BEFORE YOU BEGIN ²
BEFORE YOU BEGIN
Please read these instructions carefully to familiarize yourself with the required tools, materials, and installation sequences.
Follow the sections that pertain to your particular installation. This will help you avoid costly mistakes. In addition to proper
Installation, read all operation and safety instructions.
All information in these instructions is based upon the latest product information available at the time of publication.
ORDERING INFORMATION
URINAL MANUAL FLUSH VALVT...........................K-17906T
INSTALLATION CONDITIONS
*
Make sure that the Inlet pipe is available, and flushed by water before installation, so that the pipe is free from jam
*
The inner diameter of the water-inlet pipe is fitted to the product
*
*
FEATURES AND FUNCTIONS
* Time-lapse flushing and auto shut-down.
* Cupule-like gasket proof, which is suitable for both super high and low hydraulic
pressure.
* Simple and elegant design; easy installation and operation.
*
*
FUNCTION PARAMETERS
Nominal Diameter DN
Inlet pipe screw thread
Nominal Pressure
DN
1058841-T01-A
1061584-T01-A
INSTALLATION
INSTRUCTIONS
20
G1/2
0.75Mpa
20
G1/2
0.75Mpa
URINAL MANUAL FLUSH VALVE
Applicable medium
Medium temperature
-1-
K-17906T
.........................................K-17906T
Water
50
50
