Most accessory decoders have their own unique address (CV #513) and
some have multiple outputs (groups of 4). Accessory decoder's and loco
decoder's addresses are different, so they can be operated independently
of each other (even if the address values are the same).
Exception The MRC #AD360 Dispatch Decoder uses a short (1-127) mobile decoder
address. You can treat the MRC #AD360 as a loco decoder and use
accessory functions F1 and F2 to operate it. It is very easy to use and
program. No accessory address mapping is needed.

Programming Accessory Decoders with CV #513

1. Press PROG until you reach "Prog Prog Track."
2. Press ENTER until "CV #" displays.
3. Enter 513. Press ENTER.
4. Enter the accessory decoder address. Press ENTER.
Read your accessory decoder manual for proper addressing.

Selecting Accessory Decoders

1. Press ACCY. Using 0 - 9, enter the accessory decoder address. Press
ENTER.
2. "1or2" will display reminding you to press only 1 or 2 to control the
accessory. Press 1 to turn the accessory on and 2 to turn it off. You can
keep pressing 1 or 2 until you are done with accessory.
3. Press ENTER to escape accessory operation.

Accessory Routes

Grouping of turnouts (or accessories) can be consisted to form a route. The
Prodigy Advance
accessories in each route. Please do not set a route number higher than
31, nor add more than 8 accessories into one route.
Setting Accessory Decoder Routes (Master Cab only)
1. Press SYS and 5.
2. "Route SET" appears in display. Press ENTER.
3. Enter route number (1 – 31). Press ENTER.
4. "Add Accy #" will display. Using 0 - 9, enter an accessory address (1 to
255).
If you want this accessory (turnout points) to move in a direction opposite
its normally programmed direction (reverse polarity), use DIRECTION to
set its direction. Press ENTER.
5. "Add Accy #" will display again, prompting you to add another accessory
into the route. Repeat above steps to enter up to 8 accessories into one
route.
6. When finished setting up your route, press ENTER.

Running Accessory Routes

1. Press ROUTE. Enter the Route number you wish to run. Press ENTER.
2. "1or2" will display reminding you to press only 1 or 2 to select the routes.
Clearing Accessory Routes (Master Cab only)
1. Press SYS and 0. Then press ENTER.
2. Enter the route number. Then press ENTER.
2-12 Operation
DCC system allows up to 31 routes and up to 8
