebook do not have onboard RAM. There are two SO-DIMM M O D U L E sockets for installing SO-DIMM RAM. It can Installation the total memory size up to 1GB with a 512MB module on each socket.
- Page 8 I N S T A L L A T I O N First, remove AC-power and battery. Installation First Memory Module F I R S T 1. Remove 2 screws (M2.5*6L(K)) at bottom side then turn back the notebook and use M E M O R Y tweezers to unlock 3 keyboard latches.
- Page 9 Installation and Replacement for CPU Module C P U M O D U L E The Z70N Series Notebook comes standard with a Intel®’s µFC-PGA Socket on the motherboard, which means it can support all µFC-PGA CPUs up to First, remove AC-power and battery.
- Page 10 I N S T A L L A T I O N & R E P L A C E M E N T M2*3L 4. Slide the FAN bracket left then take it away. Remove 4 screws (M2*6L(K)) at heat sink.
- Page 11 I N S T A L L A T I O N & R E P L A C E M E N T 7. Paste thermal pad onto the CPU heat sink module then install it. 8. Secure 4 screws to fix it and stick the warranty seal label on the screw. 9.
- Page 12 I N S T A L L A T I O N & R E P L A C E M E N T 10. Install the keyboard cover then secure 2 screws (M2*3L(K)) to fix it. M2*3L 11. Install the keyboard module onto top case and secure 2 screws (M2.5*6L(K)) at bottom side then fix it.
- Page 13 I N S T A L L A T I O N Installation and Replacement for Mini-PCI Adapter M I N I - P C I A D A P T O R First, remove AC-power and battery. I N S T A L L A T I O N 1.
- Page 14 I N S T A L L A T I O N & R E P L A C E M E N T M2*3L 5. Disconnect the two antenna cables then open the two latches to pop up wireless WLAN module 45 degrees angle and push it down to lock it up.
- Page 15 I N S T A L L A T I O N & R E P L A C E M E N T M2*3L 8. Install the keyboard cover then secure 2 screws (M2*3L(K)) to fix it. M2*3L 9. Install the keyboard module onto top case and secure 2 screws (M2.5*6L(K)) at bottom side then fix it.
- Page 16 I N S T A L L A T I O N & R E P L A C E M E N T Installation for Optical Drive Module O P T I C A L D R I V E The illustration below shows how to assemble and install the optical drive M O D U L E module of the notebook.
