Olimpia electronics BS-463/A Quick Start Manual

BS-463/A
Operation VOLTAGE
CONSUMPTION
PRODUCED IN ACCORDANCE WITH
OPERATION TEMPERATURE RANGE
RELATIVE HUMIDITY
EXTERNAL DIMENSIONS
WEIGHT
GUARANTEE
GENERAL
The BS-463/A (figure 1) is a keyboard which
cooperates only with BS-468 panel or BS-
468/A panel from Olympia Electronics.
Using the BS-463/A we can do only simple
operations on
arming/disarming and code entry. To fully
program the panel you need the BS-466 (for
BS-468 panel) or BS-466/A (for BS-468/A
panel) or a personal computer.
Figure 1 : BS-463/A keyboard.
Page 1 from 2
BS-468 PANEL or BS-468/A PANEL

TECHNICAL CHARACTERISTICS

Thank you for your trust in our products
Olympia Electronics - European manufacturer
the panel such
KEYBOARD FOR
Powered by the BS-468 panel or BS-468/A panel
Maximum consumption 32mA
EN 50136-1-1, EN 60950-1
0 to 60 C
Up to 95%
136 x 90 x 28 mm
Keyboard Indicators
Lit means that the panel has an
error and blinking means that there
is an alarm
as
Α
System fully armed
Β
System partially armed
Blinks when there is no power
supply 230V AC
Control Keys
0-9 number entries.
* Menu entry and Enter.
# Cancel key ESC.
A, B, C, ABC keys for immediate arming
without a code.
C and ABC simultaneously to send a panic
signal.
OPERATION
The control of the BS-463/A is simple.
Press the key # and then enter the required
code.
Programming
There are 3 parameters that can be altered
on the keyboard: the address, the
illumination level and the function of the
buzzer. In order to make an alteration, the
keyboard must be set to programming
mode by the technician. The above is done
by pressing the key
(WITHOUT DISPLAY)
o
185gr.
2 years
* + technicians code
921463001_09_003
