Chiltern Model Steam Engines

Mill Twin Cylinder Model Steam Engine v2 Assembly Instructions v1.1

Notes:

In overview the engine should first be assembled "dry" with no oil/lubricants, thread lock or

gasket sealant applied, then disassembled, polished, painted as required, and finally re-

assembled lubricating and applying thread lock and gasket sealant as applicable.

The engine will work properly "dry" but if it is to be run under load, it is recommended that

thread lock, such as Loctite 222 Screwlock (or equivalent low strength locking compound) be

used to stop the fasteners from coming loose. Also that a gasket sealant, such as Loctite

Instant Gasket (or equivalent), is used on the cylinder's mating surfaces with the end plates

and Chest. Both thread lock and gasket sealant can be purchased for a small sum from

automotive shops or on the internet.

Although all sharp edges and burrs should have been removed during manufacturing, check

all parts and if any sharp edges or burrs exist carefully remove them with a metal file.

It is recommended that the base castings are painted. Hammerite's range of metal paint

sprays work well for this application although do take a long time to dry between coats, up

to a week before the engine can finally be assembled. Use masking tape to cover the mating

surfaces or scrape off the paint as needed afterwards.

For polishing the brass components, wet and dry paper can be used - start with coarse e.g.

280 grade to get the worst marks out of the brass work and end with very fine paper, e.g.

1500 grade and finally Brasso and a rag.

Be careful not to over tighten or cross thread the capscrews, use only a small and/or

medium screw driver. If excessive force is being used there is probably something out of

alignment.

Always check

www.chilternmodesteam.co.uk

and tips. Any questions or comments good or bad, please don't hesitate to contact us via

email: sales@chilternmodelsteam.co.uk.

We would be grateful if you would take some pictures of your completed model and email

them to us for inclusion on our WEB site.

Tools required for assembly depend on which screws have been supplied with the kit but

can include; M2 (4mm) and M3 (5.5mm) open ended spanners, 2.5mm (preferable long)

Hex/Allen Key, 1.5mm Allen/Hex Key, medium slot screw driver, metal file and small pliers,

metal hack saw.

10.

NOTE: some of the screws as provided in the kit may need to the cut or filed to length,

please contact us if this presents a problem and we will work on a solution.

for the latest assembly drawing, instructions

Page 1.
