Summary of Contents for Steam Saphira C8
- Page 1 www.steamaustralia.com.au – info@steamaustralia.com.au – 1300 79 50 50 V1.221020...
-
Page 2: Table Of Contents
Contents Safety Precautions ................................3 Steam Cleaner Description ..............................4 Components ..................................5 Accessories ..................................5 Standard Accessories ..............................5 Optional Accessories ..............................5 Before Switching On ................................6 Water Quality ................................. 7 Filling with Water ................................7 Attaching/Removing the Hose ............................7 Using Your Appliance ................................. -
Page 3: Safety Precautions
• This appliance must only be used in accordance with these instructions. It is to be used as a steam generator with steam cleaning accessories to clean flooring, walls, upholstery, tiles, windows, fabrics and bench tops. -
Page 4: Steam Cleaner Description
Steam Cleaning is different to traditional cleaning as we are super heating the water to over 170°C and in most cases, we will only use the steam and the super-heated water vapour to sanitise and clean at the same time. This means we use a very small amount of water over the duration of our clean and the higher pressures reduces the amount of “elbow grease”... -
Page 5: Components
1. Water Tank Cap 2. Machine Ready Light 3. Pressure Gauge 4. Wheels 5. Water Tank Empty Light 6. Mains ON/OFF Switch 7. Steam Hose Socket Accessories Standard Accessories 2.5m Hose AC8000061 Triangle Brush AC8000011 Extension tube 500mm (2) AC0010022 Brush nylon 30mm... -
Page 6: Optional Accessories
AC0020001 Wall Mop Pad 250mm AC0000035 Deluxe Iron with PP1020003 AC8000016 Floor Mop Head 390mm Silicon Mat AC0020012 Floor Mop Pad 390mm Steam Australia Accessories Bag AC0030002 Triangle Brush Cushion RHS315 Reynard Microfibre Cloth 50pk AC8000004 Plunger RHS315-20 Reynard Microfibre Cloth 20pk RR1822352/50 Rubbermaid 18”... -
Page 7: Before Switching On
Turn the machine on using the black On/Off button. The button will light up and the boiler should start heating up the water. If there is too little water in the boiler, the Saphira C8 will start pumping water from the tank into the boiler which will make the machine vibrate for a little while. -
Page 8: Accessories Guide
Floor 300mm Use the floor brush to scrub off hard-to- 2 x AC8000011 remove dirt. In stubborn areas use level Extension Tube S/O 2 or 3 steam followed by moderate 500mm brushing. Microfibre Cloth Can be fitted with microfibre cloth (clips... - Page 9 Detail Nozzle For detail cleaning in kitchens, bathrooms and other areas: - Tile grouts (walls and floors) - Sinks and taps - Toilet side lip - Drains - Ovens - Sliding door tracks For best results when cleaning grout, hold brush on angle to clean sides of the grout line, and then tilt in other direction to clean the other side of the AC8000002...
-
Page 10: Optional Accessories
Window Squeegee For cleaning glass surfaces (windows and bathroom mirrors). Spray a stream of steam in a circular AC8000006 motion onto the glass surface, then use Window Squeegee S/O w/ 250mm the rubber squeegee part to remove insert water condensation and clean the surface. - Page 11 Deluxe Iron To use the Deluxe Steam Iron, unplug your steam hose and plug in iron. Make sure the machine is ‘Ready’. AC0000035 To use as an iron, turn dial to desired Iron temperature and use.
-
Page 12: Maintenance
O-rings are present. O-rings can be found on some accessories, all extensions and both ends of the hose. If you notice steam leaking from some accessories, check the O-rings from the area where the hose/accessories connection leaks steam. -
Page 13: Servicing
Follow the steps in “Boiler Maintenance” to drain the boiler. If problem persists, contact your local authorised service agents. If you are unsure about any symptoms you should stop use of the steam cleaner and contact Steam Australia or your local authorised service agent.
