Scope and Recommendations
The ICC Model VIP+ is a double wall construction listed venting system designed for venting boilers, engines and other
commercial and industrial heating appliances. Positive pressure piping system up to 60" w.c. (15 Pa.).
Listed Models :
Sizes:
Ø6" (152mm) to Ø24" (610mm) Flue Diameters
G
A major cause of vent related fires is failure to maintain required clearances (air space) to combustible materials. It is of utmost
•
importance that this venting system be installed only in accordance with these instructions. Do not fill the air space with insulating
material.
Contact local building or fire officials about restrictions and installation inspection in your area.
•
Do not begin installing the ICC Model VIP+ venting system until you have carefully read the appliance and vent system installation instructions.
Use only ICC Model VIP+ components. Failure to do so will void the certification and warranty of the product.
Keep these installation and operating instructions in a safe location for future reference.
Examine all components for possible shipping damage prior to installation.
•
Proper joint assembly is essential for a safe installation.
•
Follow these instructions exactly as written.
•
Check tightness of joints upon completion of assembly.
•
This venting system must be free to expand and contract.
•
This venting system must be supported in accordance with these instructions.
•
Check for unrestricted vent movement through walls, ceilings, and roof penetrations.
•
Different Manufacturers Have Different Joint Systems and Adhesives.
•
Do Not Mix Pipe, Fittings, or Joining Methods from Different Manufacturers.
•
Tested and Listed to:
UL-103 , UL-2561 , ORD ULC C-959 , UL-1978 , ULC-S662
by Underwriters Laboratories, Inc (Listing # MH16722)
Positive Pressure Chimney System
INSTALLATION AND MAINTENANCE INSTRUCTIONS
VIP+ Double Wall Air Insulated Chimney (1" Air Space)
VIP+ Double Wall 1" Fiber Insulation
VIP+ Double Wall 2" Fiber Insulation
VIP+ Double Wall 4" Fiber Insulation
ICC - Model VIP+
and Grease Duct
WARNING
ICC INDUSTRIAL CHIMNEY COMPANY INC.
400 J.F. Kennedy, St. Jérome
Québec, Canada, J7Y 4B7
Tel.: (450) 565-6336
Fax: (450) 565-6519
www.icc-rsf.com
VIP+_2016-04
