- Page 1 DESTRAT VENTILATOR OPERATING AND MAINTENANCE MANUAL Model: S-DSVF-115V / S-DSVF-220V September 2020 s u r n a . c o m...
- Page 2 INVESTING IN QUALITY, RELIABILITY & PERFORMANCE ISO 9001 QUALITY World Leading Design and Technology This product is manufactured to meet the stringent requirements of the internationally recognized ISO 9001 standard for quality assurance in design, development and production. The Highest Standards of Manufacturing ETL SAFETY EN60335-1: Saftey requirements of households and similar electrical appliances..
-
Page 3: Table Of Contents
TABLE OF CONTENTS Specifications Warnings Warranty Information Installation Instructions Routine Maintenance Troubleshooting... - Page 4 MODEL CODE NOMENCLATURE S - DSVF - XXXV 115V 115V/1Ph/50-60Hz 220V 220V/1Ph/50-60Hz Destratification Ventilator DSVF Surna...
-
Page 5: Specifications
SPECIFICATIONS S-DSVF-XXX-V PHYSICAL Model S-DSVF-115V Model S-DSVF- 220V 17.91 ± 0.12 in (455 ± 3 mm) Fan Diameter Height 12 in (305 mm) Weight 22 lbs (9.98 kg) 25.71 ± 0.12 in (653 ±3 mm) Fan Base Diameter Mounting Bracket Length1 6.54 in (166.1 mm) - Page 6 DIMENSIONAL DR AWINGS Dimensional drawings Air Flow A==t A View FIGURE 1: Dimensional Drawings Rotation 12 in 5.51 ±0.12 in 5.55 ±0.12 in 6.54 in Ø0.31 in Ø0.31 in 305 mm 140 ±3 mm 141 ±3 mm 166.1 mm Ø8 mm Ø8 mm 0.59 in 1.18 in...
-
Page 7: Warnings
To reduce risk of injury, do not bend the blade brackets servicing of the Surna Destrat Ventilator. This document when installing the brackets, balancing the blades, or contains information required to install and operate the cleaning the fan. - Page 8 To reduce the risk of fire or electric shock, do not use this DO NOT use an extension cord or plug adapters. These unit with any solid-state speed control device. actions may result in a fire hazard or electric shock. To reduce risk of injury, it is recommended to mount the DO NOT operate this unit with damaged power wires.
-
Page 9: Warranty Information
WARRANTY INFORMATION For the equipment manufactured by Surna (“Company”), Returns must have prior written approval by Company the warranty shall exist for a period of twelve (12) months and are subject to restocking and replacement charges from initial start-up or eighteen (18) months from date where applicable. - Page 10 DESTR AT VENTIL ATOR ORDER Below is a list of all parts provided with each Surna Destrat Ventilator unit. The following are included with the order (quantities are dependent on individual order). 1. Surna Destrat Ventilator fan unit 2. Surna Destrat Ventilator product manual 3.
-
Page 11: Installation Instructions
INSTALLATION INSTRUCTIONS MECHANICAL ELECTRICAL Mounting details are shown in figures 2 and 3. The unit must be securely supported in compliance WARNING: Turn off the breaker until all electrical with local codes. Do not use rope or chain to suspend connections are made. - Page 12 BR ACKET DIAGR AM FIGURE 2: Bracket Diagram Dimension Specification Airflow guide Hanger bracket Crossbeam Bolts with washers for mounting Supportive wire1 Supportive wire lock Hanger base TABLE 3: Bracket Parts Recommended only; not included.
- Page 13 INSTALLING BR ACKET FIGURE 3: Bracket Installation Diagram 1. Lift bracket to 900 angle. 2. Tighten lower bolts on bracket. 3. Insert two bolts into the holes, secure using washers and nuts provided.
- Page 14 MOUNTING FIGURE 4: Mounting Dimensions Dimension Specification It is reccommended that the Fan shroud be hung a minimum of 6 in (152.4 mm) above the top of any fan coils Minimum clearance of 18 in (457.2 mm) around fan intake. Minimum clearance of 36 in (915 mm) around fan shroud.
- Page 15 ELECTRICAL FIGURE 5: Connection Diagram...
- Page 16 Signal Color Spec Connector S-DSVF-115V and S-DSVF-220V Control Methods 0-10V V.DC / PWM DC10V Power Output +10V V.DC Tach Output* 12 Pulse/R Duty 20% to 70% 0 - 1 0 V / Yellow Over-Temperature, Over-Current, Locked-Rotor, Protection Function 12MS-4-A3 Lock-Voltage, Over-Voltage...
-
Page 17: Routine Maintenance
Mix warm water and a simple detergent (that is non-corrosive to aluminum or copper), such The Surna Destrat Ventilator should be cleaned and as Cal-Green or Evap-Green, in a spray bottle, assessed for damage at least once every 6 months. -
Page 18: Troubleshooting
TROUBLESHOOTING CONTACT US UNIT NOT PRODUCING ENOUGH AIRFLOW To avoid voiding the warranty, please contact Surna via email at support@surna.com or via phone at Verify proper power is supplied of 115V or 220V. 303.993.5271 before having a technician perform work. - Page 19 NOTES...
- Page 20 1780 55th Street Boulder, CO 80301 303.993.5271 info@surna.com s u r n a . c o m *Information is subject to change without notice.
