- Page 1 TECHNOLOGY MANUAL INSTANTANEOUS GAS WATER HEATER MODEL: 5L/6L CF EDITION: 01 / MAY, 2007 ISSUED BY MTS (CHINA)
-
Page 2: Table Of Contents
Technology Manual – Instantaneous Gas Water Heater 5L/6L CF INDEX Characteristic & Function…………………………………………………………………..2 - - 4 Outlook & summary………………………………………………………………………….2 General technology data………………………………………………………………………3 Function……………………………………………………………………………………….4 Structure & Components……………………………………………………………………5 - - 8 Structure & Main components list…………………………………………………………….5 Gas & water valve…………………………………………………………………………….6 Work and control program……………………………………………………………………7 Electric circuit…………………………………………………………………………………8 Installation…………………………………………………………………………………9 - - 15 Product dimension........................9... -
Page 3: Outlook & Summary
Technology Manual – Instantaneous Gas Water Heater 5L/6L CF OUTLOOK & SUMMARY Exhaust flue pipe Digital temperature display Flame window Water adjust knob, control heating water volume Winter/Summer switch knob; control half or whole burner working Battery power light Gas adjust knob, control gas combustion input power Battery power switch Battery box, 2 pcs A1 inside Cold water inlet with filter, G1/2”... -
Page 4: General Technology Data
Technology Manual – Instantaneous Gas Water Heater 5L/6L CF GENERAL TECHNOLOGY DATA Model 5L CF 6L CF Hot water output(L/Min) Heat input(KW) Heat efficiency >80% Gas type Liquefied Petroleum Gas(LPG) / Natural gas (NG) Gas pressure (Kpa) 2.8---LPG / 2.0---NG Gas consume ( M3/h) 0.367-PG / 1.029- NG... -
Page 5: Characteristic & Function
Technology Manual – Instantaneous Gas Water Heater 5L/6L CF FUNCTION 1. Convenient This water heater needs two A1 batteries to feed micro-computer(IC) power. You only need to turn on the power button, open the gas valve, cold water valve and hot water valve; warm water will be supplied continuously after several seconds. -
Page 6: Structure & Main Components List
Technology Manual – Instantaneous Gas Water Heater 5L/6L CF TRUCTURE & MAIN COMPONENTS Flue connector Hang holds (￠127mm ) Flue exhaust holder Temp. limit sensor (6L) Heating exchanger (H.E) Ignition sensor Burner Flame sensor W/S gas valve Water valve Gas valve Microswitch Ignition control(IC) Solenoid valve... -
Page 7: Gas & Water Valve
Technology Manual – Instantaneous Gas Water Heater 5L/6L CF GAS & WATER VALVE PART DESCRIPTION PART DESCRIPTION Gas adjust valve Water tap O ring 14.3*9*2.65 O ring Mechanical gas valve ring base Steady spring Mechanical gas valve ring Steady spring fixed support Mechanical gas valve ring Steady spring support axis... -
Page 8: Work And Control Program
Technology Manual – Instantaneous Gas Water Heater 5L/6L CF WORK AND CONTROL PROGRAM Install battery Open water Check failure Microswitc Close water Close water Sparking Open gas valve Flame sensing Stop ignition Working Safety device - 7 -... -
Page 9: Structure & Components
Technology Manual – Instantaneous Gas Water Heater 5L/6L CF ELECTRIC CIRCUIT Ignition Flame sensor To temp. limit LED/ display light Yellow Black Microswitch Black - Red + To solenoid valve Battery box - 8 -... -
Page 10: Product Dimension
Technology Manual – Instantaneous Gas Water Heater 5L/6L CF PRODUCT DIMENSION - 9 -... -
Page 11: Installation Place Requirement
Technology Manual – Instantaneous Gas Water Heater 5L/6L CF INSTALL PLACE REQUIREMENT Installation should be conducted by certificated professionals. 1) Preparation before installation: Make sure of accordance of all the accessories with the provisions in the instruction Make sure of accordance of the gas to be applied with the requirement of nameplate 2) Installation place requirement The heater should be installed in a well ventilated place or room, such as: kitchen, a room not used for living, well ventilated corridor... - Page 12 Technology Manual – Instantaneous Gas Water Heater 5L/6L CF Inlet port Here lead directly to the air outdoors. 3) Position for installation Some effective measures must be taken if the heater is fixed on the wall, which is made up of some inflammable materials. The insulation board should be with a length of all sides 0.1m longer than that of the heater’s casing.
- Page 13 Technology Manual – Instantaneous Gas Water Heater 5L/6L CF It is not allowed to use the heater and the fan at the same time. If it is necessary, a window or door must be opened. The length of the gas tube which connects the heater to the gas pipe in the room or to a gas bottle filled with liquefied petroleum gas (LPG), must be less than 2 meters.
-
Page 14: Fixation Of Heater
Technology Manual – Instantaneous Gas Water Heater 5L/6L CF FIXATION OF HEATER 1) The place and the size of water inlet, water outlet and gas inlet to see the heater. 2) Drill two holes (Φ8, depth 50mm)in the wall according to the size of the A, and insert two Φ8 plastic expansion bolt into the holes. -
Page 15: Water Pipe And Gas Pipe
Technology Manual – Instantaneous Gas Water Heater 5L/6L CF WATER PIPE AND GAS PIPE 1) It must fix the controlling valves at the water inlet , outlet and gas pipe, 2) The wire and the gas pipe are not allowed behind or above the heater. 3) The length of the gas tube which connects the heater to the gas pipe in the room or to a gas bottle filled with liquefied petroleum gas (LPG), must be less than 2 meters. -
Page 16: Installation
Technology Manual – Instantaneous Gas Water Heater 5L/6L CF EXHAUSTING PIPE 1) This product is Natural-flue type. While operating it consumes oxygen from the air of the room and exhausts the fume out of the room by the flue pipe 2) The flue pipe must be fixed on the heater, and its installation should accord with the above drawing 3) The flue pipe should be made up of heat-resistant and corrosion-proof materials (stainless steel... -
Page 17: Use Instruction
Technology Manual – Instantaneous Gas Water Heater 5L/6L CF USE INSTRUCTION Preparative Fix 2pcs A1 dry battery into the battery box. Open the gas valve and water inlet valve Turn on the battery power switch which is located at the bottom of the heater Ignition Open the hot water valve, the heater will ignite automatically, but the water pressure must be more than 0.025MPa. -
Page 18: General Safety Instruction
Technology Manual – Instantaneous Gas Water Heater 5L/6L CF GENERAL SAFETY INSTRUCTION Make sure of accordance of the gas to be applied with the requirement of nameplate Example: Gas type: NG (natural gas) 12T Gas Pressure: 2000Pa If the gas type of the heater needs to be exchanged, it must be conducted by certificated professionals Check whether the gas pipe leaks or not Please smear soap water on the connector, to check whether the gas pipe leaks or not. - Page 19 Technology Manual – Instantaneous Gas Water Heater 5L/6L CF If the air temperature falls below 0℃, unscrew the water plug near the inlet and let out the water in the heater, after that, screw down the plug. If the heater has not been used in a long time please let the water out of the heater too.
- Page 20 Technology Manual – Instantaneous Gas Water Heater 5L/6L CF General failure & Solution 1. If the water heater is only used occasionally, it may switch off suddenly. Cause: Too low voltage of battery supplying for ignition control(IC) and gas solenoid valve. Too low water pressure.
- Page 21 Technology Manual – Instantaneous Gas Water Heater 5L/6L CF If ignition can not spark properly, change IC. ※Technology knowledge: Min. working water pressure is 0.025 Mpa (0.25 kgf/cm microswitch and The correct connection situation for water driving axis is as shown in the following picture 2.
- Page 22 Technology Manual – Instantaneous Gas Water Heater 5L/6L CF 3> Check whether g solenoid valve can open or not when sparking; Listen the opening sound “Da” or touch to feel the opening vibration or measure the voltage at the gas valve with a multimeter. If this isn’t working, disconnect the solenoid valve from the base, remove any dirty on its surface and reassemble.
- Page 23 Technology Manual – Instantaneous Gas Water Heater 5L/6L CF hold Circumfluence Driving axis Mechanical gas valve spring Plastic septum 4. Water heater can not spark (ignition) Cause: Battery voltage is too low; Water pressure is too low. Microswitch can not drive(ON); Microswitch failure;...
-
Page 24: General Failure & Solution
Technology Manual – Instantaneous Gas Water Heater 5L/6L CF Check that all electric connectors are ok or broken off. Finally replace IC. 5. Hot water does not reach the wished temperature. Cause: Gas pressure is too low; Gas switch is not opened enough; Mixing too much cold water;...
