Summary of Contents for Luminator Renew System
- Page 1 OPERATING & INSTRUCTION MANUAL Renew™ Air Treatment Solution | Version 1.0 www.luminator.com...
-
Page 2: Table Of Contents
Configure a Static IP Address ............................17 Copyright 2020 Luminator Technology Group, Inc. The information contained in this document is proprietary to Luminator Technology Group, Inc., and shall not be used or reproduced for any purpose without prior written consent. -
Page 3: Introduction
INTRODUCTION 1.1 OVERVIEW This version of Luminator Technology Group’s Renew™ Air Treatment System is manufactured and designed for installation and use in transit, rail and vehicle applications. This guide has basic product information such as mounting information, connections, and startup procedures for the system –... -
Page 4: System Atomizer
SYSTEM ATOMIZER 2.1 INTRODUCTION The Renew System Atomizer includes a fluid pump, air pump, heating element, power supply, and microcontroller. The Atomizer is designed to disperse Grignard Pure and is designed to be controlled autonomously using the Renew Controller and Renew Sensor. -
Page 5: Connections
5 pin XLR Pin Receptacle connector Used to control the Atomizer Half duplex RS485 DMX Protocol RDM protocol (Future) Data +/-, GND 3 Pin Twist Lock Receptacle connector Used to power the Atomizer 120VAC Page 5 www.luminator.com... -
Page 6: System Controller
SYSTEM CONTROLLER 3.1 INTRODUCTION The Renew System Controller obtains data from the Sensor, to monitor levels of Grignard Pure in the air and continuously adapts the amount of product to be dispersied by the Atomizer. This enables the system to maintain the pre-determined effective concentration at all times. - Page 7 Used for configuration and monitoring of the system Hosted webpage for configuration at IP address 192.168.123.10 USB: Standard USB Host Mode A Connector Utilized for data logging by installing a USB thumb drive Page 7 www.luminator.com...
-
Page 8: Configuration Settings
This value represents the total number of detected vapor droplets between .3 micron and 2.5 microns in size per cubic centimeter. At publication of this document, current efficacy testing concluded this level should be approx 4000 detected particals/cm^3. Page 8 www.luminator.com... -
Page 9: System Sensor
SYSTEM SENSOR 4.1 INTRODUCTION The Renew System Sensor features a PM2.5 Laser Difraction Sensor with RS485 Full Duplex Isolated Interface. The Sensor detects levels of Grignard Pure in the air and transmits this data to the Controller. 4.2 POWER The Sensor is powered from the Controller with 5V DC power source. -
Page 10: Initial System Setup
GREATLY EXCEEDS THE EFFICACY LEVEL NEEDED. THIS INITIAL BURST WOULD NEED TO DISSIPATE TO LOWER LEVELS BEFORE THE SYSTEM WILL TURN BACK ON. NOTE: THE FLUID IN THE TUBING IS DETECTED BY A SENSOR. IF AN AIR BUBBLE OR NO FLUID IS PRESENT, THE SYSTEM WILL NOT OPERATE. Page 10 www.luminator.com... -
Page 11: Activate The Controller
NOTE: WITH EARLY SOFTWARE VERSIONS THIS CALIBRATION STEP COULD TAKE SEVERAL MINUTES E.G. 8 MINUTES. NOTE: EFFECTIVE ATOMIZED LEVELS OF GRIGNARD PURE MAY BE TOO SMALL TO BE VISIBLE. NOTE: THE STATUS OF THE SYSTEM CAN BE VIEWED BY CONNECTING A LAPTOP PER THE INSTRUCTIONS IN SECTION 0. Page 11 www.luminator.com... -
Page 12: Renew System Application
RENEW SYSTEM APPLICATION 6.1 INTRODUCTION The Controller features a web application to provide the following functions: System status System configuration Date and time setting Firmware upgrades Accessing this site is not necessary for the system to operate. However, it can be used to change system parameters. -
Page 13: Accessing The Application
FIGURE 4 : RENEW CONTROLLER WEB PAGE 6.3 CONTROLLER STATUS The system status displays the various system states such as: Connection to the Sensor Automatic Sensor cleaning Automatic Sensor calibration Currently dispensing Grignard Pure Page 13 www.luminator.com... -
Page 14: Controller Configuration
1000 1000 1000 no action is taken by the Controller This is based on live virus efficacy testing, PM Threshold (#/cm^3) 3500 3500 3500 3500 higher numbers are not necessarily more effective FIGURE 6 : CONTROLLER CONFIGURATION Page 14 www.luminator.com... -
Page 15: Controller Software Upgrade
The Controller application interface supports easy software upgrades. Required items: A .hex file supplied by Luminator 1. Using a browser, select the file as shown in the following figure. FIGURE 7: CONTROLLER SOFTWARE UPGRADE 2. The application will ask you to confirm the upgrade, as shown in the following figure. -
Page 16: Controller Date And Time Settings
OFF, THE NEXT TIME POWER IS APPLIED, THE DATE AND TIME WILL RESUME WHERE IT LEFT OFF. 1. Select “Set Date/Time” from the menu. 2. Enter the desired settings. 3. Select “Set” to save the settings. FIGURE 9: RENEW CONTROLLER DATE AND TIME Page 16 www.luminator.com... -
Page 17: Appendix
Controller or to monitor system status. 1. Navigate to the “Control Panel” of the computer and select “Network and Sharing Center” FIGURE 10: ACCESSING THE NETWORK SHARING CENTER Page 17 www.luminator.com... - Page 18 2. Select “Change Adapter Settings” FIGURE 11: ACCESSING NETWORK ADAPTER SETTINGS 3. Select the “Local Area Connection”, right click and select “Properties” FIGURE 12: MODIFY LAN CONNECTION SETTINGS Page 18 www.luminator.com...
- Page 19 FIGURE 13: CHANGE LOCAL AREA NETWORK SETTINGS 5. Select “Use the Following Address” and set the static IP Address and Subnet mask on the same subnet as the Controller. Example: 192.168.123.20 and 255.255.255.0 FIGURE 14: SETTING STATIC IP ADDRESS Page 19 www.luminator.com...
