7201
OPERATING
INSTRUCTIONS
USB Digital Scale
Jan 2011
Figure 01 - Model 7201W10 USB Digital Scale in case
_____________________________________________________________________________
SOILMOISTURE EQUIPMENT CORP.
P.O. Box 30025, Santa Barbara, CA. 93130 U.S.A.
Telephone (805) 964-3525
www.soilmoisture.com – sales@soilmoisture.com
Advertisement
Table of Contents
Related Manuals for Soilmoisture Equipment 7201
Summary of Contents for Soilmoisture Equipment 7201
- Page 1 7201 OPERATING INSTRUCTIONS USB Digital Scale Jan 2011 Figure 01 - Model 7201W10 USB Digital Scale in case _____________________________________________________________________________ SOILMOISTURE EQUIPMENT CORP. P.O. Box 30025, Santa Barbara, CA. 93130 U.S.A. Telephone (805) 964-3525 www.soilmoisture.com – sales@soilmoisture.com...
-
Page 2: Table Of Contents
TROUBLESHOOTING ......................18 GENERAL CARE AND MAINTENANCE ..................19 PARTS LIST ..........................19 REPLACEMENT PARTS .......................19 ASSESORIES AND USEFUL ITEMS FOR THIS UNIT ............19 COMBO KITS ........................19 SOILMOISTURE EQUIPMENT CORP. P.O. Box 30025, Santa Barbara, CA. 93130 U.S.A. Telephone (805) 964-3525 www.soilmoisture.com – sales@soilmoisture.com... -
Page 3: Unpacking
Be sure to read all operating instructions thoroughly before operating the unit. Remove the Model 7201 Scale from the shipping box. In the box is also a USB cable for connecting the Scale to a PC or to Soilmoisture Equipment Corp. (SEC) Model 7205 Record it in a Flash. -
Page 4: Aquaint Yourself With The Parts
Shuts down after 5 min of non use in battery • Power AC adapter; 9V, 100mA negative center • USB Self Powered • 6 x AA Alkaline battery (not supplied) SOILMOISTURE EQUIPMENT CORP. P.O. Box 30025, Santa Barbara, CA. 93130 U.S.A. Telephone (805) 964-3525 www.soilmoisture.com – sales@soilmoisture.com... -
Page 5: Features And Functions
The scale is designed to operate in a normal room temperature. If subjected to cold or warm temperature, it should be allowed to reach the room temperature before operating. SOILMOISTURE EQUIPMENT CORP. P.O. Box 30025, Santa Barbara, CA. 93130 U.S.A. Telephone (805) 964-3525... -
Page 6: How To Use And/Or Operate Unit
Figure 03 - Connect USB cable at the back of scale Battery & Power Installation 1. Insert 6 batteries (Fig.04). Figure 04 - Inserting the batteries Figure 05 - USB cable Set-up SOILMOISTURE EQUIPMENT CORP. P.O. Box 30025, Santa Barbara, CA. 93130 U.S.A. Telephone (805) 964-3525 www.soilmoisture.com – sales@soilmoisture.com... -
Page 7: Weighing Function
(e.g. gm key for grams or OZ key for ounces weight display and so on).The weight is updated on the LCD after the weight placed on the platform is stable. Figure 06 - Scale Weighing Function SOILMOISTURE EQUIPMENT CORP. P.O. Box 30025, Santa Barbara, CA. 93130 U.S.A. Telephone (805) 964-3525... -
Page 8: Sampling Function
It is necessary to make a sample counting of the items to be counted first before the COUNT function can be used. New Count Sampling 1. Press NEW COUNT SAMPLING key. SOILMOISTURE EQUIPMENT CORP. P.O. Box 30025, Santa Barbara, CA. 93130 U.S.A. Telephone (805) 964-3525 www.soilmoisture.com – sales@soilmoisture.com... - Page 9 5. After this, it will prompt to put the sample items on the platform (please put exact number of items as entered above to ensure accurate sampling). SOILMOISTURE EQUIPMENT CORP. P.O. Box 30025, Santa Barbara, CA. 93130 U.S.A. Telephone (805) 964-3525...
- Page 10 It is best to sample the scale once in a while if it is used to count one kind of item only. SOILMOISTURE EQUIPMENT CORP. P.O. Box 30025, Santa Barbara, CA. 93130 U.S.A.
-
Page 11: Counting Function
The number of items (or the count) on the platform is displayed on the LCD once the weight has stabilized. SOILMOISTURE EQUIPMENT CORP. P.O. Box 30025, Santa Barbara, CA. 93130 U.S.A. Telephone (805) 964-3525... - Page 12 The scale will display “Added to memory” once the operation is completed. Example, if the current count SOILMOISTURE EQUIPMENT CORP. P.O. Box 30025, Santa Barbara, CA. 93130 U.S.A.
- Page 13 Displaying Count Stored in Memory While in counting mode, press MR key to display the count value that is currently stored in memory. SOILMOISTURE EQUIPMENT CORP. P.O. Box 30025, Santa Barbara, CA. 93130 U.S.A. Telephone (805) 964-3525 www.soilmoisture.com – sales@soilmoisture.com...
- Page 14 At this time, press CE key to erase this value stored in memory. The scale will display “Memory erased!” once the operation is completed. SOILMOISTURE EQUIPMENT CORP. P.O. Box 30025, Santa Barbara, CA. 93130 U.S.A. Telephone (805) 964-3525...
-
Page 15: Tare Function
“T” appears at the lower left corner of the LCD when the Tare function is currently enabled. SOILMOISTURE EQUIPMENT CORP. P.O. Box 30025, Santa Barbara, CA. 93130 U.S.A. Telephone (805) 964-3525... -
Page 16: Hold Display Function
DISPLAY key then put the item on the platform. The weight of the item will be displayed on the LCD for about 10 seconds even if the item is removed from the platform. SOILMOISTURE EQUIPMENT CORP. P.O. Box 30025, Santa Barbara, CA. 93130 U.S.A. -
Page 17: Calibration
2kg weight to be put on the platform. Put 2kg weight and the scale will calibrate itself. Once calibration is successful, the scale will go to weighing mode. To exit user calibration without completing, simply press CE key. SOILMOISTURE EQUIPMENT CORP. P.O. Box 30025, Santa Barbara, CA. 93130 U.S.A. Telephone (805) 964-3525... -
Page 18: Troubleshooting
Low Bat blinks at the upper right corner of the LCD. Please replace the battery as soon as possible. Operation with low battery is possible but the accuracy of the scale is affected. SOILMOISTURE EQUIPMENT CORP. P.O. Box 30025, Santa Barbara, CA. 93130 U.S.A. Telephone (805) 964-3525... -
Page 19: General Care And Maintenance
Record it in a Flash battery powered recorder COMBO KITS 7201PKG7201W05 RIF + USB Digital Scale, 5Kg 7201PKG7201W10 RIF + USB Digital Scale, 10Kg SOILMOISTURE EQUIPMENT CORP. P.O. Box 30025, Santa Barbara, CA. 93130 U.S.A. Telephone (805) 964-3525 www.soilmoisture.com – sales@soilmoisture.com... - Page 20 ____________________________________________________________________________ With dealers throughout the world, you have convenience of purchase and assurance of after sales service. © COPYRIGHT 2011 ALL RIGHTS RESERVED 0898-7201 SOILMOISTURE EQUIPMENT CORP. P.O. Box 30025, Santa Barbara, CA. 93130 U.S.A. Telephone (805) 964-3525 www.soilmoisture.com – sales@soilmoisture.com...
