Summary of Contents for electroVolt LiONCore Series
- Page 1 RECHARGEABLE LITHIUM BATTERIES MANUAL Manual covers LiONCore models, 55111 - 551117 V PWLL C.C OM...
-
Page 2: Safety Warnings
Using LiFePO4 batteries can be hazardous! Using LiFePO4 batteries can be hazardous! Thank you for purchasing a LiONCore battery from electroVolt. The LiONCore Series of lithium-ion batteries offers the kind of power solution you’ve been looking for. Available in several popular power ranges this robust series of off-the-shelf batteryies can meet all your power needs and is an excellent replacement option for everyday SLA / AGM batteries. - Page 3 10. Always transport LiFePO4 batteries with the terminals covered using a non-conductive material such as electrical tape. 11. Keep LiFePO4 batteries out of direct sunlight and environments that might exceed 55°C (131°C). 12. Always keep a class D chemical fire extinguisher nearby, in case of fire when storing, handling, charging or using LiFePO4 battery packs.
- Page 4 CHARGING INSTRUCTIONS & SAFETY WARNINGS 1. Do to international shipping regulations, LiFePO4 batteries are not shipped fully charged. All ElectroVolt LiFePO4 battery packs should be fully charged prior to the first use. Do not charge in series or parallel during initial charge.
-
Page 5: Specifications
Using LiFePO4 batteries can be hazardous! Failure to observe any of the following precautions can result in fire, explosion and cause personal injury. BATTERY DISPOSAL INSTRUCTIONS & SAFETY WARNINGS 1. Any battery that has been subjected to conditions outside of normal use, shows signs of damage or has been retired from use should be disposed of properly. -
Page 6: Battery Management System (Bms)
BATTERY MANAGEMENT SYSTEM (BMS) ElectroVolt LiONCore batteries come with a built-in battery management system (BMS) that protects the battery for increased safety and prolonged life expectancy. The ElectroVolt BMS protects against the following conditions: High Voltage / Over Charge Protection If one or more of the battery cells exceeds the pre-defined upper voltage threshold during charging the BMS will disconnect to prevent charge current from continuing. -
Page 7: Battery Installation
BATTERY INSTALLATION Use properly sized cable and cable lugs (as applicable) to handle the expected load (figure 1) keeping all cables as short as possible. Torque battery terminal connections to the specified values using the supplied flat washer, split washer and bolts (as applicable). (reference specifications chart on previous page). -
Page 8: Charging Temperature
CHARGING TEMPERATURE For optimal performance and longevity charging LiONCore LiFePO4 batteries below 10°C (50°F) should be avoided. ElectroVolt LiONCore LiFePO4 batteries can be safely charged between 0°C to 45°C (32°F to 113°F). All ElectroVolt LiONCore LiFePO4 batteries have buit-in battery management system (BMS) that protects the battery from damaging over-temperature conditions. - Page 9 PROPER SERIES AND PARALLEL CONNECTIONS: SERIES CONNECTION PARALLEL CONNECTION To increase voltage, connect batteries in series. To increase capacity, connect batteries in parallel. This will not increase the system capacity. This will not increase the system voltage. Two 12.8V batteries rated at 100Ah. Two 12.8V batteries rated at 100Ah.
- Page 10 1 year from the original date of shipment. During that period, as its sole responsibility and as the purchaser’s sole remedy under this warranty, ElectroVolt will repair or replace defective products or, at its sole discretion, issue a credit memo for the purchase price of such products.
