SSB- 6113
120Amp, 12V/24V Programmable Battery Protector
This manual contains important safety and operation instructions for correct use of the battery protector.
Read through the manual and pay special attention to the markings and labels of the protector,
Failure to heed this warning may cause injury to persons and damage to Equipment.
Warning and Precautions
●
The protector is not designed for any life saving application.
●
The protector is not designed for environments that would allow water to come in contact with terminals on the housing
which would result a short circuit.
●
Install the protector in environments with sufficient ventilated space around the unit to allow dissipation of heat at the
surface, a minimum of 50mm surrounding space is required.
●
Wear protective goggles and turn your face away when connecting or disconnecting the battery.
●
Never smoke, use an open flame, or create sparks near battery or protector during normal operation as batteries may give
out explosive gas.
●
Do not use the protector if it has been dropped or damaged.
●
Do not remove casing of the protector, there is no user -serviceable parts inside.
●
If the protector does not work properly or if it has been damaged, unplug all DC connections.
Copy Right
All rights reserved.
No part of this publication may be reproduced, or transmitted in any form or by any means without the written
permission from Manson Engineering Industrial Ltd.
Changes in the manual.
Manson Engineering Industrial Ltd. has the right to update and change the content of this manual without any prior
notice and obligation.
Disclaimer
Exclusions for documentation, Indemnity and Product application.
Manson Engineering Industrial Ltd. (Manson)
1)
Assumes no warranty to the accuracy, suitability of technical information given in the user manuals or other documentation.
2)
Undertakes no responsibility or liability of losses, damages and related expenses whether specific, direct, indirect
consequential or accidental which might result from the use of information given in this manual.
3)
Shall not be liable to anyone for any special, collateral, incidental or consequential damages in connection with or from the
use of these Manson products. The sole and exclusive liability to Manson, regardless of the form of action shall not exceed
the purchase price of the Manson product.
Operation Manual
Keep this manual in a safe place for quick reference at all times.
battery and equipment connected to the battery system.
Pay special attention to these two types of notices used in this manual.
Failure to observe this warning may result in damage to equipment
and improper functioning of the protector.
WARNING:
CAUTION:
Advertisement
Related Manuals for Manson Engineering Industrial SSB-6113
Summary of Contents for Manson Engineering Industrial SSB-6113
- Page 1 No part of this publication may be reproduced, or transmitted in any form or by any means without the written permission from Manson Engineering Industrial Ltd. Changes in the manual. Manson Engineering Industrial Ltd. has the right to update and change the content of this manual without any prior notice and obligation. Disclaimer Exclusions for documentation, Indemnity and Product application.
- Page 2 Cable Sizes and Fuses Cables used at each positive terminal must be of sufficient rating, under sized cables would affect the performance of the unit and shortens the life span. Wires connected to control or signal ports carry less than 0.5 Amp. Fuses or circuit breakers of appropriate rating must be installed at positive terminal of the house battery and main battery.
- Page 3 If no selection is done within 10sec., unit will go back to last set system voltage. Remark: You have about 10 seconds to confirm your setting otherwise the SSB-6113 will go to the last set system voltage or factory default setting.
- Page 4 4.3 Set Menu Mode 2 ------ Setting the Connect Voltage / Isolate Voltage / Alert Voltage /Delay Time The procedure is same for setting and adjusting all the above parameters. Example: Setting Connect Voltage During the Review stage as in 4.2, toggle the button to get to Connect Voltage position.
- Page 5 Operation of SSB-6113 The LED display and Remote Alert signal port Normally the display is turned off to conserve energy, press any one of the two buttons to wake up the display. When unit is in isolated (disconnect) mode, the display shows...
- Page 6 Installation (Example for 12VDC system) 7.1 The selection of Isolate Voltage and Connect Voltage are very much affected by the type of load and relative battery capacity. Select a higher Isolate Voltage for relatively smaller load; for high initial draw load such as Motor, choose a lower Isolate Voltage.
- Page 7 8.1 Connection of the supplied accessory “Remote LED indicator w Override button” to the above control port [Neg.], [A], [R] Black wire to [Neg.] Negative ground Red wire to Main terminal Remote Override function Green wire to [R] Remote Override function Yellow wire to [A] LED indicator Remark: If no intention to use Remote Over-ride Connection, then do not wire up Main terminal and [R] port.
-
Page 8: Specifications
SPECIFICATIONS Battery Voltage System 12V System 24V System Default Range Default Range Isolator Setting Connect Voltage 13.7VDC 9.2 - 16VDC 27.4VDC 18.4 - 32VDC 12.8VDC 9 - 15.8VDC 25.6VDC 18 - 31.6VDC Isolate Voltage Alert Voltage 12.0VDC 9 - 15.9VDC 24.0VDC 18 - 31.8VDC Connect Delay...
