Avenue 5330 Data Pack

A-d video converter with audio option
Hide thumbs

Advertisement

Quick Links

Download this manual
Model 5330 A-D Video
Converter with
6330 Audio Option
E
N S E M B L E
D
E
S
I
G
This data pack provides detailed installation, configuration and operation information for
the 5330 Analog to Digital Video Converter module along with the 6330 Audio
Processing option submodule as part of the Avenue Signal Integration System.
The module information in this data pack is organized into the following sections:
• 5330/6330 Overview
• Applications
• Installation
• Installation
Configuring Rear BNCs
°
• Cabling
• Module Configuration and Control
Front Panel Controls and Indicators
°
Avenue PC Remote Control
°
Avenue Touch Screen Remote Control
°
• Troubleshooting
• Software Updating
• Warranty and Factory Service
• Specifications
Data Pack
N
S
5330/6330-1
Revision 3.1 SW v2.2.6

Advertisement

loading
Need help?

Need help?

Do you have a question about the 5330 and is the answer not in the manual?

Questions and answers

Summary of Contents for Avenue 5330

  • Page 1 Revision 3.1 SW v2.2.6 This data pack provides detailed installation, configuration and operation information for the 5330 Analog to Digital Video Converter module along with the 6330 Audio Processing option submodule as part of the Avenue Signal Integration System. The module information in this data pack is organized into the following sections: •...
  • Page 2 AES or SDI outputs. Video outputs are fully timed to your house reference. On loss of output (such as noise), the 5330 can be set to mute to black or freeze on the last good frame of video.
  • Page 3 Model 5330/6330 Video Audio ADC 5330 module emory registers can be used to save the complete configuration of the module, making it easy to change instantly between different configurations. Modules at software version 2.2.0 or later support SNMP (Simple Network Management Protocol) monitoring.
  • Page 4 MODULE CONFIGURATION AND CONTROL section later in this manual. Satellite Reception As illustrated in the block diagram below, the 5330 will accept an input from an analog receiver, convert it to serial digital, then lock the signal to the house reference with full timing capability.
  • Page 5 Model 5330/6330 Video Audio ADC Compact Systems A one rack unit (1 RU) Avenue chassis populated with a 5400 TSG and one or two 5330 modules makes an ideal signal acquisition system where small size and light weight are required. With the variety of analog input formats which the 5330 Frame Synchronizer accepts, it is equally at home with the Y/C feed from a VHS machine, Y/Pr/Pb from a BetaCam, or composite from an analog camera.

  • Page 6: Installation

    • Cpst/SDI Out BNC Configuration – The BNC labeled CPST/SDI can be set with Switch S1 on the rear of the 5330 circuit board for either CPST (up) for a composite output or to SDI (down) for an SDI output.The default setting for this switch is CPST when shipped from the factory.
  • Page 7 Model 5330/6330 Video Audio ADC 5330 ADC Module Plug the 5330 module into any one of the slots in the 1 RU or 3 RU frame and install the plastic overlay provided onto the corresponding group of rear BNC connectors associated with the module location.
  • Page 8 Model 5330/6330 Video Audio ADC 3 RU Backplane AES 3/4 Out or SDI Out – Set BNC to output AES 3/4 audio or SDI video with toggle switch S5 on circuit board. AES 1/2 Out or SDI Out – SDI Out – Connect to Set BNC to output AES 1/2 audio SDI video destinations.

  • Page 9: Module Configuration And Control

    The configuration parameters for each Avenue module must be selected after installation. This can be done remotely using one of the Avenue remote control options or locally using the module front panel controls. Each module has a REMOTE/LOCAL switch on the front edge of the circuit board which must first be set to the desired control mode.
  • Page 10 • Output: The Bypass selection takes the 5330 out of the video path by routing around it. Split mode may be used to compare input and output signals to observe the effect of adjustments.
  • Page 11 If analog audio is in use the anticipated nominal level of this incoming audio can be set with the four Anlg Lvl controls. • Audio Mode: The 5330 can handle both types of content present in AC-3 or Dolby- E signals. Some synchronizing requirements are necessary for supporting these protocols.
  • Page 12 Model 5330/6330 Video Audio ADC Audio Operational Example This section describes the audio configuration of the satellite application example given at the beginning of this manual. Stereo analog audio is arriving from a satellite receiver as shown in the Satellite block diagram.
  • Page 13 Model 5330/6330 Video Audio ADC 5330/6330 Parameter Table FACTORY DEFAULT CONTROL LOCAL REMOTE DEFAULT USER LEVEL VIDEO IN/PROCESSING CONTROLS Composite Switch 1: Compst No Setup Cpst or CAV Input Select If CAV: Y_C No Setup Composite Level 1 Switch 2:...
  • Page 14 Model 5330/6330 Video Audio ADC 5330/6330 Parameter Table (Continued) FACTORY DEFAULT CONTROL LOCAL REMOTE DEFAULT USER LEVEL TIMING CONTROLS Horizontal Timing 0 clocks +/– 1716 clocks 0 clocks Admin Vertical Timing 0 lines +/– 525 lines 0 lines Admin VIDEO OUTPUT CONTROLS...
  • Page 15 Model 5330/6330 Video Audio ADC 5330/6330 Parameter Table (Continued) FACTORY DEFAULT CONTROL LOCAL REMOTE DEFAULT USER LEVEL AUDIO CONTROLS (6330 Audio Submodule Installed) Ch 1-4 In (level) –70 dB –70 to +12 dB –70 dB Level 1 Ch 1 – Output 1 Ch 1 –...
  • Page 16 Model 5330/6330 Video Audio ADC Front Panel Controls and Indicators Each front edge indicator and switch setting is shown in the diagram below: Input green LED: Ref green LED: On indicates input video signal On when the selected reference is present and detected.
  • Page 17 • The function is not active. • The module is locked. • The User Level set with Avenue PC is not accessible from the current User Level. 5330 Avenue PC Menus The Vid In menu shown below allows you to configure the following input sources: •...
  • Page 18 Model 5330/6330 Video Audio ADC The Proc menu shown below allows you to adjust the following video processing parame- ters for the signal: • Gain – adjust the percentage of overall gain (luminance and chrominance). • Chroma – adjust the percentage of chroma amplitude.
  • Page 19 Model 5330/6330 Video Audio ADC Custom – to enable the B/W Clip and Chr Clip Modes controls to set custom parameters with the following controls: • B/W Clip – select On to enable black and white clip functions or Off to disable them.
  • Page 20 Model 5330/6330 Video Audio ADC The next group of audio menus are used when the 6330 Audio submodule is installed. Use the Aud Mix menu shown below to control the audio mixing and shuffling of the module. Each output bus assignment will be indicated by a green box.
  • Page 21 Model 5330/6330 Video Audio ADC Use the Aud In menu shown below to adjust the following parameters: • 1/2 Input – select the input audio source for Input 1/2. • 3/4 Input – select the input audio source for Input 3/4.
  • Page 22 Model 5330/6330 Video Audio ADC Use the Aud Delay menu shown below to adjust the amount of audio delay on the output: • Auto Track – enable auto tracking by selecting On or Off. • Bulk Delay – set the amount of bulk delay using the left and right arrows.
  • Page 23 Model 5330/6330 Video Audio ADC The Filter menu shown below allows setting of the luminance and chroma sharpness with the following detail enhancing controls: • Lum Sharp – set to Off to bypass detail enhancing filters. Set to 1/4, 1/2, or Max to set the sharpness of the luminance portion of the signal.
  • Page 24 Model 5330/6330 Video Audio ADC The Blanking menu shown below allows you to adjust the output blanking of the module with the following controls: • Mode – set the blanking mode to Narrow (lines 1-9 are blanked in NTSC, lines 1-6 in PAL), Wide (lines 1-20 in NTSC, lines 1-22 in PAL), or Custom.
  • Page 25 3) Freezes on Noise – when the module detects the video quality to be unaccept- able, the 5330 will freeze and output the last good field of video. The Memory menu shown below allows you to save overall module setups to five memory registers as follows: •...
  • Page 26 Model 5330/6330 Video Audio ADC The Trim menu allows you to correct subtle issues in the individual color difference channels with offset and gain controls. The offset controls adjust the DC offsets above or below the nominal points. This can be used to correct black balance errors. The gain controls adjust the amplitude of each channel.
  • Page 27 • The function is not active. • The module is locked. • The User Level set with Avenue PC is not accessible from the current User Level. 5330 Touch Screen Menus The Vid In menu shown below allows you to configure the following input sources: •...
  • Page 28 Model 5330/6330 Video Audio ADC The Proc menu shown below allows you to adjust the following video processing parame- ters for the signal: • Gain – adjust the percentage of overall gain (luminance and chrominance). • Chroma – adjust the percentage of chroma amplitude.
  • Page 29 Model 5330/6330 Video Audio ADC Use the Clip menu shown below to adjust the following parameters: • Legalizer – set the legalizer function to one of the following: Off – to disable it. Legal – to apply the following factory default values: •...
  • Page 30 Model 5330/6330 Video Audio ADC The next group of audio menus are used when the 6330 Audio submodule is installed. Use the Aud Mix menu shown below to control the audio mixing and shuffling of the module. Each output bus assignment will be indicated by a green box.
  • Page 31 Model 5330/6330 Video Audio ADC Use the Aud In menu shown below to adjust the following parameters: • 1/2 Input – select the input audio source for Input 1/2. • 3/4 Input – select the input audio source for Input 3/4.
  • Page 32 Model 5330/6330 Video Audio ADC Use the Aud Delay menu shown below to adjust the amount of audio delay on the output: • Auto Track – enable auto tracking by selecting On or Off. • Bulk Delay – set the amount of bulk delay using the left and right arrows.
  • Page 33 Model 5330/6330 Video Audio ADC Use the Aud Out menu shown below to adjust the following audio output parameters: • Audio Embed – turn embedding Off for no embedding in the output signal. To embed an audio group, select the position to embed from either Cascade (next available audio group) or Replace (replace all groups).
  • Page 34 Model 5330/6330 Video Audio ADC The Filter menu shown below allows setting of the luminance and chroma sharpness with the following detail enhancing controls: • Lum Sharp – set to Off to bypass detail enhancing filters. Set to 1/4, 1/2, or Max to set the sharpness of the luminance portion of the signal.
  • Page 35 Model 5330/6330 Video Audio ADC Use the Timing menu shown below to adjust the following parameters: • Hor Timing – adjust the horizontal timing of the output signal to place the leading edge of sync coincident with other sources. • Vertical Timing – set the vertical timing to a typical setting of 0 lines.
  • Page 36 Model 5330/6330 Video Audio ADC The Blanking menu shown below allows you to adjust the output blanking of the module with the following controls: • Mode – set the blanking mode to Narrow (lines 1-9 are blanked in NTSC, lines 1-6 in PAL), Wide (lines 1-20 in NTSC, lines 1-22 in PAL), or Custom.
  • Page 37 2) Mutes on Noise – when the module detects the video quality to be unaccept- able, the 5330 will output a black signal. 3) Freeze on Noise – when the module detects the video quality to be unaccept- able, the 5330 will freeze and output the last good field of video. 5330/6330-37...
  • Page 38 Model 5330/6330 Video Audio ADC The Memory menu shown below allows you to save overall module setups into up to five memory registers as follows: • Select Save, then one of the five memory registers Reg 1 – 5. The box will turn green.
  • Page 39 Model 5330/6330 Video Audio ADC The Trim menu allows you to correct subtle issues in the individual color difference channels with offset and gain controls. The offset controls adjust the DC offsets above or below the nominal points. This can be used to correct black balance errors. The gain controls adjust the amplitude of each channel.

  • Page 40: Troubleshooting

    Software upgrades for each module can be downloaded remotely if the optional System Control module is installed. These can be downloaded onto your PC and then Avenue PC will distribute the update to the individual module. (Refer to the Avenue PC documenta- tion for more information).

  • Page 41: Warranty And Factory Service

    Model 5330/6330 Video Audio ADC WARRANTY AND FACTORY SERVICE Warranty This module is covered by a five year limited warranty, as stated in the main Preface of this manual. If you require service (under warranty or not), please contact Ensemble Designs and ask for customer service before you return the unit.

  • Page 42: Specifications

    Model 5330/6330 Video Audio ADC SPECIFICATIONS 5330 Video ADC Analog Inputs Type: SMPTE Y, Cr, Cb Beta Y, Cr, Cb NTSC, PAL Composite NTSC, PAL S-Video (Y/C) 75 Ω, BNC Impedance: Return Loss: > 40 dB Input DC: ± 1 volt DC Input Hum: <...
  • Page 43 Model 5330/6330 Video Audio ADC Analog Audio Inputs (6330 Submodule) Number: 4, Balanced Pair Processing: 24 bits CMRR: > 60dB, 20Hz to 10KHz 15k Ω, balanced, transformerless Analog Input Z: AES Audio Inputs (6330 Submodule) Number: 2 (Total of four channels)
  • Page 44 Model 5330/6330 Video Audio ADC 5330/6330-44...
