BSR-7071/A
SUPPLY VOLTAGE V min - V max
CURRENT LOAD
STANDBY CURRENT
MAX. LEAKAGE CURRENT (I max) WITH THE SWITCH OPEN
MAX. RATED CONTINUOUS CURRENT WITH THA SWITCH CLOSED (I max)
MAX. RATED SWITCHING CURRENT (I max)
MAX. SERIES IMPEDANCE WITH THE SWITCH CLOSED (Z max)
DEGREES OF COVER PROTECTION
PRODUCED IN ACCORDANCE WITH
OPERATION TEMPERATURE
RELATIVE HUMIDITY
DIMENSIONS
WEIGHT
GUARANTEE
GENERAL
The line isolator is a bidirectional non-addressable loop monitoring device for addressable fire
detection system's loops. It is installed on the Addressable Loop, powered by the Loop and
monitors continuously the voltage levels and the signal's integrity. The main supported function
is to isolate a portion of the loop (between the two closer isolators) in the event of a short-
circuit. In case of two short circuit events, only the detectors before the first and after the
second short circuit are powered. Repair of the short circuit condition brings the loop condition
back to normal automatically (closed loop). Location of the short circuit position is achieved by
reading the lost address detectors attached on the top of each isolator. We can have up to 4
additional detectors-devices connected and controlled on a single isolator output (A and B
topology).
It is advised to apply up to 3 additional devices on the output of each isolator (4 detectors or 4
call points or 2 sirens). Maximum resistance between isolators in each loop, should not exceed
the 1,5Ohm. The consumption of the isolator must be considered in modification of existing
loops, to reduce by one the number of the detectors in full load loops. We can have up to 50
paired units (50 isolators + 50 detectors). For systems with more than 50 paired units, reduce
by one the detectors for every three added isolators.
The reasons that an isolator device is isolating are stated below.
Page 1 from 5
Line Isolator
TECHNICAL SPECIFICATIONS
L
s
Thank you for your trust in our products.
Olympia Electronics - European manufacturer.
c
c
21-30V DC
0-500 mA
200 μA
3mA
0.5 Α
2 Α
0.050 Ohm
IP 20
EN 54-17
-10 to 60 °C
Up to 95%
Ø106mm x 41mm
130gr
2 years
921707100_09_006
Advertisement
Table of Contents
Summary of Contents for Olimpia electronics BSR-7071/A
- Page 1 BSR-7071/A Line Isolator TECHNICAL SPECIFICATIONS SUPPLY VOLTAGE V min - V max 21-30V DC CURRENT LOAD 0-500 mA STANDBY CURRENT 200 μA MAX. LEAKAGE CURRENT (I max) WITH THE SWITCH OPEN MAX. RATED CONTINUOUS CURRENT WITH THA SWITCH CLOSED (I max) 0.5 Α...
- Page 2 Α’ topology Isolator Simple detectors Isolator Simple detector Β’ topology C’ topology Short Circuit on Loop Wiring Α’ topology Address Address Address Short Circuit Detector ON Detector ON Detector ON Β’ topology Address Detector ON Electrically, the attached detectors are connected to the output of each isolator. This is why regardless the isolator state it is possible the attached detectors to be operational, like the above two topologies (Α...
- Page 3 Instructions to the installer. Reasons that lead to isolation 1. Short Circuit condition 2. Wrong Polarity on Input Output terminals 3. More than 3 devices connected on the isolator output 4. Increased losses on the loop wiring 5. Protocol integrity faults Installation - Comments 1.
- Page 4 Photos of the Product Isolator BSR-7071/A Input / Output Connection Terminals Mounting Screws +L -L +L -L Smoke Detector attached on top of isolator BSR-7071/A Polarity of Terminals Packaging of BSR-7071/A with the manual and the mounting parts. Page 4 from 5 921707100_09_006...
- Page 5 HEAD OFFICE km. O.N.R. Thessaloniki-Katerini P.C. 60300 P.O. Box 06 Εginio Pierias Greece www.olympia-electronics.gr info@olympia-electronics.gr Certification BSR-7071/A LINE ISOLATOR The Line Isolator BSR-7071/A is certified 0848 from H.E.E.Q.A.C. Also H.E.E.Q.A.C. controls the production under CPR 0848-CPR-014 number: EN-54-17: 2005 KOLINDROS PIERIAS...
