CALIBRATION PROCEDURE

NI PXIe-4154

This document contains information for calibrating the NI PXIe-4154 Battery Simulator. For

more information about calibration, visit

Contents

Software Requirements............................................................................................................. 1

Documentation Requirements .................................................................................................. 2

Password................................................................................................................................... 2

Calibration Interval................................................................................................................... 2

Test Equipment......................................................................................................................... 3

Test Conditions......................................................................................................................... 4

Calibration Procedures ............................................................................................................. 5

Initial Setup....................................................................................................................... 5

Verification....................................................................................................................... 5

Voltage Output Verification ..................................................................................... 6

Current Output Verification...................................................................................... 7

Voltage Measurement Verification .......................................................................... 9

Current Measurement Verification........................................................................... 10

Output Resistance Verification (Channel 0 Only).................................................... 14

Load Regulation Verification ................................................................................... 17

Remote Sense Accuracy Verification....................................................................... 19

Transient Response Verification (Channel 0 Only) ................................................. 20

Adjustment................................................................................................................................ 23

Considerations .......................................................................................................... 24

Adjusting Current Measurement .............................................................................. 25

Adjusting Voltage Output......................................................................................... 26

Adjusting Current Output ......................................................................................... 27

Adjusting Voltage Measurement .............................................................................. 29

Adjusting Output Resistance (Channel 0 Only) ....................................................... 30

Where to Go for Support .......................................................................................................... 31

Software Requirements

Calibrating the NI PXIe-4154 requires installing NI-DCPower version 1.5 or later on a Windows

calibration system. You can download the NI-DCPower instrument driver from

. NI-DCPower supports programming an External Calibration in the C and LabVIEW

drivers

application development environments (ADEs). When you install NI-DCPower, you only need

to install support for the ADE that you intend to use.

ni.com/calibration

ni.com/
