Summary of Contents for Ice AP901
- Page 2 Electrical equipment should be installed, operated, serviced, and maintained only by qualified personnel. Local safety regulations should be followed. No responsibility is assumed by ICE for any consequences arising out of the use of this material. We reserve right to changes without further notice.
-
Page 3: Table Of Contents
Instruction manual – AP901 Arc Protection Unit 3 (39 TABLE OF CONTENTS 1 ABBREVIATIONS ......................5 2 GENERAL ......................... 6 Arc protection unit AP901 features ................6 Simplified block diagram ..................8 3 OPERATION AND CONFIGURATION ................9 LED indicator functions .................... 9 LED Operation Quick Guide ................... - Page 4 Instruction manual – AP901 Arc Protection Unit 4 (39 10.1 Carrying out testing in light only mode ..............31 10.2 Carrying out testing in light and current mode ............32 10.3 Testing the CBFP function ..................33 10.4 Testing arc flash protection unit operation time ............33 10.5 Test plan example ....................
-
Page 5: Abbreviations
Instruction manual – AP901 Arc Protection Unit 5 (39 BBREVIATIONS CB – Circuit breaker CBFP – Circuit breaker failure protection EMC – Electromagnetic compatibility EPROM – Erasable programmable read only memory HW – Hardware LED – Light emitting diode LV – Low voltage ms –... -
Page 6: General
AP901 is a multipurpose arc flash protection unit and can be applied for variety of applications. AP901 can be used as a stand-alone unit or as part of a more complex arc protection system through the binary bus. Main features of AP901:... - Page 7 Instruction manual – AP901 Arc Protection Unit 7 (39 Figure 2-1: Arc protection unit AP901 A1017B...
-
Page 8: Simplified Block Diagram
Instruction manual – AP901 Arc Protection Unit 8 (39 IMPLIFIED BLOCK DIAGRAM AP901 simplified block diagram in Figure shows the main components of the AP901 unit. Figure 2-2: AP901 simplified block diagram A1017B... -
Page 9: Operation And Configuration
PERATION AND CONFIGURATION INDICATOR FUNCTIONS AP901 contains 12 indication LEDs. A user definable text pocket can be slid in for identifying each LED function (except Power and Error LEDs). LED’s are located at the front plate of the unit for clear viewing without a need for opening doors. -
Page 10: Led Operation Quick Guide
Instruction manual – AP901 Arc Protection Unit 10 (39 LED O PERATION UICK UIDE STEADY ACTION IF BLINKING ABNORMAL POWER Auxiliary supply Auxiliary power Check the power source Blue disconnected connected Verify system condition. see Configuration ERROR chapters 11: Troubleshooting... -
Page 11: Push-Button Description
11 (39 BUTTON DESCRIPTION AP901 contains one single push-button (SET) that can be used for all operational functions of the unit. The push-button is utilized for auto-configuration of the system (see chapter 3.3.1) and for resetting the indicators and latched output relays. -
Page 12: Dipswitch Settings
12 (39 IPSWITCH SETTINGS AP901 functionality such as tripping logic is configured using dipswitch settings. Different trip schemes can be easily programmed by selecting the appropriate dipswitch positions. This gives users the flexibility to change settings dependent on application. Tripping may be selected based on arc light only or arc light and current thresholds (or other tripping criteria such as undervoltage, or similar). - Page 13 Scheme selection Refer to chapter 3.5.1 and Refer to chapter 3.5.1 and 6 Scheme select Table 3-2 AP901 dipswitch setting selection The chapter 3.5.1 shows AP901 internal logic and dipswitch selections. For input and output descriptions refer to chapter 7. A1017B...
-
Page 14: Scheme Select Dip-Switch Settings
Logic scheme 0 The AP901 logic scheme 0 can be not only applied as stand-alone arc protection unit, but also widely used as non-selective outgoing feeder compartment protection. Depend on this scheme, user can select either light only mode or arc light + overcurrent mode to trip all circuit breakers. - Page 15 Logic scheme 1 The AP901 logic scheme I is mainly utilized in selective arc protection solution. The fiber sensor S1 monitors the outgoing feeder cable compartment. The fiber sensor S2 monitors the corresponding feeder breaker compartment and busbar compartment. Trip contact T1 is responsible for tripping circuit breaker of the outgoing feeder.
-
Page 16: Non-Volatile Memory
Instruction manual – AP901 Arc Protection Unit 16 (39 General trip logic for AP901 (SS: 1) TRIPPING SIGNALS FAULT LOCATION ╳ ╳ ╳ ╳ ╳ S3, S4, S5 ╳ ╳ ╳ ╳ ╳ ╳ ╳ ╳ ╳ VOLATILE MEMORY All critical system data including dipswitch settings and auto-configuration file described in chapter 3.3.1 are stored in EPROM non-volatile memory to ensure correct operation and full... -
Page 17: Arc Sensors
The detailed instructions are described in “Arc Sensors Series – Instruction booklet”. ENSOR EPENDENCIES Different sensor types can be utilized with the AP901 arc flash protection unit. The table below describes the dependencies. AS01 AS02... -
Page 18: System Self-Supervision
If one or more of the sensors are disconnected the healthy sensors remain in use and unit remains operational accordingly. The AP901 will remain in error mode until the disconnected sensors are repaired. -
Page 19: Application Examples
ICE representative for a solution to your particular application. APPLICATION WITH CURRENT AND LIGHT CONDITION AP901 may be applied requiring both overcurrent and arc light conditions for trip. In this case tripping is performed only if both conditions are fulfilled simultaneously. Typically the overcurrent condition is obtained from the AP910 unit and the trip relay will be activated in 7ms. - Page 20 Instruction manual – AP901 Arc Protection Unit 20 (39 LV or MV application by AP901. Figure 6-1: This LV or MV application example has light and current tripping criteria for sensor channels S2, S3 and S4. The sensor channel S1 monitoring the zone before CT is set to operate on light only.
-
Page 21: Wind-Power Application Example (Light Only Condition)
Synchronous Generator (PMSG) is applied with a converter cabinet and LV/MV transformer. The AP901 is equipped with four point sensor channels and each channel may have up to three sensors (type AS01) connected in series allowing for up to 12 point sensors. Additionally one fiber optic loop sensor channel is available as an option. - Page 22 Instruction manual – AP901 Arc Protection Unit 22 (39 Figure 6-2: Typical wind-power application by AP901. A1017B...
-
Page 23: Circuit Breaker Failure Protection (Cbfp)
Breaker failure function is activated if AP901 detects the presence of light after a set operate time. When AP901 is set to operate on light and current both parameters must persist to activate CBFP. Breaker failure can be set to operate either on 100ms or 150ms delay (see chapter 3.5). -
Page 24: Connections
Instruction manual – AP901 Arc Protection Unit 24 (39 ONNECTIONS A1017B... -
Page 25: Outputs
25 (39 UTPUTS 7.1.1 T RIP RELAYS The AP901 unit has integrated trip relays T1 and T2 for tripping of the circuit-breakers. T1 and T2 relays are normally open type (NO). 7.1.2 T RIP RELAYS T3 relay output may act either as an electronic lock-out relay or as a trip relay. This option must be specified when ordering. -
Page 26: System Failure Relay Sf
AS02) may be connected to each channel. AP901 has an option of one fiber optic loop sensor channel with transceiver and receiver (Tx, Rx). When the fiber optic loop sensor is connected to the unit one end is connected to Tx and another to Rx. -
Page 27: Auxiliary Voltage
Instruction manual – AP901 Arc Protection Unit 27 (39 Note: when AP901 receives overcurrent signal from NP900 Series protection relays the actual operation time depends on the operation time of the external device and so total operational time cannot be specified or guaranteed. -
Page 28: Wiring Diagram
Instruction manual – AP901 Arc Protection Unit 28 (39 IRING DIAGRAM Figure 8-1: Wiring diagram of AP901 unit. A1017B... -
Page 29: Dimensions And Installation
Instruction manual – AP901 Arc Protection Unit 29 (39 IMENSIONS AND INSTALLATION AP901 is either door mounted or panel mounted in standard 19 inch rack (height of 4U and 1/8 of a unit wide). Figure 9-1: AP901 dimensions in millimeters (side view) - Page 30 Instruction manual – AP901 Arc Protection Unit 30 (39 23,5 Figure 9-2: AP901 cut out for panel mounting (millimeters) A1017B...
-
Page 31: Testing
10 T ESTING It is recommended that the AP901 unit is tested prior to substation energizing. Testing is carried out by simulating arc light to each sensor and verifying the tripping and LED indication. For arc light simulation use a superior camera flash type: Canon Speedlite 430EX or equivalent. -
Page 32: Carrying Out Testing In Light And Current Mode
Instruction manual – AP901 Arc Protection Unit 32 (39 10.2 C ARRYING OUT TESTING IN LIGHT AND CURRENT MODE Check that the dipswitch setting positions are in accordance with your application Activate the camera flash within 20cm (12 inches) of the AS01 sensor unit and activate the binary input BI1 used for overcurrent condition simultaneously. -
Page 33: Testing The Cbfp Function
10.4 T ESTING ARC FLASH PROTECTION UNIT OPERATION TIME The AP901 operation time test is not required at commissioning as it is performed by the manufacturer as a type test and routine production test. Refer to routine test reports sent with AP901 unit and consult your nearest ICE representative for type test reports. -
Page 34: Test Plan Example
Instruction manual – AP901 Arc Protection Unit 34 (39 10.5 T EST PLAN EXAMPLE Date: Substation Switchgear: AP901 serial number: Preconditions Light only Light + current Remark Sensor channel 1 setting Sensor channel 2,3,4 setting Master trip binary input in use... -
Page 35: Troubleshooting Guide
Instruction manual – AP901 Arc Protection Unit 35 (39 11 T ROUBLESHOOTING GUIDE Problem Check Cross reference Sensor does not activate when Sensor cable wiring Refer to « Arc Sensors Series - testing Instruction booklet » Camera (or other test equipment) -
Page 36: Technical Data
Instruction manual – AP901 Arc Protection Unit 36 (39 12 T ECHNICAL DATA 12.1 P ROTECTION Trip time using mechanical trip relays 7ms* Reset time (arc light stage) Protection operational after power up 88ms *total trip time using arc light (L>) or phase/residual overcurrent (I>) from AP910 and arc light (L>) 12.2 A... -
Page 37: Binary Inputs Bi1, Bi2
Instruction manual – AP901 Arc Protection Unit 37 (39 12.5 B BI1, BI2 INARY NPUTS Rated voltage 24 or 110 or 220Vdc Rated current 3 mA Number of inputs 12.6 D ISTURBANCE TESTS EMC test CE approved and tested according to EN... -
Page 38: Mechanical Tests
Instruction manual – AP901 Arc Protection Unit 38 (39 12.8 M ECHANICAL TESTS Vibration test 2 ... 13.2 Hz ±3.5mm 13.2 ... 100Hz, ±1.0g Shock/Bump test acc. to IEC 60255- 20g, 1000 bumps/dir. 21-2 12.9 C ASING AND PACKAGE Protection degree (front) - Page 39 Instruction manual – AP901 Arc Protection Unit 39 (39 A1017B...
