- Page 1 AIRBLOC AS AIRBLOC SLIMLINE ENERGY SAVING AIR CURTAINS User instructions & installation manual...
- Page 2 AIRBLOC AS AIRBLOC SLIMLINE ENERGY SAVING AIR CURTAINS Index Introduction Product range selection guide Mounting options Fixing instructions Wiring instructions Controls Infra-red Commissioning Maintenance Warranty Dimension data Wiring diagrams & interconnects User instructions...
- Page 3 Figure 1 1. Introduction The Airbloc slimline is a range of aesthetic high quality air curtains designed for surface mounting to suit External air, gases dust applications such as hotels, cinemas, Heated air remains and insects excluded retail outlets, commercial premises, cold inside maintaining rooms or any similar environment where internal environment...
- Page 4 AIRBLOC AS AIRBLOC SLIMLINE ENERGY SAVING AIR CURTAINS 2. Product range selection guide Model Mini Standard High High Maximum door height (m) Ambient air curtains Electric heated air curtains Ambient models Model AS100 AR AS160 A AS200 A Motor orientation Centre Centre Maximum door width...
-
Page 5: Mounting Guide
Figure 2 Wall mountings 3. Mounting guide AS70ES04 & AS80ES03 Airbloc slimline units should be installed horizontally directly over the door opening. It is recommended that the air curtain is installed on the inside of the building, withn the open room space against a wall or ceiling as shown in Figures 2 to 4. - Page 6 AIRBLOC AS AIRBLOC SLIMLINE ENERGY SAVING AIR CURTAINS Ambient Models (Fig 10) Electrically heated models (Fig 5-9) 4. Fixing point data Capacity Model Airbloc slimline air curtains are supplied AS160A 1200 AS160SE12 1100 with M6 nuts for installation to either the Standard AS200A 1400...
- Page 7 Figure 9 AS160SE12 & AS200SE15 Figure 12 AS160A & AS200A Figure 10 AS160HE15 & AS200HE18 Figure 11 AS100AR...
-
Page 8: Wiring Instructions
AIRBLOC AS AIRBLOC SLIMLINE ENERGY SAVING AIR CURTAINS 5. Wiring instructions Warning Warning Ambient models Before installation carefully read the Always use the ON/OFF switch on the instruction manual and labels on the remote switch box to operate the unit. All slimline ambient air curtains require upper side of the air curtain and remote DO NOT operate the air curtain by means... - Page 9 Figure 16 Switchbox ASCP1-2 6. Switches & remote switchboxes Ambient models Are supplied with a remotely sited switchbox. ON/OFF, HI/LOW fan speed can be activated from the switchbox. (See Figure 16). Electrically heated models AS70SE04 are supplied with ON/OFF, HI/LOW heat settings. Switches are located adjacent to the outlet grilles.
-
Page 10: Infrared Remote Control
AIRBLOC AS AIRBLOC SLIMLINE ENERGY SAVING AIR CURTAINS Figure 20 Remote control 7. Infra-red remote control Airbloc slimline air curtains may be specially ordered with remote infra-red control. (See Figure 20). This feature greatly simplifies on site wiring and eliminates low level switches and unauthorised adjustment. -
Page 11: Commissioning & Adjustment
Figure 21 Examples of air flow adjustment 8. Commissioning & adjustment AS70SE04 All air curtains are equipped with a very flexible and simple discharge air outlet that facilitate regular and smooth air flow. Using these outlets it is possible to adjust air flow angle up to 15˚... -
Page 12: Dimension Data
AIRBLOC AS AIRBLOC SLIMLINE ENERGY SAVING AIR CURTAINS 11. Dimension data Figure 22 Slimline range AS70SE04 All other units Ambient models Dimensions in mm Models AS100AR AS160A AS200A Overall width 1157 1651 2053 Outlet width 1600 2003 Total depth Total height Outlet height Outlet width Electrically heated models... -
Page 13: Wiring Diagrams
12. Wiring diagrams Figure 23 Ambient air curtains internal wiring (AS100AR, AS160A & AS200A) LN Earth Single phase electrical supply system 230V, 50Hz Electric motor type 33-014 - 580W, 230V, 50Hz Capacitor 12µF, 400V Figure 24 ASCP1-2 Switchbox interconnecting wiring (to suit above) - Page 14 AIRBLOC AS AIRBLOC SLIMLINE ENERGY SAVING AIR CURTAINS Figure 25 Electrically heated air curtains internal wiring (AS70SE04) L, N, EARTH Single phase electrical supply system 230V, 50Hz Electric motor 230V, 50Hz, 60W Input TH, TH2 Elements thermostats Triple rocker switch 10A, 230V R1,R2,R3,R4, Electrical heating elements 230V, 1000W each...
- Page 15 Figure 26 Electrically heated air curtains internal wiring (AS80SE03) LN Earth Single phase electrical supply system 230V, 50Hz Electric motor type 60W 0.5A 230V, 50Hz Capacitors 4µF, 400V TH1,TH2 Element thermostats (cut out: 75˚C) R1, R2 Electrically heated elements 230V 1500W each Figure 27 ASCP1-4 Switchbox interconnecting wiring (to suit above)
- Page 16 AIRBLOC AS AIRBLOC SLIMLINE ENERGY SAVING AIR CURTAINS Figure 28 Electrically heated air curtains internal wiring (AS100SE06, AS100SE09, AS160SE12, AS200SE15) R,S,T,N Three phase electrical supply 415V, 50Hz M (AS100only) Electric motor type 31-873, 60W, 0.5A, 230V 50Hz M (AS160/200 only) Electric motor type 33-961, 150W, 1.25A, 230V 50Hz CAP (AS100 only) 4µf, 400V capacitor...
- Page 17 Figure 30 Electrically heated air curtains internal wiring (AS100HE12R, AS100HE12) R,S,T,N Three phase electrical supply 415V, 50Hz Electric motor type 33-014 580W 2.7A 230V, 50Hz Capacitors 12µF, 400V Fan overrun stst (cutout 35˚C) Element thermostats (cut out: 65˚C) R1, R2, R3 Electrical heating elements selector switches Common low voltage (12V) Low voltage switched...
- Page 18 AIRBLOC AS AIRBLOC SLIMLINE ENERGY SAVING AIR CURTAINS Figure 32 Electrically heated air curtains internal wiring (AS160HE15, AS200HE18) R,S,T,N Three phase electrical supply system 415V, 50Hz Electric motor type 33-014 580W 2.5A 230V, 50Hz Capacitors 12µF, 400V Fan overrun stats (cutout 35˚C) element thermostats (cut out: 65˚C) K1.1, K2.1, K2.4, K1.2, K2.2, K2.3 Contactor switch...
- Page 19 Aircurtains with wired remote switchbox may have additional controls wired in line i.e. room stat, timer, door switch, BMS, (some available as optional extras). Please refer to appropriate wiring diagram following. Failure to follow these instructions can lead to incorrect operation/irreparable damage to door curtain.
- Page 20 AIRBLOC AS AIRBLOC SLIMLINE ENERGY SAVING AIR CURTAINS Figure 36 ASCP1-6 Switchbox interconnecting wiring to suit AS100SE06R, AS100SE09R, AS160SE12, AS200SE15 Figure 37 ASCP1-6 Switchbox interconnecting wiring to suit AS100HE12R Figure 38 ASCP1-6 Switchbox interconnecting wiring to suit AS160HE15 & AS200HE18...
- Page 21 Figure 39 Ambient models 13. User instructions Ambient models Follow instructions shown in Section 3-11 . To activate the unit use the switchbox and depress the ‘ON/I’ switch. This will bring the unit on to low speed fan. To activate the high fan speed press the ‘II’...
- Page 22 AIRBLOC AS AIRBLOC SLIMLINE ENERGY SAVING AIR CURTAINS Maintenance /User instructions AS100SE06 - AS200HE18 Follow instructions shown in section 3-11. To activate the unit, use the switchbox and press the ‘ON/I’ switch. This will bring the unit on to low fan speed.
- Page 23 AIRBLOC Nordair and Airbloc are Unit 22 Battersea Road registered trademark of Ambi-Rad Mersey Heaton Industrial Estate Limited. BCEMA Stockport Cheshire SK4 3EA United Kingdom Due to continuous product innovation, Telephone 0161 219 0000 Ambi-Rad reserves the right to change Facsimile 0161 219 0001 product specification without due UK sales e-mail:sales@nordair.co.uk...
