Summary of Contents for Dateq XTC II
- Page 1 XTC II Gebruiksaanwijzing User manual DATEQ Audio Technologies B.V. De Paal 37 1351 JG Almere The Netherlands www.DATEQ.nl...
-
Page 3: Safety Instructions
DATEQ XTC II manual Safety instructions Safety instructions 1. All safety instructions, warnings and operating instructions must be read first. 2. All warnings on the equipment must be heeded. 3. The operating instructions must be followed. 4. Keep the operating instructions for future reference. -
Page 4: Product Support
The dual headphones connector has a split-function to listen to the mix and the CUE signal simultaneously. The master outputs are on cinch and on balanced XLR connectors. Optional 19-inch brackets are available to make it possible to mount the XTC II into a 19-inch rack. Contact your dealer to obtain the brackets. Product support... - Page 5 DATEQ XTC II: A new version of the XTC a standard in the battle scene The new DATEQ XTC II is the perfect tool for the every DJ. Multifunctional, but still easy-to-use. This manual reveals all it's characteristics and secrets..
-
Page 6: Installation
DATEQ XTC II manual Installation The DATEQ XTC II can be mounted into a table, but it can also be use stand-alone. Optionally 19-inch brackets are available to mount the XTC II into a 19-inch rack. Don't forget to leave some space for the connectors at the back of the XTC II. - Page 7 DATEQ XTC II manual Connecting Connecting the XTC II All connections can be made at the rear and the front of the XTC II. Below we will explain the function of the connectors. M ad e b y A lmere/ T h e N eth erlan d s W W W .D A T EQ.N L...
- Page 8 Connecting DATEQ XTC II manual Left/ right master outputs (XLR 3-pin male) Function Type Audio ground Audio + Output Audio - Output Master/ monitor/ record/ effect(FX)- send outputs (cinch) Function Type Audio + Output Shield Audio ground Sub out (6.3mm jack)
-
Page 9: Operation
The processed signal (so with the effect) becomes available at the channels fader and can be added to the mix. If the effect return signal is NOT present the XTC II 's own send signal is being used instead, shown by a blinking FX indicator. -
Page 10: Master Section
Operation DATEQ XTC II manual Master section The XTC II master section holds a 2x30 segmented VU-meter showing the master mix or cue level accurately. The master volume control can adjust the master-mix volume. The balance adjusts the master left-right balance. -
Page 11: Software Setup
(Limiter-lock). Limiter The XTC II has a build-in limiter. As soon as the output level of the console crosses the +6dB threshold, the limiter will respond with slowly decreasing the level. This way a good the quality and dynamics of the audio signal will be guaranteed for a longer period, and the connected apparatuses will be protected against overload conditions. -
Page 12: Jumper Settings
Setup DATEQ XTC II manual Jumper settings To be able to reach the internal jumpers the AC-cord has to be disconnected from the mains first. Then the 8 torx screws of the front panel can be unscrewed and the front panel can be flipped open gently . -
Page 13: Technical Specifications
CROSSTALK......>75dB @ 1kHz NOISE........-80dB Common Power supply......100 – 250Vac/ 50 - 60Hz Power consumption....25W Lamp connector...... 12Vdc/ 3W Front........320x354mm Height........8HE Depth........92mm Weight........4.5kg Dateq Audio Technologies B.V. reserves the right to amend specifications without notice... -
Page 15: Eg-Verklaring Van Overeenstemming
EG-VERKLARING VAN OVEREENSTEMMING acc.to art.10.1 EMC directive 89/336/EEC Wij, DATEQ Audio Technologies b.v. de Paal 37, 1351 JG ALMERE, Nederland verklaren, uitsluitend op onze verantwoordelijkheid, dat dit produkt Type: XTC II Serienummers: 35-XXXX waarop deze verklaring betrekking heeft, in overeenstemming is met de volgende... -
Page 16: Ec Declaration Of Conformity
EC-DECLARATION OF CONFORMITY acc.to art.10.1 EMC directive 89/336/EEC DATEQ Audio Technologies B.V. de Paal 37 1351 JG ALMERE THE NETHERLANDS hereby declare, exclusively to our responsibility, that this product Type: XTC II Serialnrs.: 35-XXXX to which this declaration applies, is in accordance with the following harmonized European...
