Griven nanoParade AL4484 User Manual

nanoParade
AL4484
Technical Data
Length / Lunghezza
Weight / Peso
Housing / Corpo proiettore
IK rating / classe IK
IP rating / grado IP
Ambient temp./ Temperatura ambientale
Power consumption / Alimentazione
Leds per meter / Numero di Leds
Power consuption / Potenza massima
Nominal current / Corrente nominale
Thermal protection / Protezione termica
Electrical class / Classe elettrica
Cable length / Lunhezza del cavo
Control system / Sistema di controllo
DMX Channels / Canali
Color range / Colori
RGB version
Optics/ Ottiche
Order codes
LENGTH
03 320 mm
06 620 mm
12 1220 mm
OPTIONS
A Active
P Passive
A
With cables and connectors
B With cables
S Standard fixing
L With fixing bracket
F With fixing brackets
Exemple of code combination
Griven S.r.l. - Via Bulgaria, 16
46042 Castel Goffredo
Mantova - Italy
User Manual
Rev. 1.00
Date: 27/06/2017
320 mm
0,2 Kg ( 0,44 Lbs)
4.6 W (RGB) 3W (White)
0,6 A /m (RGB) 0,4 A /m (White)
Theoretical variety of infinite color hues.
CODES EXTENSION
LED TYPE
RG RGB
CW COLD WHITE
WW WARM WHITE
DW DYNAMIC WHITE
LED bar with in-built DMX receiver
LED bar without in-built DMX receiver
Fitted with IN and OUT power and data cables (L=200) and IP67 connectors
Fitted with IN and OUT power and data cables ( L=200mm)
Fixing system for perpendicular projection
Adjustable fixing bracket for beam orientation ( for 320mm long bars)
Adjustable fixing brackets for beam orientation ( for 620mm and 1220mm long bars)
AL4484
Please combine the required
AL4484 + LENGTH + LED TYPE
Tel. +39.0376.779483
© Copyright Griven 2017 - Griven reserves the right to make
changes to this product and related instructions at any time
Fax +39.0376.779682
without prior notice and such changes shall be effective
E-mail: sales@griven.com
immediatly
Web: www.griven.com
AL4484 nanoParade
620 mm
0,4 Kg ( 0,88 Lbs)
Anodized Alluminum, Stainless Steel Brackets
IK08
IP67
-40°C to 50°C ( -40°F to122°F)
24 Vdc
50 (RGB) 70 (White)
9.2 W (RGB) 6W (White)
0,6 A /m 0,4 A /m (White)
Electronic
200 mm
USITT DMX-512 - RDM ( only RGB version)
3 ch.(RGB) 1 ch. (WHITE)
Theoretical variety of infinite color hues.
120°
ON REQUEST
03 RG A B L
+ OPTION to order
.
0,8 Kg (1,76 Lbs)
18.4 W (RGB) 12W (White)
0,6 A /m 0,4 A /m (White)
III
Theoretical variety of infinite color hues.
1220 mm
