Follow the procedure in this guide to perform the notebook’s installation and replacement of various major components. Z60Np innovations in mobile computing to provide robust wired and wireless performance at lower power levels never seen before. The key installation and replaceable items include the HDD module, Memory module, CPU Module, Optical Drive module and Mini-PCI module.
Page 2
I N S T A L L A T I O N Appropriate Tools T O O L S The illustrations below show the appropriate tools that should be used for the notebook’s service and repair. Phillips-head Screwdriver C R O S S Use a Phillips-head screwdriver to fasten/remove the K- or B-typed screws.
Page 3
I N S T A L L A T I O N & R E P L A C E M E N T Please pay special attention to the cautions below to prevent any damages to the notebook and also please be sure to select the appropriate tools described in this section to perform any services desired.
Page 4
I N S T A L L A T I O N & R E P L A C E M E N T 4. Always wear a ground strap on your hand to protect the notebook from static discharge. 1 - 4...
HDD Module H D D M O D U L E The Z60Np series Notebook uses an industry-standard 2½ HDD with IDE interface. You can replace the HDD to any capacity of your choice within our approval and prior test First, remove AC-power and battery.
Page 6
I N S T A L L A T I O N & R E P L A C E M E N T 3. Take away Hard-Disk from the HDD Housing 4. Replace the new Hard-Disk onto the HDD Housing. 5.
I N S T A L L A T I O N Memory Installation M E M O R Y The Z60Np Series Notebook does not have onboard RAM. There are two M O D U L E SO-DIMM sockets for installing SO-DIMM RAM. It can upgrade the total memory size up to 1GB with a 512MB module on each socket.
Page 8
I N S T A L L A T I O N module 4. Place the CPU Cover then Secure 2 screws (M2*4L) to fix it Upgrading First Memory Module F I R S T 1. Use the tool to prop the keyboard cover up and slide to the right and press key M E M O R Y “F7”...
Page 9
I N S T A L L A T I O N & R E P L A C E M E N T 3. Remove 2 screws (M2*4L) on the DIMM Bracketr then take it away 4. Remove SO-DIMM by opening the two latches to pop up it then pull the it out 5.
Page 10
I N S T A L L A T I O N & R E P L A C E M E N T 6. Place DIMM Bracket and secure 2 screws (M2*4L) to fix it 7. Install the Keyboard module into chassis properly and secure 2 screws (M2*3L) to fix it 8.
CPU Module C P U M O D U L E The Z60Np Series Notebook comes standard with a Intel®’s µFC-PGA Socket on the motherboard, which means it can support all µFC-PGA CPUs up to 1.7 GHz. First, remove AC-power and battery.
Page 12
I N S T A L L A T I O N & R E P L A C E M E N T 3. Remove 4 screws (M2*4L) from Heat-Sink then take the CPU heat-sink away 4. Carefully remove the CPU thermal pad 5.
Page 13
I N S T A L L A T I O N 6. Don’t touch the die above the CPU. Then use the CPU vacuum hand pump to “suck up” the CPU and take the CPU away. Installing CPU C P U 1.
Page 14
I N S T A L L A T I O N & R E P L A C E M E N T 3. Place the CPU Heat-Sink on CPU then secure 4 screws (M2*4L) in sequence and stick the warranty label 4.
Page 15
I N S T A L L A T I O N & R E P L A C E M E N T 5. Place the CPU Cover then Secure 2 screws (M2*4L) to fix it First, remove AC-power and battery. Optical Drive Module Replacement O P T I C A L D R I V E R...
Page 16
I N S T A L L A T I O N & R E P L A C E M E N T Installing Mini-PCI module I N S T A L L A T I O N 1. Use the tool to prop the keyboard cover up and slide to the right and press key “F7” M I N I - P C I then turn over the keyboard cover at the same time.
Page 17
I N S T A L L A T I O N & R E P L A C E M E N T degrees 1 - 17...
