Sinterit ATEX*/INTERTEK Vacuum Cleaner
USER MANUAL
refers to product „Atex Vacuum Cleaner" NRTL certified (ETL Intertek listed)
Read the instruction manual before using the device.
Internal device construction differences might appear betweet products with ATEX
and INTERTEK certificates.
Version 09/2020/USA
Advertisement
Table of Contents
Related Manuals for SINTERIT ATEX
Summary of Contents for SINTERIT ATEX
- Page 1 Sinterit ATEX*/INTERTEK Vacuum Cleaner USER MANUAL refers to product „Atex Vacuum Cleaner” NRTL certified (ETL Intertek listed) Read the instruction manual before using the device. Internal device construction differences might appear betweet products with ATEX and INTERTEK certificates. Version 09/2020/USA...
- Page 2 This manual should be considered an integral part of the vacuum cleaner and must be kept together with the unit until this is scrapped. In case of loss or damage to the manual, ask Sinterit for a new copy or visit www.sinterit.com/support- page/ and download the PDF.
-
Page 3: Table Of Contents
H. Safety plates (specification tag and symbols) ......................14 Scrapping..................................15 6. Initial startup of the Sinterit INTERTEK Vacuum Cleanerr after delivery ................ 15 7. Preparing the machine to work ............................16 A. Preparing the machine to work without Sinterit Powder Separator ................ 18 8. -
Page 4: Marking Text Conventions Used In The Document
Sinterit caused by use of the vacuum cleaner by personnel not properly trained or who use it in an improper manner, as well as by even partial failure to comply with the safety regulations and intervention procedures indicated in this manual. -
Page 5: Contents Of The Sinterit Intertek Vacuum Cleaner Pack
A.Antistatic hose (3 m) / B.Aluminium connector 40/50 (for Antistatic hose) / C.Rubber nozzle (with aluminium connector) / D.PVC brush / E.Double curved wand / F.Floor brush / G.Sinterit INTERTEK Vacuum Cleaner User Manual / Sinterit INTERTEK Vacuum Cleaner USER MANUAL | 5... -
Page 6: Sinterit Intertek Vacuum Cleaner
3. Sinterit INTERTEK Vacuum Cleaner A. DESCRIPTION Image 2. Front view of the Sinterit INTERTEK Vacuum Cleaner. Image 3. Back view of the Sinterit INTERTEK Vacuum Cleaner. 1.Control panel / 2.Motor Head / 3.Motor Head handle / 8.Power cable / 9.Suction hose connector / 4.Filtering chamber / 5.Release fasteners / 6.Castors /... -
Page 7: Specification
Size of package 570 x 670 x 1300 [mm] (22.4 x 26.4 x 51.2 [in]) Package weight 30 [kg] (66.13 [lbs]) Package contains Sinterit INTERTEK Vacuum Cleaner + set of accessories + Manuals POWER Voltage 115 [V] AC, 60 [Hz] Power 1.1 [kW] (1.5 [HP]) - Page 8 It is therefore necessary, if such working conditions exist, to provide workers with such approved individual protection devices and to inform them of the risks relating to noise exposure. 8 | Sinterit INTERTEK Vacuum Cleaner USER MANUAL...
-
Page 9: Exceptional Risks
Remove the filter and clean it, empty the container and store the vacuum cleaner in a place protected against atmospheric agents with a temperature between 0°C and 40°C. • Cover with a nylon sheet to prevent accumulation of dust. Sinterit INTERTEK Vacuum Cleaner USER MANUAL | 9... -
Page 10: General Safety Rules
The Motor Head’s protection cap containing moving parts must not be removed by the user. • Make sure all the guards and protection devices are in place and that all the safety devices are in place and working properly. 10 | Sinterit INTERTEK Vacuum Cleaner USER MANUAL... -
Page 11: Personal Protection
In the event of the cable, plugs or couplings being replaced, make sure these are protected against water spray and check mechanical strength. • Motor brushes and burnt-out fuses must be replaced by Sinterit or authorised dealers. Always use original spare parts. STOP! •... -
Page 12: Safety Requirements During Using The Vacuum Cleaner
Do not vacuum lit cigarette ends. The filter could be damaged. • If the filters are correctly fitted, the machine will not eject any objects. • Shake the filter only when the exhauster is off. 12 | Sinterit INTERTEK Vacuum Cleaner USER MANUAL... -
Page 13: Safety During Repair And Maintenance
Structural damage and improper alterations or repairs could change the protection capacity of the vacuum cleaner and therefore cancel this certification. • Any alterations to the appliance can only be made by Sinterit Support. WARNING! NON-SPARKING DEFLECTOR The vacuum cleaner is provided with a brassy non-sparking deflector that avoids potential ignition sources within the container and allows working with safety in case of CLASS II –... -
Page 14: Safety Plates (Specification Tag And Symbols)
Clean these with a cloth, soap and water. Do not use solvents, diesel fuel or petrol. • Replace the damaged plates with new ones supplied by Sinterit. If a plate is attached to a replaced part, make sure a new plate is affixed to the new part. -
Page 15: Scrapping
Sinterit cannot foresee all possible circumstances capable of representing a potential hazard. The warnings in this manual and on the products should not, therefore, be deemed exhaustive. In the event of tools, procedures, work or machining methods being used that are not explicitly recommended by Sinterit, make sure no hazards exist for operators and others. -
Page 16: Preparing The Machine To Work
In the event of any component parts being damaged, do not proceed with installation. Notify the manufacturer and reach an agreement on how to proceed. ATTENTION! • The operator using the Sinterit INTERTEK Vacuum Cleaner always must wear antistatic clothes and antistatic shoes. • The working environment and the floor must comply with antistatic standards. - Page 17 Image 10. Two ways of using the Sinterit INTERTEK Vacuum Cleaner. IMPORTANT! For full instructions on how to use the Sinterit Powder Separator with the Sinterit INTERTEK Vacuum Cleaner, please refer to Sinterit Powder Separator’s user manual. Sinterit INTERTEK Vacuum Cleaner USER MANUAL | 17...
-
Page 18: Preparing The Machine To Work Without Sinterit Powder Separator
A. PREPARING THE MACHINE TO WORK WITHOUT SINTERIT POWDER SEPARATOR 1. Fit the Antistatic hose into the Aluminium connector 40/50 and next into the Suction hose connector . At the same time, lift the locking screw of the suction hose connections (Image 10, part 1) and insert the Antistatic hose (Image 10, part 2). - Page 19 4. For proper operation of each device (vacuum cleaner/powder separator), it is necessary to leave some free space in the container in order to keep the air access. POWDER ONLY 3/4 OF THE CONTAINER MAX 3/4 HEIGHT MAX 3/4 HEIGHT Image 12. Maximum capacity of the powder. Sinterit INTERTEK Vacuum Cleaner USER MANUAL | 19...
-
Page 20: Cleaning Of The Filtering Chamber
12. Fit the Motor Head back on and secure with Release fasteners. CAUTION! Danger of crushing upper limbs when fitting and locking the Motor Head on the Filtering Chamber. 13. Fit the necessary accessories, connect the power supply and grounding. Start working again. 20 | Sinterit INTERTEK Vacuum Cleaner USER MANUAL... -
Page 21: Maintenance Of The Sinterit Intertek Vacuum Cleaner
10. Maintenance of the Sinterit INTERTEK Vacuum Cleaner This section describes the control and special maintenance operations crucial for keeping the vacuum cleaner in perfect working condition. ATTENTION! All the transport and handling operations described in this section must be done in NOT-CLASSIFIED atmosphere, which means in an area with non potentially explosive atmosphere. -
Page 22: Periodical Maintenance
MOREOVER there is no guarantee of the required INTERTEK protection. ATTENTION! To ensure the vacuum efficiency and safety, Sinterit recommends an overhaul at the Manufacturer’s technical service workshop every 24 months. ATTENTION! In case of dust outflow from the engine, turn off the vacuum immediately and call the authorised service centre applying for assistance. -
Page 23: Replacing The Main Star Filter
12. Fit the new filter, put everything back together carefully and precisely. 13. Put the Main Star filter back in place. 14. Remember to connect the internal grounding! (Image 18). 15. Fit the Motor Head back on and secure with Release fasteners. Sinterit INTERTEK Vacuum Cleaner USER MANUAL | 23... -
Page 24: Troubleshooting
Star Filters must be checked every six months. In case they are worn it will be necessary to replace them with new ones, to be requested as spare parts to Sinterit Company. Sinterit will accept no responsibility in case of use of NON-ORIGINAL filters. -
Page 25: General Legal Information
12. General legal information Where this manual refers to Sinterit or the Company, this means Sinterit sp. z o.o. with its legal seat in Krakow, registered by the District Court for Kraków-Śródmieście in Krakow, XI Commercial Division of the National Court Register under number: 535095, NIP (tax number): 6793106416, with the share capital for a date of publication of this manual of PLN 102,050 (say: one hundred and two thousand and fifty). -
Page 26: Terms Of Warranty
The terms of the warranty are set forth in the agreement between the buyer and the Company. In case of a purchase made in the Sinterit online shop, the terms of the guarantee are specified in the Terms and Conditions, subject to the acceptance of the Customer before placing an order. - Page 27 Dust may be in suspension in the air as the result of the infrequent malfunction of equipment; or • Dust accumulation may be sufficient to interfere with safe dissipation of heat or may be ignitable by the abnormal operation. Sinterit INTERTEK Vacuum Cleaner USER MANUAL | 27...
- Page 28 SINTERIT Sp.z o.o. ul. Nad Drwina 10 bud. B3, 30-741 Krakow, Poland www.sinterit.com Contact: +48 570 967 854...
